HP Indigo press 3050
User guide
English version

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Indigo press 3050 and is the answer not in the manual?

Questions and answers

Summary of Contents for HP Indigo press 3050

  • Page 1 HP Indigo press 3050 User guide English version...
  • Page 2 3050 user guide...
  • Page 3 © copyright The HP Indigo press is a Hewlett-Packard Company Class 1 Laser Product 2006 containing high voltage power supplies and laser All Rights Reserved. light sources. There is no Reproduction, adaptation, danger to persons or or translation without prior...
  • Page 4: Table Of Contents

    HP Indigo press 3050 jobs ........
  • Page 5 HP Indigo online help suite ........
  • Page 6 Imaging oil replenishment........70 Paper transport adjustment .
  • Page 7 Shifting separations ..........125 For simplex printing .
  • Page 8 Maintaining the paper transport system ......177 Cleaning the paper path sensors ....... . 177 Cleaning the paper transport rollers .
  • Page 9 Checking ink flow ..........246 Calibrating ink density using an external densitometer .
  • Page 10: Preface

    Preface Welcome to the HP Indigo press 3050. This preface provides an overview of the user guide contents and explains conventions used in this guide. This preface contains the following sections: About this user guide Conventions used in this guide...
  • Page 11: About This User Guide

    Preface: Provides an overview of the user guide contents and explains conventions used in this guide. Getting started: Provides an overview of the HP Indigo press 3050 and describes the print cycle. Safety: Provides important safety information for using the HP Indigo press 3050.
  • Page 12: Conventions Used In This Guide

    Conventions used in this guide This guide uses the following documentation conventions: Keyboard keys to press appear in all capital letters, for example: Press the SHIFT key. Menu options are indicated in bold type, for example: On the File menu, click New. Window names appear in italics, for example: After selecting the options in the Print window, click OK.
  • Page 13 12 Chapter 1 Preface ENWW...
  • Page 14: Getting Started

    Getting started This chapter contains the following sections: Overview Press specifications A look inside the press Print cycle ENWW...
  • Page 15: Overview

    Overview This chapter contains a tour of the HP Indigo press 3050 and a description of the press workflow. The HP Indigo press 3050 is a sheet-fed digital offset color press that incorporates the patented HP ElectroInk liquid ink technology and high-speed electronic imaging to produce fully-finished, high-volume, high-quality color print jobs.
  • Page 16 (number of color separations on side 1 / number of color separations on side 2) Color Up to seven colors are supported. One option is four process colors (cyan, magenta, yellow, and black), plus three spot colors. Another option is the HP IndiChrome process (six color process), plus one spot color. Input formats The following input formats are supported: PostScript®...
  • Page 17: A Tour Of The Press

    Output: printed substrate Figure 2-2. From pre-press to the press The system consists of two subsystems: the HP Indigo RIP and the press. The RIP software reads the files from the pre-press station, converts them to bitmaps (one per separation), and then sends them to the press for printing.
  • Page 18: A Look Inside The Press

    A look inside the press Figure 2-3. Press schematic A look inside the press 17 ENWW...
  • Page 19: Print Cycle

    Print cycle Once the job is in the print queue, the press can begin the print cycle. The following steps are used in printing a job with the press: starting up charging and discharging the PIP inking the PIP transfer to the blanket printing the image Starting up To initiate the print cycle, in the control panel, click Print.
  • Page 20: Inking The Pip

    Laser beams (12) selectively discharging the Writing head PIP drum Figure 2-6. Discharging the PIP Inking the PIP Binary ink developer (BID) units apply ink on the PIP. Ink is applied only to the discharged areas of the PIP. Ink particles are attracted either to the BID developer drum or to the PIP. The PIP discharged areas, which are the image areas, attract the ink particles.
  • Page 21: Transferring To The Blanket

    Transferring to the blanket The PIP comes in contact with the intermediate transfer member (ITM) drum, which is covered by the blanket. The positively charged blanket attracts the inked image. The image is transferred from the PIP to the blanket (this is the first transfer). There should be no residue on the PIP.
  • Page 22 The paper transport system moves the printed sheet towards the exit rotors and feeds in a new sheet. For duplex jobs, the perfector moves the sheet into the perfector tray and turns the sheet over for the second-side printing. Rotors Perfector Impression Duplex...
  • Page 23 22 Chapter 2 Getting started ENWW...
  • Page 24: Safety

    Safety This chapter contains the following sections: Overview Warning signs and labels Safety devices Emergency power shutdown Door interlocks and warning indicators Maintenance safety and emergency procedures Flammable liquids and fumes ENWW...
  • Page 25: Overview

    HP Indigo press 3050. The safety information and procedures described in this chapter apply to operators and other personnel working on or near the HP Indigo press 3050. The safety procedures cover the press and the area immediately surrounding the press.
  • Page 26: Warning Signs

