Delta Modulon DPH Series User Manual page 134

8
Click
MODE SETTING
9 After manually selecting ECO mode via the LCD, press the icon (
upper left corner of the screen to go back to the Main Screen.
10 Press the ON/ OFF button (
if you want to power on the inverter. Please select 'YES'.
11
After selection of 'YES' to start up the inverter, each power module will start up and
perform self-inspection. At the same time, the system begins synchronization with the
bypass AC source. After the self-inspection is completed, the UPS will automatically
normal, the UPS will automatically switch to run in ECO mode to let the bypass AC
source supply power (see Figure 6-26). Now, the tri-color LED indicator illuminates
green and the following screen appears. For the tri-color LED indicator location,
please refer to Figure 2-11.
Modulon DPH Series
UPS-1.1 MEASUREMENT SETUP
Mode Setting
Select to change system mode
On-Line Green
(Figure 6-24: Select ECO Mode)
UPS-1.1 MEASUREMENT SETUP
Power Flow
(Figure 6-25: Power On Reminder Screen)
.
MAINTENANCE LOG IN
Administrator
Energy
ECO
Recycle
) once and the following screen will pop up to ask you
MAINTENANCE LOG IN
Administrator
POWER ON ?
No
Yes
6-20
10:15
May 25,2018
EVENT LOG
Bypass
Frequency
Conversion
UPS-1.1
10:15
May 25,2018
EVENT LOG
Bypass
) located in the
