LCD Display Hierarchy

(Level 1)
UPS-1.1 MEASUREMENT
(Level 2)
Power Flow
(Level 2)
Summary
Input
Main Voltage
Bypass Voltage
Output
Frequency
Voltage
Current
Load
Output Power
Battery
Runtime Remaining
Voltage
Charge Current
(Level 2)
System Status
Modulon DPH Series
(Level 1) (Level 1)
SETUP
(Level 2)
Bypass setting
Main Input
Bypass Frequency Range/
Phase Voltage (V)
Bypass Voltage (Max)/
Line Voltage (V)
Bypass Voltage (Min)/
Current (A)
ECO Voltage Range (±%)
Frequency (Hz)
Mode Setting
(Level 2)
Bypass Input
On-Line/ Green/ ECO/
Energy Recycle/
Phase Voltage (V)
Frequency Conversion
Line Voltage (V)
Frequency (Hz)
Output Setting
(Level 2)
Voltage (V) / Frequency (Hz) /
Inverter Output
Slew Rate (Hz/s) /
PM Redundancy (V) /
Phase Voltage (V)
Async Transfer Time (ms) /
Current (A)
Module Sequential Start (s) /
Frequency (Hz)
System Sequential Start (s)
(Level 2)
Power Module Battery & Charging Setting
* 1
Summary
Battery Type/ Battery Rating Voltage/
Phase Voltage (V)
Battery Strings/ Battery Low Warning/
Current (A)
Battery Cut Off Voltage/ Capacity/
DC BUS Voltage
Float Charge Voltage/
PM A/D
Equalized Charge Voltage/
PM D/D
Charge Current (Max)/
Auto Equalized Charge/
(Level 2)
Auto Equalized Charge Interval/
Auto Equalized Charge Time/
UPS Output
Battery Test Fail Voltage/
Battery Test Duration/
Phase Voltage (V)
Auto Battery Test Interval/
Line Voltage (V)
Low Temperature Alarm/
Current (A)
High Temperature Alarm/
Frequency (Hz)
Installation Date/ Next Replacement Date
Load (%)
Apparent Power (KVA)
Active Power (KW)
Parallel Setting
Power Factor
(Level 2) Parallel Group ID/ Parallel ID/
Common Battery
Battery Status
Status/ Dry Contact Setting
Voltage (V)/
Current (A)/
Input Dry Contact : 1 ~ 4
Remaining Capacity (%)/
Output Dry Contact : 1 ~ 6
Remaining Time (mins)/
Estimated Recharging
Time (mins)
General Setting
Test Result/
Battery Temp. #1 (°C)/
Date/ Time
Battery Temp. #2 (°C)/
Date Format/ Date/ Time
Battery Temp. #3 (°C)/
Screen
Battery Temp. #4 (°C)/
Screen Brightness/ Screen Sleep (after)
Charge Voltage
of PM# (V)/
User
* 1
Charge Current
Language/ MODBUS ID/
of PM# (A)
Admin Password
* 1
Dust Filter
Dust Filter Installation/
Dust Filter Installation Date/
Dust Filter Replacement Date
DHCP Client/ IP Address/
Subnet Mask/ Gateway IP/
DNS 1 IP/ DNS 2 IP/ Search Domain
Host Name
Buzzer
Force Equalized Charge/
Force Bypass to Inverter/
Reset Module/
(Figure 7-1 : LCD Display Hierarchy)
MAINTENANCE
(Level 2)
1
*
(Level 2)
1
*
(Level 2)
1
*
(Level 2)
1
*
(Level 2)
* 1
(Level 2)
1
*
(Level 2)
1
*
1
*
* 1
(Level 2)
IP Setting
* 1
(Level 2)
Control
1
*
1
*
Reset System
1 1
* *
7-2
(Level 1) (Level 1)
LOG IN
(Level 2)
Warning Log-in ID:
Warning
(Level 2)
Historical Event
Log-in ID:
Administrator
Historical Event
(Level 2)
Statistics
In Battery Mode
Battery Mode Duration
In Bypass Mode
Bypass Mode Duration
Operation Time
(Level 2)
Test
1
*
Manual Battery Test
(Level 2)
Clear
* 1
Clear Statistics
Clear Historical Event
Clear Battery Test Result
(Level 2)
Advanced
Diagnosis 1
*
System
STS Temp. (°C)
Battery Temp. (°C)
Fan Speed (rpm)
Power Module
INV Temp. (°C)
PFC Temp. (°C)
(Level 2)
Version & S/N
S/N
System
Touch Panel
Power Module#
MAIN
COM_MCU / FPGA
System_MCU / FPGA
Touch Panel_MCU / FPGA
INV
Power Module#_MCU / FPGA
PFC
Power Module#_MCU / FPGA
(Level 1)
EVENT LOG
(Level 2)
User
(Level 2)
