Delta Modulon DPH series User Manual
  1. Manuals
  2. Brands
  3. Delta Manuals
  4. UPS
  5. Modulon DPH series
  6. User manual

Delta Modulon DPH series User Manual

Three phase, 100-300 kva
Hide thumbs Also See for Modulon DPH series:
Table of Contents

Advertisement

Quick Links

Download this manual
The power behind competitiveness
Delta UPS - Modulon Family
DPH Series, Three Phase
100-300 kVA
User Manual
www.deltapowersolutions.com

Advertisement

Table of Contents
loading

Related Manuals for Delta Modulon DPH series

Summary of Contents for Delta Modulon DPH series

  • Page 1 The power behind competitiveness Delta UPS - Modulon Family DPH Series, Three Phase 100-300 kVA User Manual www.deltapowersolutions.com...
  • Page 2 Copyright © 2018 by Delta Electronics Inc. All Rights Reserved. All rights of this User Manual (“Manual”), including but not limited to the contents, information, and figures are solely owned and reserved by Delta Electronics Inc.

  • Page 3: Table Of Contents

    Table of Contents Table of Contents Important Safety Instructions ---------------------------------------------- 1-1 Installation Warnings ---------------------------------------------------------------------- 1-2 Connection Warnings --------------------------------------------------------------------- 1-2 Usage Warnings --------------------------------------------------------------------------- 1-3 Storage Warnings ------------------------------------------------------------------------- 1-5 Standard Compliance -------------------------------------------------------------------- 1-5 Introduction ---------------------------------------------------------------------- 2-1 General Overview ------------------------------------------------------------------------- 2-2 Package Inspection ----------------------------------------------------------------------- 2-2 Functions &...
  • Page 4 External Battery Temperature Dry Contacts ------------------------------ 4-5 4.1.4 External Switch/ Breaker Status Dry Contacts -------------------------- 4-6 4.1.5 Output Dry Contacts ------------------------------------------------------------ 4-7 4.1.6 Input Dry Contacts -------------------------------------------------------------4-10 4.1.7 Parallel Communication Cards --------------------------------------------- 4-11 4.1.8 Parallel Ports --------------------------------------------------------------------4-12 4.1.9 SMART Slot ---------------------------------------------------------------------4-12 Modulon DPH Series...
  • Page 5 Table of Contents 4.1.10 USB Port & RS-232 Port -----------------------------------------------------4-13 4.1.11 Auxiliary Power Cards --------------------------------------------------------4-13 4.1.12 Battery Start Buttons ----------------------------------------------------------4-14 Communication Interfaces at the Rear of the Touch Panel --------------------4-14 Installation and Wiring ------------------------------------------------------- 5-1 Before Installation and Wiring ---------------------------------------------------------- 5-2 Installation Environment ---------------------------------------------------------------- 5-2 UPS Transportation ---------------------------------------------------------------------- 5-4 Fixing the UPS ----------------------------------------------------------------------------- 5-5...
  • Page 6 Power Flow, Summary, System Status & EMS -----------------------------------7-19 Check System Readings ---------------------------------------------------------------7-21 7.9.1 Main Input ------------------------------------------------------------------------7-21 7.9.1.1 Check Kilowatt-Hour ----------------------------------------------------------7-22 7.9.2 Bypass Input --------------------------------------------------------------------7-33 7.9.3 Inverter Output ------------------------------------------------------------------7-33 7.9.4 Power Module Summary -----------------------------------------------------7-34 7.9.5 UPS Output ----------------------------------------------------------------------7-34 7.9.6 Battery Status -------------------------------------------------------------------7-35 7.9.7 EMS -------------------------------------------------------------------------------7-36 Modulon DPH Series...
  • Page 7 Table of Contents 7.9.7.1 Connecting the optional EMS 1000 (EnviroProbe) --------------------7-40 7.10 UPS Settings ------------------------------------------------------------------------------7-40 7.10.1 Bypass Setting ------------------------------------------------------------------7-40 7.10.2 Mode Setting --------------------------------------------------------------------7-41 7.10.3 Output Setting -------------------------------------------------------------------7-42 7.10.4 Battery & Charging Setting --------------------------------------------------7-44 7.10.5 Parallel Setting ------------------------------------------------------------------7-47 7.10.6 Dry Contact Setting -----------------------------------------------------------7-48 7.10.7 General Setting -----------------------------------------------------------------7-50 7.10.8 IP Setting -------------------------------------------------------------------------7-53 7.10.9 Control ----------------------------------------------------------------------------7-54...

  • Page 9: Important Safety Instructions

    Important Safety Instructions Important Safety Instructions 1.1 Installation Warnings 1.2 Connection Warnings 1.3 Usage Warnings 1.4 Storage Warnings 1.5 Standard Compliance...

  • Page 10: Installation Warnings

    Leave adequate space around all sides of the UPS for proper ventilation and mainte- nance. Please refer to 5.2 Installation Environment. Only authorized Delta engineers or service personnel can perform installation and maintenance. If you want to install the UPS by yourself, please install it under the su- pervision of authorized Delta engineers or service personnel Follow the IEC 60364-4-42 standard to install the UPS.

  • Page 11: Usage Warnings

    (that have serious surge current) to the UPS, it needs to be de-rated according to on-site applications. For such special applications, please contact Delta service personnel for the accurate UPS sizing. The UPS is not suitable for connecting with any asymmetrical loads.
  • Page 12 Do not open or remove the covers or panels of the UPS to avoid high voltage electric shock. Only authorized Delta engineers or service personnel can do so for installation or maintenance. If you want to open or remove the covers or panels, do it only under the supervision of authorized Delta engineers or service personnel.

  • Page 13: Storage Warnings

    Important Safety Instructions 3. Any conductive powders or metals enter into the UPS. 4. The UPS does not run normally after carefully following the instructions in this User Manual. Storage Warnings Use the original packing material to pack the UPS to prevent any possible damage from rodents.

  • Page 15: Introduction

    Introduction Introduction General Overview Package Inspection Functions & Features Exterior and Dimensions Front View Internal View Rear View Tri-color LED Indicator & Buzzer...

  • Page 16: General Overview

    1. Check the rating label attached to the UPS and make sure the device No. and capacity match what you ordered. 2. Examine if any parts are loose or damaged. 3. The UPS package contains the following items. Please check if any items are missing. Modulon DPH Series...
  • Page 17 Introduction The power behind competitiveness Delta UPS - Modulon Family DPH Series, Three Phase 100-300 kVA User Manual www.deltapowersolutions.com × 30 × 8 × 4 × 8 × 2 × 2 Item Q'ty 1 PC on the inner side of the UPS front door before...

  • Page 18: Functions & Features

    2. The UPS returns automatically to normal mode from bypass mode after an overload condition is cleared. Automatically detects whether bypass voltage is out of rating voltage (default: voltage ±15% & frequency ±3Hz). If yes, the UPS will stop supplying power to the critical loads to protect your electronic equipment. Modulon DPH Series...
  • Page 19 Introduction Supports ECO mode: when input voltage and frequency are within the range of rating voltage ±10% and rating frequency ±3Hz, the UPS will transfer to bypass mode; other- Both auxiliary power and control circuit adopt redundancy design, which doubly en- hances UPS reliability.

  • Page 20: Exterior And Dimensions

    Moreover, fan failure detection circuit is established. State-of-the-art microprocessor technology performs self-detection and monitors fan speed in real time, which provides complete and detailed operating status of the UPS. Exterior and Dimensions 2000 1100 (Figure 2-1: Exterior & Dimensions) Modulon DPH Series...

  • Page 21: Front View

    Introduction Front View On the front of the UPS, there are a 10” color touch panel, a tri-color LED indicator, a door switch, six casters and four leveling feet. Please see Figure 2-2. 10” Color Tri-color LED Touch Panel Indicator Door Switch Casters Leveling Feet...

  • Page 22: Internal View

    (Figure 2-3: How to Open the UPS Front Door) Internal View WARNING: Only authorized Delta engineers or service personnel can perform installation, wiring, panel & cover removal, maintenance and operation. If you want to execute any action mentioned above by yourself, the action must be under the supervision of authorized Delta engineers or service personnel.
  • Page 23 Introduction Internal View (Front View with Door Open) Communication Interfaces DISPLAY BATT. EXT. BATT EXT.SWITCH O/P DRY I/P DRY START BT1 BT2 TEMP. STATUS CONTACT CONTACT PARALLEL REPO BATT. START BT3 BT4 PARALLEL RS-232 GND B A GND B A MODBUS BMS Power Module Slot ×...

  • Page 24: Rear View

    (Figure 2-5: Location of the Four Breakers) Rear View WARNING: Only authorized Delta engineers or service personnel can perform installation, wiring, panel & cover removal, maintenance and operation. If you want to execute any action mentioned above by yourself, the action must be under the supervision of authorized Delta engineers or service personnel.
  • Page 25 Introduction Figure 2-6 is the UPS rear view. To see the wiring terminals shown in Figure 2-8 ~ Figure 2-10, please remove the rear panel’s eight M5 screws shown in Figure 2-7. (Rear) (Rear) M5 Screw × 8 Rear Panel (Figure 2-6: UPS Rear View) (Figure 2-7: Location of the Rear Panel &...
  • Page 26 (Figure 2-9: Wiring Terminals_ Battery Input & UPS Output) (Rear View after Rear Panel Removal) Grounding Terminals for Top Wiring ( & INPUT BYPA SS INPUT Grounding Terminals for Bottom Wiring ( & (Figure 2-10: Wiring Terminals_ Grounding) Modulon DPH Series 2-12...

  • Page 27: Tri-Color Led Indicator & Buzzer

    Introduction Tri-color LED Indicator & Buzzer Please see Figure 2-11 for the location of the tri-color LED indictor. For information about the tri-color LED indicator, please refer to Table 2-1. For information about the 10” color touch panel, please refer to 7. LCD Display & Settings. 10:15 May 25,2018 UPS-1.1...
  • Page 28 ‘Energy Recycle’ Mode Indicates a minor or medium warning, accompanied with buzzer sound. Warning Level Buzzer Frequency Minor Sounds 50ms every 3 seconds. Medium Sounds 50ms every second. To clear the warning, please refer to 10. Troubleshooting. Modulon DPH Series 2-14...
  • Page 29 Introduction Tri-color LED Status Meaning Indicator Indicates a major warning, accompanied with buzzer sound. Warning Level Buzzer Frequency Major Long beep To clear the warning, please refer to 10. Troubleshooting. 2-15...