    Flammable vapors from heated imaging oil may be present! No smoking, open flame, or sources of ignition allowed! Make sure that the room is properly ventilated at all times. See the HP Indigo Press 3050 Site Preparation Guide. Warning signs and labels 25 ENWW...
  • Page 27: Placement Of Warning Labels

    Employees should be retrained at least once a year. Eye wash stations The HP Indigo press 3050 uses inks and imaging oil that may be irritating to skin and eyes. In extreme cases of exposure, these may cause blindness. Take the following precautions:...
  • Page 28: Noise Levels

    Do not place hands on the moving blanket. Use a tool to grip the blanket metal bar. Electrical safety The HP Indigo press 3050 must be properly grounded at all times. Before operating the unit, ensure that it is grounded in conformance with the electrical code standards for your country/region (see the HP Indigo press 3050 Site Preparation Guide for recommendations).
  • Page 29: Emergency Power Shutdown

    Emergency power shutdown The following can cut off electrical power to the press: Emergency Stop buttons: In an emergency press one of the red Emergency Stop buttons to turn off all power to the main engine. A red Emergency Stop button on a yellow background is located at the operator workstation, at both sides of the front door, and in other prominent locations on the press.
  • Page 30: Door Interlocks And Warning Indicators

    Figure 3-2. Power Enable switch Door interlocks and warning indicators The HP Indigo press 3050 has interlocked doors that stop the machine and turn off electrical power to most system devices when the service doors are opened. WARNING! Access and use of bypass keys must be restricted to specifically trained personnel. Do not disconnect or override any of these safety devices when operating the system.
  • Page 31 If any of the doors are open, the interlock activates and prevents operation of the high-voltage power supply and the main motor. Reservoir door Upper feed door Front door Rear cover tray B door Rear cover tray A door Front cover tray B door Front cover Lower feed door...
  • Page 32: Maintenance Safety And Emergency Procedures

    All interlocked doors have visual indications when they are open. The door and interlock warning indicators appear in the control panel and in the schematic window, which shows all open doors. Interlock indicators Figure 3-5. Interlocks window Maintenance safety and emergency procedures Standby status Put the press in Standby when the system is not required to print or when the system is unattended.
  • Page 33: Inch-Safe-Service Method

    Inching button Figure 3-7. Exit Inching button Inch-safe-service method WARNING! Do not perform maintenance on rotating parts (such as drums) with a hand on a moving part while the press is on slow roll (for example, pressing the Inching button). Health and safety regulations require that you use the inch-safe-service method.
  • Page 34: Flammable Liquids And Fumes

    Flammable liquids and fumes Because the imaging oil used by the HP Indigo press is combustible (USDOT Class 3A), use the following safety procedures: Operate the press in a well-ventilated room (see the HP Indigo Press 3050 Site Preparation Guide).
  • Page 35: Disposing Of Consumables And Cleaning Materials

    Contaminated chemical-resistant gloves Empty imaging oil containers Additional information It you have any questions regarding safe operation of the HP Indigo press 3050, do not continue operation without contacting a customer engineer. Additional MSDS are available upon request from your customer engineer.
  • Page 36: Hp Indigo Press 3050 Basics

    HP Indigo press 3050 basics This chapter contains the following sections: The press interface HP Indigo online help suite ENWW...
  • Page 37: The Press Interface

    As you progress, additional windows become available. Wizards Wizards reduce the usual input process by providing interactive, step-by-step instructions for complex routines. 36 Chapter 4 HP Indigo press 3050 basics ENWW...
  • Page 38: Hp Indigo Online Help Suite

    HP Indigo online help suite About the online help suite The HP Indigo press online help suite consists of two separate guides: the reference guide and the operation guide. The reference guide describes the windows used to operate the press. The operation guide provides step-by-step instructions for the options available from the windows.
  • Page 39: Operation Guide

    Related operation procedures or by clicking a link within the topic text. Figure 4-3. Example of an operation guide help topic 38 Chapter 4 HP Indigo press 3050 basics ENWW...
  • Page 40: Help Topics Window

    Help Topics window To open the HP Indigo press Help Topics window, click Help, and then Contents in the control panel. The Contents tab of the Help Topics window lists all the topics in the help. Access topic pages from this tab by locating the relevant topic, and then clicking Display.
  • Page 41 Figure 4-5. Related topics 40 Chapter 4 HP Indigo press 3050 basics ENWW...
  • Page 42: The Main Windows

    The main windows This chapter contains the following sections: Using the control panel Managing jobs Using the Job Editor ENWW...
  • Page 43: Using The Control Panel

    Using the control panel The control panel is the main window. It opens automatically whenever you load the press software. From this window, you control the entire operation of the press. Error indicator Warning indicator Print button Current print job Print mode panel selector...
  • Page 44: Current Print Job Panel

