Before Installation And Wiring; Installation Environment - Delta Modulon DPH Series User Manual

5.1

Before Installation and Wiring

1. Please read this user manual thoroughly before installation, wiring and usage. Only
authorized Delta engineers or service personnel can perform installation, wiring, panel &
cover removal, maintenance and operation. If you want to execute any action mentioned
above by yourself, the action must be under the supervision of authorized Delta
engineers or service personnel. If you use a forklift or other equipment to move the UPS,
2. You can install at maximum sixteen battery modules (optional) inside the UPS cabinet.
For relevant information, please refer to 5.9 Battery Module (Optional). To extend
backup time, the UPS can be connected with at maximum four external battery cabinets
External Battery Cabinet Connection Warnings for relevant information.
3. In this user manual, the meaning of Q1, Q2 and Q3 represents the following.
5.2

Installation Environment

Install the UPS indoors. Do not place it outdoors.
Make sure that transportation routes (e.g. corridors, door gates, elevators, etc.) and
installation area can accommodate and bear the weight of the UPS, external battery
cabinet and handling equipment. Please refer to Table 5-1
mation.
Table 5-1: UPS Floor Weight Loading Table
UPS Capacity
Power Module Q'ty
Maximum Battery
Weight Loading
The UPS adopts top wiring. Please leave adequate space on the top of the UPS to al-
low cable entry.
Ensure that the installation area is big enough for maintenance and ventilation. Since
the UPS adopts the design of air inlet at the front and air outlet at the rear, we suggest
that you:
Modulon DPH Series
Code
Q1
Q2
Q3
15kVA/ 15kW
Module Q'ty
Weight
1323.6kg/m
Input/ Bypass Breaker
Manual Bypass Breaker
Output Breaker
DPH Series UPS_ 15~ 60kVA
30kVA/ 30kW
1+1 2+1
16 16
675kg 697kg
2
1365.1kg/m
5-2
Table 5-1.
Meaning
45kVA/ 45kW
3+1
16
718kg
2 2
1406.7kg/m
5.6
-
60kVA/ 60kW
4+1
16
739kg
2
1448.3kg/m
