2.4

Exterior and Dimensions

2.5

Front View

On the front of the UPS, there are a 10" color touch panel, a tri-color LED indictor, a door
switch, six casters and four leveling feet. Please see Figure 2-2.
1. For information about the 10" color touch panel, please refer to 7. LCD Display &
Settings.
2. For information about the tri-color LED indicator, please refer to 2.8 Tri-color LED
Indicator & Buzzer.
3. The casters at the bottom of the UPS can be used to move over short distances, and
the leveling feet fix and stabilize the UPS on the ground. Please refer to 5.3 UPS
Transportation for relevant information.
4. Please refer to Figure 2-3 for how to open the UPS front door.
Modulon DPH Series
850
mm
600
mm
(Figure 2-1: Exterior & Dimensions)
2-6
2000
mm