  • Page 31: Operation Modes

    Operation Modes Operation Modes 3.1 Single Input 3.2 Dual Input 3.3 Hot Standby Redundancy (Only For Dual Input & At Least Two UPSs) 3.4 Common Battery (Only for Parallel UPSs connecting to the Same External Battery Cabinet(s))

  • Page 32: Single Input

    After receiving the DC power, the inverter converts it into clean and stable AC power to the connected critical loads via the Output Breaker (Q4). Please refer to Figure 3-1. During On- Line mode, the UPS’s tri-color LED illuminates green and the text 'On-Line' appears in the upper right corner of the screen. Modulon DPH Series...

  • Page 33: Battery Mode_ Single Input_ Single Unit

    Operation Modes Static Switch Rectifier Inverter MAIN LOAD Batteries (Figure 3-1: On-Line Mode Diagram_ Single Input Single Unit) 3.1.2 Battery Mode_ Single Input_ Single Unit The UPS transfers to Battery mode automatically if the main AC source is abnormal, for example, when unstable voltage or a power outage occurs.

  • Page 34: Bypass Mode_ Single Input_ Single Unit

    (see Figure 5-11~Figure 5-13 for the location of these terminal blocks and terminals) and any copper bars connected to the Manual Bypass Breaker (Q3), as they may carry high voltage. the connected critical loads are not protected. Modulon DPH Series...
  • Page 35 Operation Modes When the UPS needs maintenance, you can manually switch the UPS to Manual Bypass mode. To let the UPS run in Manual Bypass mode, please follow the procedures below: Tap the LCD’s ON/ OFF Button ( ) and the 'POWER OFF?' screen will pop up to 'YES'.

  • Page 36: Eco Mode_ Single Input_ Single Unit

    For the diagram of Frequency Conversion mode, please see Figure 3-6. During Frequency Conversion mode, the UPS’s tri-color LED illuminates green and the text 'Frequency Conversion' appears in the upper right corner of the screen. Modulon DPH Series...

  • Page 37: Green Mode_ Single Input_ Single Unit

    Operation Modes Static Switch Rectifier Inverter MAIN LOAD Batteries (Figure 3-6: Frequency Conversion Mode Diagram_ Single Input Single Unit) 3.1.7 Green Mode_ Single Input_ Single Unit To activate Green mode, please refer to 6.2.7 Green Mode Start-up Procedures, 7.6 Main Screen and 7.10.2 Mode Setting.

  • Page 38: Energy Recycle Mode_ Single Input_ Single Unit

    UPS’s tri-color LED illuminates yellow and the text 'Energy Recycle' appears in the upper right corner of the screen. Static Switch Rectifier Inverter MAIN LOAD Batteries (Figure 3-8: Energy Recycle Mode Diagram_ Single Input Single Unit) Modulon DPH Series...

  • Page 39: On-Line Mode_ Single Input_ Parallel Units

    Operation Modes 3.1.9 On-Line Mode_ Single Input_ Parallel Units In On-Line mode (parallel), the total loads will be equally shared by parallel UPSs. If one of the parallel units fails and its load is less than the total capacity of the remaining parallel units, the failing UPS's output will be switched off and its load will be equally shared by the remaining parallel units.

  • Page 40: Battery Mode_ Single Input_ Parallel Units

    'Battery' in the upper right corner. Please refer to Figure 3-10 for the path of electrical power through the parallel UPSs in Battery mode. Static Switch Rectifier Inverter MAIN Batteries LOAD Static Switch Rectifier Inverter MAIN Batteries (Figure 3-10: Battery Mode Diagram_ Single Input Parallel Units) Modulon DPH Series 3-10...

  • Page 41: Bypass Mode_ Single Input_ Parallel Units

    Operation Modes 3.1.11 Bypass Mode_ Single Input_ Parallel Units In Bypass mode (parallel), when all inverters encounter abnormal situations such as overload, short circuit, abnormal output voltage or low battery, they will automatically shut themselves down. Meanwhile, if all parallel UPSs detect the bypass AC source is normal, they will automatically switch to Bypass mode to protect the connected critical loads from power interruption.

  • Page 42: Manual Bypass Mode_ Single Input_ Parallel Units

    Power of the connected critical loads will be supplied by manual bypass. During Manual Bypass mode (parallel), all parallel Figure 3-12 for the path of electrical power through the parallel UPSs in Manual Bypass mode. Modulon DPH Series 3-12...
  • Page 43 Operation Modes Static Switch Rectifier Inverter MAIN Batteries LOAD Static Switch Rectifier Inverter MAIN Batteries (Figure 3-12: Manual Bypass Mode Diagram_ Single Input Parallel Units) 3-13...

  • Page 44: Eco Mode_ Single Input_ Parallel Units

    'ECO' in the upper right corner. Please see Figure 3-13 for the path of electrical power through the parallel UPSs in ECO mode. Static Switch Rectifier Inverter MAIN Batteries LOAD Static Switch Rectifier Inverter MAIN Batteries (Figure 3-13: ECO Mode Diagram_ Single Input Parallel Units) Modulon DPH Series 3-14...

  • Page 45: Green Mode_ Single Input_ Parallel Units

    Operation Modes 3.1.14 Green Mode_ Single Input_ Parallel Units To activate Green mode, please refer to 6.2.7 Green Mode Start-up Procedures, 7.6 Main Screen and 7.10.2 Mode Setting. that each parallel UPS’s system will automatically detect its own output status (i.e. total load color LED illuminates green and each UPS’s LCD shows the text 'Green' in the upper right corner.

  • Page 46: Dual Input

    Output Breaker (Q4). During the conversion process, output voltage remains the same. Please see Figure 3-16 for Battery mode diagram. During Battery mode, the UPS’s tri-color LED illuminates yellow and the text 'Battery' appears in the upper right corner of the screen. Modulon DPH Series 3-16...

  • Page 47: Bypass Mode_ Dual Input_ Single Unit

    Operation Modes Static Switch BYPA. Rectifier Inverter MAIN LOAD Batteries (Figure 3-16: Battery Mode Diagram_ Dual Input Single Unit) 3.2.3 Bypass Mode_ Dual Input_ Single Unit When the inverter encounters abnormal situations such as over temperature, overload, short circuit, abnormal output voltage or low battery, it will automatically shut itself down. If the UPS detects the bypass AC source is normal, it will automatically switch to Bypass mode to protect the connected critical loads from power interruption.

  • Page 48: Manual Bypass Mode_ Dual Input_ Single Unit

    Turn OFF the Bypass Breaker (Q2). Turn OFF the Input Breaker (Q1) and Output Breaker (Q4). Turn OFF each external battery cabinet’s breaker (Q5). personnel can perform maintenance safely. Please see Figure 3-18 for Manual Bypass Modulon DPH Series 3-18...

  • Page 49: Eco Mode_ Dual Input_ Single Unit

    Operation Modes Static Switch BYPA. Rectifier Inverter MAIN LOAD Batteries (Figure 3-18: Manual Bypass Mode Diagram_ Dual Input Single Unit) 3.2.5 ECO Mode_ Dual Input_ Single Unit To activate ECO mode, please refer to 6.2.5 ECO Mode Start-up Procedures, 7.6 Main Screen and 7.10.2 Mode Setting.

  • Page 50: Frequency Conversion Mode_ Dual Input_ Single Unit

    Figure 3-20. During Frequency Conversion mode, the UPS’s tri-color LED illuminates green and the text 'Frequency Conversion' appears in the upper right corner of the screen. Static Switch BYPA. Rectifier Inverter MAIN LOAD Batteries (Figure 3-20: Frequency Conversion Mode Diagram_ Dual Input Single Unit) Modulon DPH Series 3-20...

  • Page 51: Green Mode_ Dual Input_ Single Unit

    Operation Modes 3.2.7 Green Mode_ Dual Input_ Single Unit To activate Green mode, please refer to 6.2.7 Green Mode Start-up Procedures, 7.6 Main Screen and 7.10.2 Mode Setting. Green mode is the same as On-Line mode, but the difference is that the system will the UPS.

  • Page 52: On-Line Mode_ Dual Input_ Parallel Units

    Figure 3-22 for the path of electrical power through the parallel UPSs in On-Line mode. Static Switch BYPA. Rectifier Inverter MAIN Batteries LOAD Static Switch BYPA. Rectifier Inverter MAIN Batteries (Figure 3-22: On-Line Mode Diagram_ Dual Input Parallel Units) Modulon DPH Series 3-22...

  • Page 53: Battery Mode_ Dual Input_ Parallel Units

    Operation Modes 3.2.9 Battery Mode_ Dual Input_ Parallel Units If the main AC source is abnormal, for example, when unstable voltage or a power outage occurs, all parallel UPSs will automatically transfer from On-Line mode to Battery mode. During the conversion process, output voltage remains the same. During Battery mode (parallel), each UPS’s tri-color LED illuminates yellow and each UPS’s LCD shows the text 'Battery' in the upper right corner.

  • Page 54: Bypass Mode_ Dual Input_ Parallel Units

    Please see Figure 3-24 for the path of electrical power through the parallel UPSs in Bypass mode. Static Switch BYPA. Rectifier Inverter MAIN Batteries LOAD Static Switch BYPA. Rectifier Inverter MAIN Batteries (Figure 3-24: Bypass Mode Diagram_ Dual Input Parallel Units) Modulon DPH Series 3-24...

  • Page 55: Manual Bypass Mode_ Dual Input_ Parallel Units

    Operation Modes 3.2.11 Manual Bypass Mode_ Dual Input_ Parallel Units WARNING: 1. In Manual Bypass mode, make sure that all of the breakers (except each UPS’s Manual Bypass Breaker (Q3)) are in the OFF position before working on any of the parallel UPSs’ internal circuits. This avoids electric shock. no high voltage inside all parallel UPSs and maintenance can be performed safely.
  • Page 56 Static Switch BYPA. Rectifier Inverter MAIN Batteries LOAD Static Switch BYPA. Rectifier Inverter MAIN Batteries (Figure 3-25: Manual Bypass Mode Diagram_ Dual Input Parallel Units) Modulon DPH Series 3-26...

