Internal View
(Front View with Door Open)
Wiring Terminal Cover Screw x 4
(Figure 2-6: Wiring Terminal Cover & Screws Location)
(Internal View after Wiring
Terminal Cover Removal)
L1
L2
N
L3
AC Input (for
Dual Input Application)
AC Input (for Single
N
Input Application)/
L1
L2
L3
Bypass Input (for
Dual Input Application)
(Figure 2-7: Wiring Terminals_ AC Input & Bypass Input)
