5.7.3 STS Module's LED Indicator
The STS module's LED indicator shows its operation status. Please refer to the following
table.
LED Indicator
OFF
ON (yellow)
Flashing (yellow)_ on for 0.3 second and
Modulon DPH Series
Press the Lock
(Figure 5-33: Press the Lock of the STS Module)
LED Indicator
NOTE:
In bypass mode, if you turn the STS module's switch to the lower position (
(Figure 5-34: STS Module's LED Indicator)
The STS module is OFF.
The STS module is working in bypass
mode, ECO mode, or energy recycle
mode.
The STS module is abnormal.
5-30