  • Page 57: Eco Mode_ Dual Input_ Parallel Units

    Operation Modes 3.2.12 ECO Mode_ Dual Input_ Parallel Units To activate ECO mode, please refer to 6.2.5 ECO Mode Start-up Procedures, 7.6 Main Screen and 7.10.2 Mode Setting. In ECO mode (parallel), when each parallel UPS’s bypass input voltage and frequency are within the range of rating voltage ±10% and rating frequency ±3Hz, each parallel UPS works in Bypass mode;...

  • Page 58: Green Mode_ Dual Input_ Parallel Units

    Please see Figure 3-27 for the path of electrical power through the parallel UPSs in Green mode. Static Switch BYPA. Rectifier Inverter MAIN Batteries LOAD Static Switch BYPA. Rectifier Inverter MAIN Batteries (Figure 3-27: Green Mode Diagram_ Dual Input Parallel Units) Modulon DPH Series 3-28...

  • Page 59: Hot Standby Redundancy (Only For Dual Input & At Least Two Upss)

    Operation Modes Hot Standby Redundancy (Only For Dual Input & At Least Two UPSs) have a hot standby redundancy function. If you use two UPSs and wish them to work in hot standby redundancy mode, please connect the output of UPS1 to the bypass input of UPS 2. Please see Figure 3-28.

  • Page 60: Common Battery

    2. * The item 'Equalized Charge Voltage' will change into 'Restore Voltage' if you use the Delta lithium-ion batteries with the optional multifunctional communication card (MFC) being installed in the smart slot shown in Figure 4-13. For relevant information, please refer to 7.10.4 Battery & Charging Setting.
  • Page 61 Operation Modes Static Switch BYPA. Rectifier Inverter MAIN LOAD Static Switch BYPA. Batteries Rectifier Inverter MAIN (Figure 3-29: Common Battery Diagram_ only for Parallel UPSs Connecting to the Same External Battery Cabinet(s)) 3-31...

  • Page 63: Communication Interfaces

    Communication Interfaces Communication Interfaces 4.1 Communication Interfaces on the Front of the UPS with Front Door Open 4.2 Communication Interfaces at the Rear of the Touch Panel...

  • Page 64: Communication Interfaces On The Front Of The Ups With Front Door Open

    O/P DRY I/P DRY EXT. BATT EXT.SWITCH CONTACT CONTACT TEMP. STATUS BT1 BT2 PARALLEL REPO BATT. NC NO START BT3 BT4 PARALLEL RS-232 (Figure 4-2: Communication Interfaces_ on the Front of the UPS with Front Door Open) Modulon DPH Series...

  • Page 65: Display Port

    LED indicator. 1. You can install the optional Relay I/O card in the slot for dry contact expansion. 2. If you use the Delta lithium-ion batteries, you must purchase the optional multifunctional communication card (MFC) and install it in the SMART slot to monitor the status and...

  • Page 66: Repo Dry Contacts

    Screw × 2 DISPLAY BATT. START O/P DRY I/P DRY EXT. BATT EXT.SWITCH CONTACT CONTACT TEMP. STATUS BT1 BT2 PARALLEL REPO BATT. NC NO START BT3 BT4 PARALLEL RS-232 Dry Contact Card (Figure 4-5: Dry Contact Card Location) Modulon DPH Series...

  • Page 67: External Battery Temperature Dry Contacts

    Communication Interfaces Jump CNR3 Dry Contact Card (Figure 4-6: Jump CNR3 Location) 4.1.3 External Battery Temperature Dry Contacts You can use the external battery temperature dry contacts (BT1, BT2, BT3 and BT4) to detect at maximum four external battery cabinets’ temperature. You need to purchase the battery cabinet temperature sensor cable (optional).

  • Page 68: External Switch/ Breaker Status Dry Contacts

    Dry Contact_ S3 Normally closed (NC) device Dry Contact_ S4 Normally closed (NO) device EXT.SWITCH STATUS 2mA. Max Buffer 2mA. Max Buffer 2mA. Max Buffer 2mA. Max Buffer (Figure 4-8: External Switch/ Breaker Status Dry Contacts Design) Modulon DPH Series...

  • Page 69: Output Dry Contacts

    Communication Interfaces Event Description External input switch or breaker Detect the external input switch or breaker’s detection. status (default: S1). External bypass switch or Detect the external bypass switch or breaker’s breaker detection. status (default: S2). External output switch or Detect the external output switch or breaker’s breaker detection.
  • Page 70 P4 (Max. 0.5A/12V) DRY 4 DRY C_NO P3 (Max. 0.5A/12V) +12VS P2 (Max. 0.5A/12V) P1 (Max. 0.5A/12V) COMM_C DRY 3 DRY B_NO +12VS COMM_B DRY 2 DRY A_NO +12VS COMM_A DRY 1 (Figure 4-9: Output Dry Contacts Design) Modulon DPH Series...
  • Page 71 Communication Interfaces Event Description None No set-up. Load On Inverter The UPS works in online mode. Load On Bypass The UPS works in bypass mode. When the main AC source fails, the batteries supply Load On Battery power to the critical loads. When the UPS runs in battery mode, battery voltage Battery Low is lower than the setup limit (default: 220Vdc).

  • Page 72: Input Dry Contacts

    To learn how to set up, please contact your local dealer and refer to 7.10.6 Dry Contact Setting. I/P DRY CONTACT Dry-1 Buffer 2mA. Max Dry-2 Buffer 2mA. Max Dry-3 2mA. Max Buffer Dry-4 2mA. Max Buffer (Figure 4-10: Input Dry Contacts Design) Modulon DPH Series 4-10...

  • Page 73: Parallel Communication Cards

    NOTE: If you use non-Delta lithium-ion batteries, you must set up these two items. Please refer to 7.10.6 Dry Contact Setting to perform relevant setup. If you have any questions, please contact Delta customer service. 4.1.7 Parallel Communication Cards The UPS has two parallel communication cards, which are master parallel communication card and backup parallel communication card.

  • Page 74: Parallel Ports

    Figure 4-13. For relevant installation and application information, please contact Delta customer service. 2. If you use the Delta lithium-ion batteries, you must purchase the optional multifunctional communication card (MFC) and install it in the SMART slot shown in Figure 4-13 to monitor the status and information of the Delta lithium-ion batteries.

  • Page 75: Usb Port & Rs-232 Port

    Communication Interfaces 4.1.10 USB Port & RS-232 Port You can use the provided RS-232 cable or the USB cable to connect the UPS’s RS-232 port or USB port with a computer, and use either the USB port or the RS-232 port to (1) upgrade the firmware of UPS, power modules, system control card and parallel communication cards, and (2) download event logs.

  • Page 76: Battery Start Buttons

    A GND RESET MODBUS INP UT BRE AKE R OU TPU T BRE AKE BYP ASS BRE AKE MA NU AL BYP ASS BRE AKE (Figure 4-17: Communication Interfaces _ at the Rear of the Touch Panel) Modulon DPH Series 4-14...
  • Page 77 MODBUS function. (Built-in MODUBS card) 2. Connects to a user-supplied monitoring system. Connects to the Delta battery management system (optional). The BMS port application is only applicable to sealed lead-acid batteries. Please refer to 7.10.4 Battery & Charging Setting. Before shipment, the DISPLAY port has been...

  • Page 79: Installation And Wiring

    Installation and Wiring Installation and Wiring 5.1 Before Installation and Wiring 5.2 Installation Environment 5.3 UPS Transportation 5.4 Fixing the UPS 5.5 Wiring 5.6 External Battery Cabinet Connection Warnings 5.7 STS Module 5.8 Power Module (Optional)

  • Page 80: Before Installation And Wiring

    Before Installation and Wiring Please read this user manual thoroughly before installation, wiring and operation. Only authorized Delta engineers or service personnel can perform installation, wiring, panel & cover removal, maintenance and operation. If you want to execute any action mentioned above by yourself, the action must be under the supervision of authorized Delta engineers or service personnel.
  • Page 81 Installation and Wiring DPH Series UPS 100kVA/ 150kVA/ 200kVA/ 250kVA/ 300kVA/ Capacity 100kW 150kW 200kW 250kW 300kW 383kg 419kg 455kg 491kg 527kg Weight Weight 580.3kg/m 638.4kg/m 689.4kg/m 743.9kg/m 798.5kg/m Loading The UPS is of top and bottom wiring. Please leave adequate space for wiring, mainte- nance, and ventilation as follows: 1.

  • Page 82: Ups Transportation

    Before moving the UPS, please turn the four leveling feet counterclockwise carefully move the UPS from its pallet to ground. Please pay attention to the movement of the casters to avoid accidents. Caster Leveling Foot (Figure 5-2: UPS Leveling Foot and Caster) Modulon DPH Series...

  • Page 83: Fixing The Ups

    Installation and Wiring WARNING: 1. The UPS is fixed on the pallet with two balance supports and six M10 screws. When taking apart the two balance supports from the UPS, pay attention to the movement of the casters to avoid accidents. 2.
  • Page 84 & Nut × 3 (Figure 5-4: Balance Support Installation_ Rear of the UPS) NOTE: Please contact Delta service personnel for the expansion screws and nuts. The two balance supports and the six M10 screws are already provided with the UPS.

  • Page 85: Wiring

    1. Table 5-2 is based on (a) default input/ output voltage: 220V, (b) default battery Q’ty: 40 PCS, and (c) default charge current for each power module: 5A. 2. For other conditions different from Table 5-2, please contact Delta service personnel for relevant values.
  • Page 86 × 1 PC × 1 PC × 2 PCS × 2 PCS × 2 PCS Battery Maximum cable 500kcmil (240mm ) × 3 PCS size (+/ -/ N) Cable lug width 50mm Screw size Tightening Torque M10=250±10kgf·cm Modulon DPH Series...
  • Page 87 Installation and Wiring DPH Series 100-300kVA 100kVA/ 150kVA/ 200kVA/ 250kVA/ 300kVA/ Capacity 100kW 150kW 200kW 250kW 300kW Input Breaker (Q1) 200A 300A 400A 500A 630A Bypass Breaker (Q2) 200A 300A 400A 500A 630A Manual Bypass 200A 300A 400A 500A 630A Breaker (Q3) Output Breaker (Q4) 200A...
  • Page 88 UPS is powered on. WARNING: Only authorized Delta engineers or service personnel can modify the single input/ dual input setup. The UPS default setting is single input. If you want to modify it into dual input, please follow the steps below.
  • Page 89 Installation and Wiring (Rear View after Rear Panel Removal) AC Input BAT TER Y INP UT INP UT AC Input or Bypass Input INPUT INPUT BY PA SS INP UT BYPA SS BYPA SS INPUT INPUT AC Input or Bypass Input (Figure 5-6: Wiring Terminals_ AC Input &...
  • Page 90 For dual input and bottom wiring application, follow Figure 5-10 to install the removed four copper bars (on which the small copper bars have been mounted according to ) in the designated areas. Please secure the eight nuts tightly. Modulon DPH Series 5-12...

