Delta Modulon DPH Series User Manual page 23

2 Introduction
(Internal View after Wiring
Terminal Cover Removal)
N
Battery Input
UPS Output
N
L2
L3
L1
(Figure 2-8: Wiring Terminals_ UPS Output & Battery Input)
(Internal View after Wiring
Terminal Cover Removal)
Grounding Terminals
( & )
(Figure 2-9: Wiring Terminals_ Grounding)
2-11
