4.1.3 External Battery Temperature Dry Contacts

You can use the external battery temperature dry contacts (BT1, BT2, BT3 and BT4) to
detect at maximum four external battery cabinets' temperature. You need to purchase the
battery cabinet temperature sensor cable (optional).
(Figure 4-6: Jump CNR3 Location)
(Figure 4-7: External Battery Temperature Dry Contacts Design)
EXT. BATT
TEMP.
BT1 BT2
BT3 BT4