  • Page 91: Single Unit Wiring

    5.5.3 Single Unit Wiring WARNING: 1. Only authorized Delta engineers or service personnel can perform installation, wiring, panel & cover removal, maintenance and operation. If you want to execute any action mentioned above by yourself, the action must be under the supervision of authorized Delta engineers or service personnel.
  • Page 92 B A T T E R IN P U T BAT TER Y INP UT UP S OU TPU UPS Output UP S O UT PU INPU L1 L2 (Figure 5-12: Wiring Terminals_ Battery Input & UPS Output) Modulon DPH Series 5-14...
  • Page 93 Installation and Wiring (Rear View after Rear Panel Removal) Grounding Terminals for Top Wiring ( & INPUT BYPA SS INPUT Grounding Terminals for Bottom Wiring ( & (Figure 5-13: Wiring Terminals_ Grounding) For top wiring, remove the three top covers (2 screws for each cover); for bottom wiring, remove the three bottom covers (2 nuts for each cover).
  • Page 94 Figure 5-16: Single Unit Single Input Top Wiring Diagram_ Step 2 Figure 5-17: Single Unit Single Input Bottom Wiring Diagram_ Step 1 Figure 5-18: Single Unit Single Input Bottom Wiring Diagram_ Step 2 5.6 External Battery Cabinet Connection Warning. Modulon DPH Series 5-16...
  • Page 95 Installation and Wiring Single Input_ Top Wiring_ Step 1 (Rear View after Rear Panel Removal) Connect to the Main AC Source For the External For the Battery Cabinet UPS’s and Critical Protective Loads’ grounding Earthing BAT TER Y INP UT IN P U T INPUT INPUT...
  • Page 96 U PS O U TP U UP S OU TPU INPU Connect to the L1 L2 L3 External Battery Cabinet Connect to the Critical Loads (Figure 5-18: Single Unit Single Input Bottom Wiring Diagram_ Step 2) Modulon DPH Series 5-18...
  • Page 97 Installation and Wiring NOTE: For single input, the UPS will not work normally if the main AC power’s neutral terminal. Follow Figure 5-19 to ground the UPS, external battery cabinet(s) and connected critical loads. (At Maximum Eight) External External External External Load Load...
  • Page 98 BAT TER Y B A T T E R INP UT IN P U T UP S OU TPU INPU U PS O U TP U (Figure 5-21: Single Unit Dual Input Top Wiring Diagram_ Step 2) Modulon DPH Series 5-20...
  • Page 99 Installation and Wiring Dual Input_ Bottom Wiring_ Step 1 (Rear View after Rear Panel Removal) IN P U T B YP A SS IN PU T INPUT INPUT BYPA SS BYPA SS INPUT INPUT Connect to the Connect Bypass Source Main AC Source For the External For the...

  • Page 100: Parallel Unit Wiring

    5.5.4 Parallel Unit Wiring WARNING: 1. Only authorized Delta engineers or service personnel can perform installation, wiring, panel & cover removal, maintenance and operation. If you want to execute any action mentioned above by yourself, the action must be under the supervision of authorized Delta engineers or service personnel.
  • Page 101 Installation and Wiring Table 5-3: Wiring Terminals & Wiring Information Figure 5-15: Single Unit Single Input Top Wiring Diagram_ Step 1 Figure 5-16: Single Unit Single Input Top Wiring Diagram_ Step 2 Figure 5-17: Single Unit Single Input Bottom Wiring Diagram_ Step 1 Figure 5-18: Single Unit Single Input Bottom Wiring Diagram_ Step 2 Figure 5-24: Parallel Units Single Input Wiring Diagram 5.6 External Battery Cabinet Connection Warning...
  • Page 102 Figure 5-22: Single Unit Dual Input Bottom Wiring Diagram_ Step 1 Figure 5-23: Single Unit Dual Input Bottom Wiring Diagram_ Step 2 Figure 5-26: Parallel Units Dual Input Wiring Diagram 5.6 External Battery Cabinet Connection Warnings Modulon DPH Series 5-24...
  • Page 103 Installation and Wiring AC Input UPS Output Terminals Terminals Daisy Chain Method Bypass Input Parallel Port Terminals 3Ø4W Parallel Port Main AC Source UPS 1 AC Input UPS Output Terminals Terminals 3Ø4W Bypass Input 3Ø4W Bypass Source Terminals Loads Parallel Port Parallel Port UPS 2 AC Input...

  • Page 104: External Battery Cabinet Connection Warnings

    1. The information stated in 5.6 External Battery Cabinet Connection Warnings is only applicable to the sealed lead-acid batteries. 2. No matter sealed lead-acid batteries or lithium-ion batteries, please contact Delta You should connect the UPS with at least one external battery cabinet to ensure that the connected critical loads are protected when a power failure occurs.
  • Page 105 Installation and Wiring NOTE: 1. You can adjust the charge current from 6 A to the maximum. Each adjustment level is 1 A. 2. If you need to modify the default charge current setting and default low battery shutdown setting, please contact your local dealer or service personnel. 3.
  • Page 106 2. The above-mentioned DC circuit breaker, DC isolated switch and DC fuse are optional. If you want to buy any of them, please contact Delta service personnel. 3. If you need to parallel multiple units of external battery cabinets, please contact Delta service personnel for relevant information.
  • Page 107 Please note that only authorized Delta engineers or service personnel can perform wir- ing or you can perform wiring only under the supervision of authorized Delta engineers or service personnel. To connect the external battery cabinet(s) to the UPS, please refer to: Table 5-3: Wiring Terminals &...
  • Page 108 Table 5-4. These maximum values are suggested for general applications only. For actual maximum values, the maximum short-circuit capacity of the on-site batteries must be taken into consideration. Please contact Delta customer service for relevant information.
  • Page 109 Installation and Wiring Option 2: Installation of a 3-pole DC circuit breaker or DC isolated switch (per pole voltage External Battery Cabinet 3-Pole DC Circuit Breaker DC Fuse or DC Isolated Switch (Figure 5-29: Installation of a 3-Pole DC Circuit Breaker or DC Isolated Switch Connected in Series with a DC Fuse) External Battery...
  • Page 110 UPS system will sound an alarm. Please see the table below. External Battery Cabinet Status Alarm Battery Abnormal - Reversed Sounds 50ms every second. Battery Ground Fault Sounds 50ms every second. Battery Over Temperature Sounds 50ms every second. Battery Under Temperature Sounds 50ms every second. Modulon DPH Series 5-32...

  • Page 111: Sts Module

    Battery Life Time Expired Sounds 50ms every 3 seconds STS Module The hot swappable STS module has been installed inside the UPS in the Delta factory before shipment. Please see Figure 5-32 for its location. (UPS Front View with Door Open) DISPLAY EXT.

  • Page 112: Sts Module Installation

    (Figure 5-33: STS Module) 5.7.1 STS Module Installation The hot swappable STS module has been installed inside the UPS in the Delta factory before shipment. If the STS module is removed for some reasons and you want to re-install it, please follow the steps below: NOTE: 1.
  • Page 113 Installation and Wiring Insert the STS module into the unoccupied STS module slot until it snaps into place. At least two people are required for handling. (UPS Front View with Door Open) DISPLAY EXT. BATT TEMP. EXT.SWITCH STATUS O/P DRY BT1 BT2 CONTACT I/P DRY...

  • Page 114: Sts Module Removal

    Turn the STS module’s switch to the lower position ( ) and wait until the STS (Figure 5-38: Turn the STS Module’s Switch to the Lower Position) Unscrew the four screws shown in Figure 5-39. (Figure 5-39: Remove the Four Screws) Modulon DPH Series 5-36...
  • Page 115 Installation and Wiring Pull out the STS module from the slot (two people are required) (see Figure 5-40). When the STS module cannot be pulled out any more, press the lock (see Figure 5-41) on the left side of the STS module in order to continuously pull out the module from the UPS cabinet.

  • Page 116: Sts Module's Led Indicator

    ON (yellow) ECO mode, or energy recycle mode. Flashing (yellow)_ on for 0.3 The STS module is abnormal. NOTE: In bypass mode, if you turn the STS module’s switch to the lower position ( ), the Modulon DPH Series 5-38...

  • Page 117: Power Module (Optional)

    Installation and Wiring Power Module (Optional) The power module is optional (not included in the package of the UPS). It is hot swappable and each capacity is 50kVA/ 50kW. Please follow your UPS capacity to install the correct number of power modules. Please refer to the table below. 100kVA/ 150kVA/ 200kVA/...

  • Page 118: Power Module Installation

    Take out the two bracket ears, four M6 screws and eight M4 screws from the power module’s package. Use the provided eight M4 screws to fix the provided two bracket ears on the two sides of the power module. Please refer to Figure 5-45. Modulon DPH Series 5-40...
  • Page 119 Installation and Wiring (Figure 5-45: Install the Two Bracket Ears) Insert the power module into the unoccupied power module slot until it snaps into place. Two people are required. NOTE: To consider the center of gravity, please install the power modules from the top layer of the power module slot to the bottom layer of the power module slot in sequence.

  • Page 120: Power Module Removal

    2. Only qualified service personnel can perform the following power module removal procedures. 3. The power module is heavy (> 36 kg). At least two people are required for handling. Modulon DPH Series 5-42...
  • Page 121 Installation and Wiring Turn the power module’s switch to the lower position ( ). After that, the power module will start discharging. After discharging, the power module’s LED indicator will (Figure 5-49: Turn the Power Module’s Switch to the Lower Position) Use a screwdriver to remove the four screws from the power module shown in Figure 5-50.
  • Page 122 AKE R OU TPU T BRE AKE BYP ASS BRE AKE MA NU AL BYP ASS BRE AKE (Figure 5-51: Remove the Power Module) Press the Lock (Figure 5-52: Press the Lock of the Power Module) Modulon DPH Series 5-44...

