NOTE:
please make sure the connected critical loads will not exceed the remaining
parallel unit's total capacity.
UPS 1
Q2
BYPA.
Q1
MAIN
Batteries
UPS 2
Q2
BYPA.
Q1
MAIN
Batteries
(Figure 3-25: Manual Bypass Mode Diagram_ Dual Input Parallel Units)
Static Switch
Rectifier
Inverter
Static Switch
Rectifier
Inverter
3-25
3
Operation Modes
Q3
Q3
LOAD
