Delta Modulon DPH Series User Manual page 151

WARNING:
1. For parallel units, ensure that every operation procedure mentioned below is
simultaneously executed and performed to all of the parallel UPSs.
parallel ones, please contact service personnel.
1
In ECO mode, the LCD shows the following screen and the tri-color LED indicator
illuminates green. For the tri-color LED indicator location, please refer to Figure 2-11.
UPS-1.1 MEASUREMENT
Power Flow
POWER FLOW
Maintenance
Power Flow
Bypass
Bypass
Summary
Mains
System Status
90 %
5 mins
(Figure 6-52: ECO Mode Screen & ON/ OFF Button Location)
Press the ON/ OFF button (
2
normal or not. If normal, please select 'YES'.
UPS-1.1 MEASUREMENT
Power Flow
SETUP MAINTENANCE
) once and the following screen will pop up to ask you
SETUP MAINTENANCE
POWER OFF ?
Transfer to Bypass without Protection!
Yes
6-37
LOG IN EVENT LOG
User
Load
30 %
LOG IN EVENT LOG
User
No
6 UPS Operation
10:15
May 25,2018
ECO
ON/ OFF
Button
10:15
May 25,2018
ECO