  • Page 123: Power Module's Led Indicator

    Installation and Wiring 5.8.3 Power Module’s LED Indicator The power module’s LED indicator shows its operation status. Please refer to the following table. LED Indicator (Figure 5-53: Power Module’s LED Indicator) LED Indicator Description The power module is OFF. 1. The power module is running in online mode or in battery mode.

  • Page 125: Ups Operation

    UPS Operation UPS Operation 6.1 Pre Start-up & Pre Turn- and Parallel Units 6.2 Start-up Procedures...

  • Page 126: Parallel Units

    For relevant information, please refer to 7.10.7 General Setting. Single Unit Pre Start-up Warnings for Single Unit 1. Make sure that all the breakers, including every external battery cabinet’s breaker (Q5), are turned to the OFF position. is < 3V. Modulon DPH Series...
  • Page 127 UPS Operation 3. Check if the wiring is correct. Ensure that the AC power’s voltage, frequency, phase sequence and battery type meet the UPS’s requirements. 4. Check if all power modules are properly installed and every power module’s switch is in the upper position ( ).

  • Page 128: Start-Up Procedures

    LED indicator will illuminate green and the backup communication card’s LED indicator will illuminate yellow. For the locations of the parallel communication cards, auxiliary power cards, power modules and their LED indicators, please refer to Figure 6-1. Modulon DPH Series...
  • Page 129 UPS Operation Backup Parallel Communication Backup Parallel Auxiliary Auxiliary Power Card’s LED Indicator Communication Card Power Card Card’s LED Indicator DISPLAY BATT. START EXT. BATT EXT.SWITCH O/P DRY I/P DRY TEMP. STATUS CONTACT CONTACT BT1 BT2 PARALLEL REPO BATT. NC NO START BT3 BT4 PARALLEL...
  • Page 130 EVENT LOG Bypass Power Flow User ON/ OFF POWER FLOW Button Maintenance Power Flow Bypass Bypass Load Summary 30 % Mains System Status 90 % 5 mins (Figure 6-3: Main Screen_ User Login & ON/ OFF Button Location) Modulon DPH Series...
  • Page 131 UPS Operation Tap the ON/ OFF Button ( ) and the following screen will pop up to ask if you want to power on the UPS’s inverter. Please select 'YES'. 10:15 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN EVENT LOG Standby Power Flow User...

  • Page 132: Battery Mode Start-Up Procedures

    For the locations of the parallel communication cards, auxiliary power cards, power modules and their LED indicators, please refer to Figure 6-1. The LCD initial screen (see Figure 6-6) will appear within 40 seconds after each auxiliary power card’s LED indicator illuminates green. (Figure 6-6: LCD Initial Screen) Modulon DPH Series...
  • Page 133 UPS Operation After 20 seconds of LCD initialization, the LCD will enter the Main Screen shown in Figure 6-7 and the tri-color LED indicator will illuminate yellow. For the location of the tri-color LED indicator, please refer to Figure 2-11. User Login 10:15 May 25,2018...

  • Page 134: Bypass Mode Start-Up Procedures

    LED indicator will illuminate green and the backup communication card’s LED indicator will illuminate yellow. For the locations of the parallel communication cards, auxiliary power cards, power modules and their LED indicators, please refer to Figure 6-1. Modulon DPH Series 6-10...
  • Page 135 UPS Operation The LCD initial screen (see Figure 6-10) will appear within 40 seconds after the Input Breaker (Q1) and Bypass Breaker (Q2) are turned on. (Figure 6-10: LCD Initial Screen) After 20 seconds of LCD initialization, the LCD will enter the Main Screen. For the Main Screen information, please refer to 7.6 Main Screen.
  • Page 136 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN EVENT LOG Bypass Power Flow User POWER FLOW Maintenance Power Flow Bypass Bypass Load Summary 30 % Mains System Status 90 % 5 mins (Figure 6-13: Bypass Mode Screen) Modulon DPH Series 6-12...

  • Page 137: Manual Bypass Mode Start-Up Procedures

    UPS Operation 6.2.4 Manual Bypass Mode Start-up Procedures WARNING: 1. For parallel units, ensure that every operation procedure mentioned below is synchronized to all parallel UPSs. parallel ones, please contact service personnel. 3. Please note that you can turn on the Manual Bypass Breaker (Q3) only when the UPS needs maintenance.
  • Page 138 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN WARNING Standby Power Flow User POWER FLOW Maintenance Power Flow Bypass Bypass Load Summary Mains System Status 90 % 5 mins (Figure 6-16: On-Line Mode to Manual Bypass Mode Screen) Modulon DPH Series 6-14...
  • Page 139 UPS Operation When the UPS performs DC BUS discharging, each power module’s LED indicator About three minutes later, the UPS will shut down, and the LCD and the tri-color Switch OFF every external battery cabinet’s breaker (Q5). From Manual Bypass Mode to Online Mode WARNING: 1.
  • Page 140 Power Flow User ON/ OFF POWER FLOW Button Maintenance Power Flow Bypass Bypass Load Summary 30 % Mains System Status 90 % 5 mins (Figure 6-18: Bypass Mode Screen_ User Login & ON/ OFF Button Location) Modulon DPH Series 6-16...
  • Page 141 UPS Operation Switch OFF the Manual Bypass Breaker (Q3). Tap the ON/ OFF Button ( ) and the following screen will pop up to ask if you want to power on the UPS’s inverter. Please select 'YES'. 10:15 May 25,2018 UPS-1.1 MEASUREMENT SETUP...

  • Page 142: Eco Mode Start-Up Procedures

    For the locations of the parallel communication cards, auxiliary power cards, power modules and their LED indicators, please refer to Figure 6-1. The LCD initial screen (see Figure 6-21) will appear within 40 seconds after the Input Breaker (Q1) and Bypass Breaker (Q2) are turned on. Modulon DPH Series 6-18...
  • Page 143 UPS Operation (Figure 6-21: LCD Initial Screen) After 20 seconds of LCD initialization, the LCD will enter the Main Screen. For the Main Screen information, please refer to 7.6 Main Screen. Now, each power module keeps running and its LED indicator remains green. After each power module finishes establishing DC BUS voltage, the charger will start to charge the batteries.
  • Page 144 Conversion (Figure 6-24: Select ECO Mode) After manually selecting ECO mode via the LCD, tap the icon ( ) located in the UPS-1.1 upper left corner of the screen to go back to the Main Screen. Modulon DPH Series 6-20...
  • Page 145 UPS Operation Tap the ON/ OFF Button ( ) and the following screen will pop up to ask if you want to power on the UPS’s inverter. Please select 'YES'. 10:15 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN EVENT LOG Bypass Power Flow Administrator...

  • Page 146: Frequency Conversion Mode Start-Up Procedures

    LED indicators, please refer to Figure 6-1. The LCD initial screen (see Figure 6-27) will appear within 40 seconds after the Input Breaker (Q1) and Bypass Breaker (Q2) are turned on. (Figure 6-27: LCD Initial Screen) Modulon DPH Series 6-22...
  • Page 147 UPS Operation After 20 seconds of LCD initialization, the LCD will enter the Main Screen. For the Main Screen information, please refer to 7.6 Main Screen. Now, each power module keeps running and its LED indicator remains green. After each power module finishes establishing DC BUS voltage, the charger will start to charge the batteries.
  • Page 148 Frequency Conversion mode and the output frequency will be the same as setup value. Now, the tri-color LED indicator illuminates green and the following screen appears. For the tri-color LED indicator location, please refer to Figure 2-11. Modulon DPH Series 6-24...

  • Page 149: Green Mode Start-Up Procedures

    UPS Operation 10:15 May 25,2018 Frequency UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN EVENT LOG Conversion Power Flow Administrator POWER FLOW Maintenance Power Flow Bypass Bypass Load Summary 30 % Mains System Status 90 % 5 mins (Figure 6-32: Frequency Conversion Mode Screen) 6.2.7 Green Mode Start-up Procedures WARNING: 1.
  • Page 150 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN EVENT LOG Bypass Power Flow User POWER FLOW Maintenance Power Flow Bypass Bypass Load Summary 30 % Mains System Status 90 % 5 mins (Figure 6-34: Main Screen_ User Login) Modulon DPH Series 6-26...
  • Page 151 UPS Operation Please log in as an Administrator. For the Administrator password, please contact service personnel. After login, ensure that you are in the Administrator login status (see Figure 6-35). Administrator Login 10:15 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN EVENT LOG Bypass Power Flow...
  • Page 152 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN EVENT LOG Green Power Flow Administrator POWER FLOW Maintenance Power Flow Bypass Bypass Load Summary 30 % Mains System Status 90 % 5 mins (Figure 6-38: Green Mode Screen) Modulon DPH Series 6-28...

  • Page 153: Energy Recycle Mode Start-Up Procedures

    UPS Operation 6.2.8 Energy Recycle Mode Start-up Procedures WARNING: Energy Recycle mode is only applicable to single input and single unit application. Ensure that the Manual Bypass Breaker (Q3), Output Breaker (Q4) and every external battery cabinet’s breaker (Q5) are in the OFF position. Switch ON the Input Breaker (Q1) and Bypass Breaker (Q2).
  • Page 154 MAINTENANCE LOG IN WARNING Bypass Power Flow Administrator ON/ OFF POWER FLOW Button Maintenance Power Flow Bypass Bypass Load Summary Mains System Status 0 mins (Figure 6-41: Main Screen_ Administrator Login & ON/ OFF Button Location) Modulon DPH Series 6-30...
  • Page 155 UPS Operation Go to SETUP Mode Setting Energy Recycle. 10:15 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN WARNING Bypass Mode Setting Administrator MODE SETTING Select to change system mode Energy Frequency On-Line Green Recycle Conversion (Figure 6-42: Select Energy Recycle Mode) After manually selecting Energy Recycle mode via the LCD, tap the icon ( UPS-1.1 located in the upper left corner of the screen to go back to the Main Screen.
  • Page 156 EVENT LOG On-Line Power Flow User ON/ OFF POWER FLOW Button Maintenance Power Flow Bypass Bypass Load Summary 30 % Mains System Status 90 % 5 mins (Figure 6-45: On-Line Mode Screen & ON/ OFF Button Location) Modulon DPH Series 6-32...
  • Page 157 UPS Operation Tap the ON/ OFF Button ( ) and the following screen will pop up to ask if you want YES'. 10:15 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN EVENT LOG On-Line Power Flow User POWER OFF ? Transfer to Bypass without Protection! (Figure 6-46: Power off Reminder Screen) After selection of 'YES', the UPS will shut down the inverter, terminate each power...
  • Page 158 Tap the ON/ OFF Button ( ) and the following screen will pop up to ask if you want YES'. WARNING: Please note that, once you select 'YES Please make sure that the critical loads connected to the UPS have already Modulon DPH Series 6-34...
  • Page 159 UPS Operation 10:15 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN WARNING Battery Power Flow User POWER OFF ? Transfer to Bypass without Protection! (Figure 6-49: Power off Reminder Screen) After selection of 'YES', the UPS will shut down the inverter, terminate each power module’s output and transfer to run in Standby mode.
  • Page 160 Switch OFF the Input Breaker (Q1), Bypass Breaker (Q2) and Output Breaker (Q4). After that, the UPS will run in Standby mode. About 3 minutes later, the UPS will shut down, and the LCD and the tri-color LED Switch OFF every external battery cabinet’s breaker (Q5). Modulon DPH Series 6-36...
  • Page 161 UPS Operation WARNING: 1. For parallel units, ensure that every operation procedure mentioned below is synchronized to all parallel UPSs. parallel ones, please contact service personnel. In Manual Bypass mode, the LCD and the tri-color LED indicator are both OFF. To com- pletely shut down the UPS, switch OFF the Manual Bypass Breaker (Q3).

