Other icons that might appear when you operate the LCD include:
No.
1
2
3
4
5
6
7
8
9
10
Modulon DPH Series
Icon
1
NOTE:
1. When the LCD backlight is off, you can touch the screen to wake it up. The
LCD will go back to the Main Screen. For information about the Main Screen.
Please refer to 7.6 Main Screen.
2. The backlight sleep time can be adjusted. Please refer to 7.10.7 General
Setting.
3. If you are logged in as an Administrator (the Administrator password is
required; please refer to 7.5 Password Entry), you will be logged out when the
to the Main Screen in the User login status. Even if you set up the backlight
in 'Never Sleep' mode, you will still be logged out after the screen is idle for 5
minutes.
Goes to the top page.
Goes to the last page.
Moves up.
Moves down.
Increases number.
Decreases number.
Indicates the page No.
Deletes the number/ word.
Caps Lock.
Space.
7-10