  • Page 162: System Status

    May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN EVENT LOG Bypass Power Flow User POWER FLOW Maintenance Power Flow Bypass Bypass Load Summary 30 % Mains System Status 90 % 5 mins (Figure 6-54: Bypass Mode Screen) Modulon DPH Series 6-38...

  • Page 163: Mins

    UPS Operation Please log in as an Administrator. For the Administrator password, please contact service personnel. After login, ensure that you are in the Administrator login status (see Figure 6-55). Administrator Login 10:15 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN EVENT LOG Bypass Power Flow...

  • Page 164: About 3 Minutes Later, The Ups Will Shut Down, And The Lcd And The Tri-Color Led

    Tap the ON/ OFF Button ( ) and the following screen will pop up to ask if you want YES'. WARNING: Please note that, once you select 'YES Please make sure that the critical loads connected to the UPS have already Modulon DPH Series 6-40...

  • Page 165: Setup Maintenance Log In User

    UPS Operation 10:15 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN EVENT LOG Standy Power Flow User POWER OFF ? Transfer to Bypass without Protection! (Figure 6-58: Power off Reminder Screen) After selection of 'YES', the UPS will shut down the inverter and terminate each power module’s output.
  • Page 166 (Figure 6-61: Select Online Mode) Switch OFF the Input Breaker (Q1) and Bypass Breaker (Q2). About 3 minutes later, the UPS will shut down, and the LCD and the tri-color LED Switch OFF every external battery cabinet’s breaker (Q5). Modulon DPH Series 6-42...
  • Page 167 UPS Operation WARNING: 1. For parallel units, ensure that every operation procedure mentioned below is synchronized to all parallel UPSs. parallel ones, please contact service personnel. In Green mode, the LCD shows the following screen (Figure 6-62) and the tri-color LED indicator illuminates green.

  • Page 168: May 25,2018

    MEASUREMENT SETUP MAINTENANCE LOG IN EVENT LOG Bypass Power Flow Administrator POWER FLOW Maintenance Power Flow Bypass Bypass Load Summary 30 % Mains System Status 90 % 5 mins (Figure 6-65: Bypass Mode Screen_ Administrator Login) Modulon DPH Series 6-44...

  • Page 169: Event Log Eco

    UPS Operation Go to SETUP Mode Setting On-Line. 10:15 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN EVENT LOG Bypass Mode Setting Administrator MODE SETTING Select to change system mode Energy Frequency On-Line Green Recycle Conversion (Figure 6-66: Select On-Line Mode) Switch OFF the Input Breaker (Q1), Bypass Breaker (Q2) and Output Breaker (Q4).
  • Page 170 ) and the following screen will pop up to ask if you want YES'. 10:15 May 25,2018 Energy UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN WARNING Recycle Power Flow User POWER OFF ? Transfer to Bypass without Protection! (Figure 6-68: Power off Reminder Screen) Modulon DPH Series 6-46...
  • Page 171 UPS Operation After selection of 'YES', the UPS will stop self-aging test and transfer to run in Bypass mode. At this moment, the tri-color LED indicator illuminates yellow and the following screen appears (Figure 6-69). For the tri-color LED indicator location, please refer to Figure 2-11.
  • Page 172 LOG IN EVENT LOG Bypass Mode Setting Administrator MODE SETTING Select to change system mode Energy Frequency On-Line Green Recycle Conversion (Figure 6-71: Select Online Mode) Switch OFF the Input Breaker (Q1) and Bypass Breaker (Q2). Modulon DPH Series 6-48...

  • Page 173: Lcd Display & Settings

    LCD Display & Settings LCD Display & Settings 7.1 LCD Display Hierarchy 7.2 How to Turn on the LCD 7.3 ON/ OFF Button 7.4 Introduction of Touch Panel and Function Keys 7.5 Password Entry 7.6 Main Screen 7.7 Main Menu 7.8 Power Flow &...

  • Page 174: Lcd Display Hierarchy

    (Level 2) Control Buzzer/ Reset Module / Reset System Force Equalized Charge Force Bypass to Inverter (Level 2) EMS Setting SENSOR 　Temperature/ Humidity INPUT CONTACT: 1 ~ 4 　NO/ NC/ Event Type (Figure 7-1: LCD Display Hierarchy) Modulon DPH Series...

  • Page 175: How To Turn On The Lcd

    7.5 Password Entry. 2. * means that the item will only appear on the LCD if you use the Delta lithium-ion batteries with the optional multifunctional communication card (MFC) being installed in the smart slot shown in Figure 4-13. Please contact Delta customer service if you need more information.
  • Page 176 About 20 seconds after the LCD initial screen (see Figure 7-3) is on, the Main Screen will appear (see Figure 7-4). After you see the Main Screen, you can operate the LCD. Please note that the Main Screen appears in the User login status as shown in Modulon DPH Series...

  • Page 177: On/ Off Button

    LCD Display & Settings User Login 10:15 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN EVENT LOG Bypass Power Flow User POWER FLOW Maintenance Power Flow Bypass Bypass Load Summary 30 % Mains System Status 90 % 5 mins (Figure 7-4: Main Screen_ User Login) ON/ OFF Button NOTE: 1.
  • Page 178 After selection of 'Yes', the ON/ OFF Button will turn green ( ), indicating that the power-on process is completed. 10:15 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN EVENT LOG Bypass Power Flow Administrator POWER ON ? (Figure 7-6: Power On Reminder Window) Modulon DPH Series...

  • Page 179: Introduction Of Touch Panel And Function Keys

    LCD Display & Settings When the ON/ OFF Button is green ( ), it indicates that the UPS’s inverter is in the ON status. Tap the button once and a reminder window shown below will pop up to ask POWER OFF'. After selection of 'Yes', the ON/ OFF Button will turn gray ( ), indicating that the 10:15...
  • Page 180 For more information, please refer to 7.5 LOG IN User Password Entry. Indicates login by Administrator. Tap the icon to change the login permission. For more information, please refer to 7.5 LOG IN Administrator Password Entry. Modulon DPH Series...
  • Page 181 LCD Display & Settings Button Text/ Symbol Function Digital Display No. Icon/ Text Description (Yes or Display (Yes or (Yes or No) 1. Event log shortcut icon ( EVENT LOG Tap the icon to check all the event logs. EVENT LOG 2.
  • Page 182 7.3 ON/ OFF Button. 1. Bypass input status (Green: Normal; Red: Abnormal or OFF). Bypass 2. Bypass input screen shortcut icon. 1. Main input status (Green: Normal; Red: Abnormal or OFF). Mains 2. Main input screen shortcut icon. Modulon DPH Series 7-10...
  • Page 183 LCD Display & Settings Button Text/ Symbol Function Digital Display No. Icon/ Text Description (Yes or Display (Yes or (Yes or No) 1. Battery status (Green: Normal; Flashing Green & Gray: Battery Mode; Flashing Red & Gray: Battery Not Connected). 90 % 5 mins 2.
  • Page 184 Sleep' mode, you will still be logged out after the screen is idle for 5 minutes. 4. The default language is English. To change the displayed language of the screen, please go to General Setting User Language. The default SETUP Modulon DPH Series 7-12...

  • Page 185: Password Entry

    LCD Display & Settings Password Entry 1. Password entry is only required for login as an Administrator. User login does not require a password. 2. Tap the Administrator password (please contact service personnel for LOG IN User appears, indicating the Administrator login is successful.
  • Page 186 90 % 5 mins The screen above indicates that the UPS is in On-Line mode, and power supply of the loads comes from the inverter. Please refer to 7.10.2 Mode Setting and 6.2.1 Online Mode Start-up Procedures. Modulon DPH Series 7-14...
  • Page 187 LCD Display & Settings 10:15 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN EVENT LOG Green Power Flow Administrator POWER FLOW Maintenance Power Flow Bypass Bypass Load Summary 30 % Mains System Status 90 % 5 mins The screen above indicates that the UPS is in Green mode, and power supply of the loads comes from the inverter.
  • Page 188 The screen above indicates that the UPS is in Frequency Conversion mode and the bypass output is restricted. For Frequency Conversion mode settings, please refer to 7.10.2 Mode Setting and 6.2.6 Frequency Conversion Mode Start-up Procedures. Modulon DPH Series 7-16...

  • Page 189: Main Menu

    LCD Display & Settings 10:15 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN WARNING Bypass Power Flow Administrator POWER FLOW Maintenance Power Flow Bypass Bypass Load Summary 30 % Mains System Status 90 % 5 mins After the Manual Bypass Breaker (Q3) is turned on, the UPS will be switched to Manual Bypass mode and the screen above will appear.
  • Page 190 In the Maintenance Menu, it includes the following items. 1. Warning 2. Historical Event MAINTENANCE 3. Statistics 4. Test 5. Clear 6. Advanced Diagnosis 7. Version & S/N For more information, please refer to 7.11 System Maintenance. Modulon DPH Series 7-18...

  • Page 191: Power Flow, Summary, System Status & Ems

    LCD Display & Settings NOTE: inspection items and setup items. Please refer to 7.1 LCD Display Hierarchy. Power Flow, Summary, System Status & EMS There are four shortcut icons for you to check the Power Flow, Summary, System Status and EMS 10:15 May 25,2018 UPS-1.1...
  • Page 192 MEASUREMENT SETUP MAINTENANCE LOG IN EVENT LOG On-Line System Status Administrator SYSTEM STATUS Power Flow Summary System Status STS Module Status System Control Card Status Power Module Status Auxiliary Power Card Status Parallel Communication Card Status Modulon DPH Series 7-20...

  • Page 193: Check System Readings

    LCD Display & Settings 4. Tap the icon to check the integrated status of each optional EMS 1000 (EnviroProbe) device connected to the UPS (Green: Normal; Yellow: Warning; Red: Alarm; Gray: temperature (°C) status, humidity (%) status, and the status of input contacts DI1~DI4. For more EMS information, please refer to 7.9.7 EMS and 7.10.10 EMS Setting.

  • Page 194: Check Kilowatt-Hour

    Current(A) Current(A) kWH/d By Hour kWH/d 2018-08-16 2018-08-16 2018-08-16 2018-08-16 00:00 06:00 12:00 18:00 Search Tick 2018-08-23 13:18 Year Week Month Since Reset Item Description kWH Statistics Sheet Tabs (Day/ Week/ Month/ Year/ Since Reset) Modulon DPH Series 7-22...
  • Page 195 LCD Display & Settings Item Description 1. Shows the UPS ’s main input kWH statistics, with time on X-axis and kWH on Y-axis. Column Chart 2. Tap one of the columns on the chart and the corresponding piece of data will appear below the chart. Please refer to Page 7-23~7-30 for relevant information.
  • Page 196 10:00~11:00), the statistics of the column shown on the chart is from 10:00~10:30, and will keep updating. B. Tap the kWH statistics sheet tab ( ), and you can view the weekly kWH Week statistics of the UPS main input by hour Modulon DPH Series 7-24...
  • Page 197 LCD Display & Settings 10:15 10:15 May 25,2018 May 25,2018 UPS-1.1 UPS-1.1 MEASUREMENT MEASUREMENT SETUP SETUP MAINTENANCE MAINTENANCE LOG IN LOG IN WARNING WARNING On-Line On-Line Main Input Main Input Administrator Administrator CONSUM PT IO N Last Reset Date : 2018-07-06 MAIN INPUT MAIN INPUT Present...
  • Page 198 Tap the icon ( ) on either side of the column chart to view the statistics of the previous/ next month. Tap one of the columns on the chart, and the corresponding piece of data will Modulon DPH Series 7-26...
  • Page 199 LCD Display & Settings 10:15 10:15 May 25,2018 May 25,2018 UPS-1.1 UPS-1.1 MEASUREMENT MEASUREMENT SETUP SETUP MAINTENANCE MAINTENANCE LOG IN LOG IN WARNING WARNING On-Line On-Line Main Input Main Input Administrator Administrator CO NS UM PTI ON Last Reset Date : 2018-07-06 MAIN INPUT MAIN INPUT Present...
  • Page 200 For example, if you view the kWH statistics on 2018-08-23 at 06:00 (still within the minimum unit of the week 2018-08-19 Sun.~2018-08-25 Sat.), the statistics of the column shown on the chart is from 2018-08-19 Sun. 00:00 ~ 2018-08-23 Thur. 06:00, and will keep updating. Modulon DPH Series 7-28...
  • Page 201 LCD Display & Settings E. Tap the kWH statistics sheet tab ( ), and you can view the kWH statistics Since Reset of the UPS main input power since Last Reset Date (the last date when 'Clear Kilowatt Hour' was executed) by month 10:15 10:15 May 25,2018...
  • Page 202 If you select ( ), you can view the column chart of the week (2018-08-19 Sun. ~ Week 2018-08-25 Sat.). If you select ( ), you can view the column chart of the month (2018-08-01 ~ Month 2018-08-31). Modulon DPH Series 7-30...
  • Page 203 LCD Display & Settings If you select ( ), you can view the column chart of the year (2018-01-01~2018-12- Year 31). If you select ( ), you can view the column chart of the 10 years since Last Since Reset Reset Date.
  • Page 204 Tap the download icon ( ) to start downloading, and the following screen will appear. Loading data... Please wait... After the download has been completed, you will see the following screen. Download complete! Modulon DPH Series 7-32...

  • Page 205: Bypass Input

    LCD Display & Settings 7.9.2 Bypass Input Path: MEASUREMENT After entering the BYPASS INPUT readings of Phase Voltage, Line Voltage and Frequency. 10:15 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN EVENT LOG On-Line Bypass Input Administrator BYPASS INPUT Phase Voltage (V) 220.0 220.0 220.0...

  • Page 206: Power Module Summary

    220.0 220.0 220.0 Apparent Power (KVA) 230.0 154.6 168.2 Line Voltage (V) 380.0 380.0 380.0 Active Power (KW) 6391.7 6444.7 118.4 Current (A) 227.0 227.0 227.0 Power Factor 0.00 0.00 0.70 Frequency (Hz) 50.0 Load (%) Modulon DPH Series 7-34...

  • Page 207: Battery Status

    LCD Display & Settings 7.9.6 Battery Status Path: MEASUREMENT After entering the BATTERY STATUS readings of Status, Voltage, Current, Remaining Capacity, Remaining Time, Estimated Recharging Time, Test Result, Battery Temperature (#1~#4), and each power module’s Charge Voltage* and Charge Current* NOTE: means that the Administrator password is needed.

  • Page 208: Ems

    NOTE: The screen ( PAGE use the Delta lithium-ion batteries with the optional multifunctional communication card (MFC) being installed in the smart slot shown in Figure 4-13. Please contact Delta customer service if you need more information. 10:15 May 25,2018 UPS-1.1...
  • Page 209 LCD Display & Settings 10:15 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN WARNING On-Line Administrator Normal Warning Alarm Title Temperature Humidity °C Security 1 qqqqq3 qqpo4 EMS0 25.4 °C Security 1 qqqqq3 qqpo4 EMS1 25.8 °C Security 1 qqqqq3 qqpo4 EMS3 25.9...
  • Page 210 1. If the status of the EMS 1000 (EnviroProbe) device (ID #) is OFF (gray) as shown in 10:15 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN EVENT LOG On-Line Administrator Normal Warning Alarm Title Temperature Humidity °C Off (gray) EMS0 Modulon DPH Series 7-38...
  • Page 211 LCD Display & Settings The reasons may be: (1) The status of the EMS 1000 (EnviroProbe) device (ID #) has been set as 'Enable' (please refer to 7.10.10 EMS Setting), but the device (ID #) is not connected to the UPS or the connection cable may be damaged.

  • Page 212: Connecting The Optional Ems 1000 (Enviroprobe)

    Voltage Range. If any value is out of range, the system will issue an alarm. These settings for assistance. NOTE: means that the Administrator password is needed. For password information, please refer to 7.5 Password Entry. Modulon DPH Series 7-40...

  • Page 213: Mode Setting

    LCD Display & Settings 10:15 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN EVENT LOG Bypass Bypass setting Administrator BYPASS SETTING Bypass Frequency Range Bypass Voltage(Max) Bypass Voltage(Min) ± ECO Voltage Range(±%) ± Item Description Bypass Frequency Range Set up the bypass output’s frequency range. Bypass Voltage (Max.) Set up the bypass output’s maximum voltage.

  • Page 214: Output Setting

    Frequency Conversion mode is only applicable to single UPS but not to parallel UPSs. 7.10.3 Output Setting Path: SETUP After entering the OUTPUT SETTING screen* (shown in the figure below), you can set Please contact Delta customer service for assistance. Modulon DPH Series 7-42...
  • Page 215 LCD Display & Settings NOTE: means that the Administrator password is needed. For password information, please refer to 7.5 Password Entry. 10:15 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN EVENT LOG Bypass Output Setting Administrator OUTPUT SETTING Voltage Voltage Compensation Frequency Slew Rate Hz/s...

  • Page 216: Battery & Charging Setting

    7.10.4 Battery & Charging Setting Path: SETUP In the BATTERY & CHARGING SETTING screen* Please contact Delta customer service for assistance. NOTE: means that the Administrator password is needed. For password information, please refer to 7.5 Password Entry. 10:15 May 25,2018 UPS-1.1...
  • Page 217 Set up the battery type as VRLA/ LiB (Dry Contact)* / LiB (Integration)* NOTE: 1. * If you use non-Delta lithium-ion batteries, please set up the battery type as 'LiB (Dry Battery Type Contact)'. For relevant settings, please refer to 4.1.6 Input Dry Contacts and 7.10.6 Dry Contact Setting.
  • Page 218 Item Description 2. * If you use the Delta lithium-ion batteries, please set up the battery type as 'LiB (Integration)'. The item 'LiB (Integration)' will only appear on the LCD if you use the Battery Type Delta lithium-ion batteries with the optional...

  • Page 219: Parallel Setting

    Set up the battery replacement date. 7.10.5 Parallel Setting Path: SETUP After entering the PARALLEL SETTING screen* Please contact Delta customer service for assistance. NOTE: means that the Administrator password is needed. For password information, please refer to 7.5 Password Entry. 10:15 May 25,2018 UPS-1.1...

  • Page 220: Dry Contact Setting

    In the DRY CONTACT SETTING screen* (shown in the figure below), the event, NO (normally open) or NC (normally closed) for each of the input and output dry contacts can Delta customer service for assistance. NOTE: means that the Administrator password is needed. For password information, please refer to 7.5 Password Entry.
  • Page 221 LCD Display & Settings 10:15 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN EVENT LOG Bypass Dry Contact Setting Administrator DRY CONTACT SETTING INPUT OUTPUT Event Type None Normally Open None Normally Open None Normally Open None Normally Open Normally Open None None Normally Open...

  • Page 222: General Setting

    2018-May-10 09 : 30 : 26 10:15 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN EVENT LOG Bypass General Setting Administrator DATE/ GENERAL SETTING DUST SCREEN USER TIME FILTER Screen Brightness Screen Sleep (after) 1 min Modulon DPH Series 7-50...
  • Page 223 LCD Display & Settings 10:15 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN EVENT LOG Bypass General Setting Administrator GENERAL SETTING DATE/ DUST SCREEN USER TIME FILTER Language Admin Password **** English MODBUS ID Baud Rate On/ Off Button Access Any User 19200 10:15...
  • Page 224 2. The screen ( you use the Delta lithium-ion batteries with the optional multifunctional communication (MFC) card being installed in the smart slot shown in Figure 4-13. Please contact Delta customer service if you need more information. Modulon DPH Series 7-52...

  • Page 225: Ip Setting

    SETUP After entering the IP SETTING screen* (shown in the figure below), you can set up the contact Delta customer service for assistance. NOTE: means that the Administrator password is needed. For password information, please refer to 7.5 Password Entry.

  • Page 226: Control

    Set up the search domain. Host Name Set up the host name. 7.10.9 Control Path: SETUP After entering the CONTROL screen (shown in the figure below), you can set up the contact Delta customer service for assistance. 10:15 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE...

  • Page 227: Ems Setting

    7.5 Password Entry. 7.10.10 EMS Setting Path: SETUP After entering the EMS SETTING screen* contact Delta customer service for assistance. NOTE: means that the Administrator password is needed. For password information, please refer to 7.5 Password Entry. 10:15 May 25,2018 UPS-1.1...
  • Page 228 The status Enable/ Disable determines whether or not Status the LCD shows the EMS information of the EMS 1000 (EnviroProbe) device (ID #). Set the temperature (°C) values for Alarm/ Warning/ Temperature Recovery. Humidity Set the Humidity (%) values for Alarm/ Warning/ Recovery. Modulon DPH Series 7-56...

  • Page 229: System Maintenance

    LCD Display & Settings Item Sub Item Description Input Contact 1 1. Set the input contact as Normally Open (NO)/ Normally Input Contact 2 Closed (NC). INPUT CONTACT 2. Set the title for the input contact, 16 characters at most. Input Contact 3 3.

  • Page 230: Historical Event

    10:26:36 2017-10-15 0128-01 Mains Input Freq Out Range 09:06:59 2017-10-15 5005-01 No Output 10:27:07 2017-10-15 480A-01 COM Card #2 Absent 10:26:52 2017-10-15 0100-01 Mains Input Volt Out Range 10:26:36 2017-10-15 3200-01 About Emergency PWR Off 09:16:45 Modulon DPH Series 7-58...

  • Page 231: Statistics

    LCD Display & Settings 10:15 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN WARNING On-Line Historical Event Administrator HISTORICAL EVENT DOWNLOAD Start Date Code Location 2017-10-15 480A-01 Battery Disconnedted 09:06:59 2017-10-15 1021-01 Mains Input Freq Out Range 08:22:45 2017-10-15 2501-01 Mains Input Volt Out Range 08:10:06 2017-10-15...

  • Page 232: Test

    7.5 Password Entry. 10:15 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN EVENT LOG On-Line Clear Administrator CLEAR Clear Statistics Clear Historical Event Clear Clear Clear Battery Test Result Clear Kilowatt Hour (kWh) Clear Clear Modulon DPH Series 7-60...

  • Page 233: Advanced Diagnosis

    LCD Display & Settings Item Description After you select 'Clear Clear Statistics records of the statistics will be cleared. Clear Historical After you select 'Clear' and confirm clearance of historical Event event logs, all historical event logs will be cleared. Clear Battery Test After you select 'Clear Result...

  • Page 234: Version & S

    Bypass Version & S/N Administrator VERSION & S/N MAIN System Power Module 1 EA017700017W0 Power Module 2 EA017700018W0 Touch Panel Power Module 3 EA017700019W0 Power Module 4 EA017700020W0 Power Module 5 EA017700021W0 Power Module 6 EA017700022W0 Modulon DPH Series 7-62...
  • Page 235 LCD Display & Settings 10:15 May 25,2018 UPS-1.1 MEASUREMENT SETUP MAINTENANCE LOG IN EVENT LOG Bypass Version & S/N Administrator VERSION & S/N MAIN FPGA Parallel Communication 0H0017AR00.03.03 4A0000AR00.01.02 Choose File Card #1 Parallel Communication 0H0017AR00.03.03 4A0000AR00.01.02 Card #2 System Control Card 0H0017AR00.05.02 4A0000AR00.00.00 UPGRADE...
  • Page 236 PM #_ MCU/ FPGA NOTE: The screen ( use the Delta lithium-ion batteries with the optional multifunctional communication card (MFC) being installed in the smart slot shown in Figure 4-13. Please contact Delta customer service if you need more information.

  • Page 237: Optional Accessories

    Optional Accessories Optional Accessories...
  • Page 238 NOTE: The number of the BMS that needs to be installed in the UPS depends on how many external battery cabinets are connected with the UPS. For the installation of the BMS, please contact Delta customer service. Modulon DPH Series...
  • Page 239 Optional Accessories Item Function If you use the Delta lithium-ion batteries, you must also purchase and install the multifunctional communication card (MFC) in the smart slot shown in Figure 4-13 in order to monitor the battery status via the UPS’s LCD. For relevant information, please refer to 7.9.6 Battery Multifunctional Status, 7.10.4 Battery Charging Setting, and 7.10.7 General Setting.

  • Page 241: Maintenance

    Maintenance Maintenance...
  • Page 242 UPS. If not, replace the fans. NOTE: Please ask your local dealer or customer service for more maintenance information. Do not perform maintenance if you are not trained for it. Modulon DPH Series...

  • Page 243: Troubleshooting

    Troubleshooting Troubleshooting 10-1...
  • Page 244 When you see the following alarm messages appear on the LCD, please follow the solutions shown below. If you see other alarm messages that are not listed in the table below, please contact Delta service personnel for assistance. Do not perform troubleshooting if you are not trained for it.
  • Page 245 Troubleshooting Alarm Possible Cause Solution Message 1. Please check if the bypass breaker is turned off or not. If yes, please turn it on. 2. Please check if the bypass AC 1. The bypass breaker is source’s frequency is abnormal Bypass Input turned off.
  • Page 246 Reversed service personnel for assistance. Check the batteries. If wrong battery Battery The battery wiring is wrong or wiring or battery abnormalities exist, Test Fail battery abnormalities exist. please contact service personnel for assistance. Modulon DPH Series 10-4...
  • Page 247 Troubleshooting Alarm Possible Cause Solution Message 1. Check if the battery wiring is normal or not. 2. Check if the input dry contact The battery grounding is Battery configuration is normal or not. wrong or the input dry contact Ground Fault 3.
  • Page 248 AC In Type assistance. Parallel Check if the output settings among the parallel UPS units are correct or the parallel UPS units’ output Incompatible - not, and contact service personnel for settings. Output Type assistance. Modulon DPH Series 10-6...
  • Page 249 Troubleshooting Alarm Possible Cause Solution Message 1. There are conflicts 1. Check if the battery settings among Parallel between the parallel UPS the parallel UPS units are correct or units’ battery settings. not, and contact service personnel Incompatible - 2. The input dry contact for assistance.
  • Page 250 1. Check if any foreign matter blocks the fans or not. If yes, remove the INV #n Over The fans of the power module foreign matter. Heat Warning #n are abnormal. 2. Contact service personnel for assistance. Modulon DPH Series 10-8...
  • Page 251 Troubleshooting Alarm Possible Cause Solution Message 1. Check if any foreign matter blocks the fans or not. If yes, remove the INV #n Over The fans of the power module foreign matter. Heat Shutdown #n are abnormal. 2. Contact service personnel for assistance.
  • Page 252 UPS in accordance with the normal start-up procedures On Manual The manual bypass breaker after the relevant abnormalities are Bypass is turned on. eliminated. 2. If the alarm message still exists, please contact service personnel for assistance. Modulon DPH Series 10-10...
  • Page 253 Troubleshooting Alarm Possible Cause Solution Message PM #n Charger The charger of the power Please contact service personnel for Volt Abnormal module #n is abnormal. assistance. PM #n Charger The charger of the power Please contact service personnel for Current Abnormal module #n is abnormal.
  • Page 254 1. Please refer to the user manual of The voltage of the lithium- Li-ion Battery the lithium-ion batteries. ion batteries is too high or the Over Volt Warning 2. Please contact service personnel for batteries are abnormal. assistance. Modulon DPH Series 10-12...
  • Page 255 Troubleshooting Alarm Possible Cause Solution Message 1. Please refer to the user manual of Li-ion Battery The voltage of the lithium- the lithium-ion batteries. Under Volt ion batteries is too low or the 2. Please contact service personnel for Warning batteries are abnormal.
  • Page 256 The loads are abnormal overload or short circuit. Over Current or the power modules are 104* 2. If the alarm message still exist after Shutdown - R damaged. the solution mentioned above has been executed, please contact service personnel. Modulon DPH Series 10-14...
  • Page 257 Troubleshooting Alarm Possible Cause Solution Message Parallel Unit Please contact service personnel for the parallel UPS units’ assistance. parameter settings. 1. Please check if the system control card is properly installed. System Control The system control card is 2. If the alarm message still exist after Card Removed removed or damaged.
  • Page 258 The inverter of the power Please contact service personnel for Fault Warning module #n is abnormal. assistance. The inverter of the power Please contact service personnel for Fault Shutdown module #n is abnormal. assistance. Modulon DPH Series 10-16...
  • Page 259 1. If the alarm still exists after the above possible causes are eliminated, please contact your dealer or customer service. 2. * If you use non-Delta lithium-ion batteries, the LCD will not show the alarm messages (No. 88~ No. 96) shown in the table above. If you have any questions, please contact customer service.
  • Page 261 Appendix 1 Technical A1-1...
  • Page 262 Ethernet × 1, SMART slot × 1, REPO × 1 Online Mode up to 96.5% ECO Mode Nominal Voltage ± 240 Vdc (Default) Charge Voltage ± 272 Vdc (adjustable from 204 Vdc to 312 Vdc) Battery Protection of Battery Deep Discharge Modulon DPH Series A1-2...
  • Page 263 Appendix 1 Model 100kVA/ 150kVA/ 200kVA/ 250kVA/ 300kVA/ UPS Capacity 100kW 150kW 200kW 250kW 300kW Operating Altitude 1000 meters (without derating) Operating Temperature 0 ~ 40°C Environment Relative Humidity 95% (non-condensing) Audible Noise < 75 dBA * IP Degree of Protection IP 20 Parallel Redundancy Yes (up to 8 units)

  • Page 265: Appendix 2 : Warranty

    Appendix 2 Warranty Warranty A2-1...
  • Page 266 The User Manual must be carefully followed. Seller makes no representation No. 501326810000 Version : V 0.0 Release Date : 2018_12_28 Modulon DPH Series A2-2...

Table of Contents