    Pay attention to the machine state while operating the press, because most machine functions are possible only at a defined machine state. Pay particular attention to the machine state while servicing the press. Each maintenance procedure describes proper the machine state for the safe performance of that procedure. Current print job panel The current print job panel displays the following job properties: job name...
  • Page 45: The Schematic Animated Indicator

    The schematic animated indicator The schematic animated indicator is a representation of the press as it is seen from the front. It can appear in several forms on the control panel. Each form indicates a different machine status. Standby Print Figure 5-4.
  • Page 46 PIP drum Writing Head Scorotrons Cleaning station BID units ITM drum Output rotors Perfector Impression drum Exit tray Ink cans Ink tanks Imaging oil filter Paper feed unit Figure 5-5. Schematic window Accessing a subsystem Access a subsystem using one of the following methods: In the Schematic window, click the subsystem.
  • Page 47: Managing Jobs

    Managing jobs As part of your working routine, you will be importing, maintaining, arranging, and printing jobs. All these activities are performed by the Job Manager. Jobs are imported into the system and appear in the Job Manager window. To import jobs manually, on the Job menu, click Import, or use the RIP Hotfolders.
  • Page 48: The Loaded Jobs List

    Loaded Jobs list, deleted, or copied to the Retained Jobs list before it is deleted. End of print status is generally defined as part of the default job properties on the HP Indigo RIP or by redefinition of the job properties. Managing jobs 47...
  • Page 49: Retained Jobs

    Retained Jobs The Retained Jobs window contains jobs that have been marked for deletion (in job properties) after a specified time. You can access the jobs for reprinting or exporting (archiving) while they are still on the Retained Jobs list. Access the Retained Jobs list in one of the following ways: On the Job menu, click Retain List.
  • Page 50: Job Editor Functions

    Jobs that are created in this way are used as building blocks for creating or editing jobs in the Job Editor. Automatic load of SNAP jobs. See the HP Indigo Yours Truly Express User Guide and the HP Indigo Yours Truly Designer User Guide for further details.
  • Page 51 Use the following procedure to configure the press Hotfolder: From the control panel, click the Options menu, and then select Hot Folder. Figure 5-9. Hot Folder Parameters window Click the Hot Folder tab, and then define the Hotfolder path. Figure 5-10. Defining Hotfolder path 50 Chapter 5 The main windows ENWW...
  • Page 52: Job Imposition

    Job imposition Job imposition helps you to orient printed areas on the substrate for maximum efficiency, minimizing waste. Job imposition is controlled from the Imposition window. From the Job Editor window, on the Tools menu, and then click Imposition. Figure 5-11. Imposition window The Imposition window allows you to perform job imposition by selecting a signature file (template) that defines the number and layout of spreads to fit on a printed page.
  • Page 53 52 Chapter 5 The main windows ENWW...
  • Page 54: Operating The Press

    Operating the press This chapter contains the following sections: Turning the press on and off Printing jobs Job maintenance Service operations Calibrating the press colors ENWW...
  • Page 55: Turning The Press On And Off

    Turning the press on and off Turning the press on Turn on the main circuit breaker at the rear of the machine and wait for the control panel to appear on the screen (this may take several minutes). Power Enable switch Main circuit breaker Figure 6-1.
  • Page 56: Preparing The Press

    Preparing the press Use the following procedure to prepare the press: Make certain that all the subsystems are assembled on the press. Make certain the blanket was cleaned the preceding day. Load the substrate type for the first job to be printed. Close all doors.
  • Page 57: Printing Jobs

    Printing jobs Jobs begin the printing process in the Print Queue. Their position on the list depends on urgency, substrate type, substrate thickness, number of colors in the job, or other job properties. Arrange the jobs in the list to facilitate the workflow. For example, all jobs that use the same substrate type or all jobs that use the same fifth and sixth color should be grouped and printed consecutively.
  • Page 58 Evaluate the printed job. Check for image placement in relation to the leading edge and to the left side margin (normally the image should be centered on the narrow axis and 10 mm [0.39 inches] from the leading edge). If necessary, open the Job Properties window, click the Image Placement tab and make corrections.
  • Page 59 If the job is duplexed, check the front-to-back registration. If registration is off, open the Job Properties window, click the Image Placement tab. Make corrections. Figure 6-8. Image Placement tab – duplex job Front side leading edge Front crossmarks aligned with backside crossmarks Back side leading...
  • Page 60: Stage 3: Printing The Full Run

    If the job is a multi-sheet job, make sure that the image placement is the same for all the job sheets. Distance from left margin to image is Distance from leading equal throughout edge to image is the run equal throughout the Figure 6-10.
  • Page 61: Divider Between Pages

    On the control panel, click Print to print the full-run. Divider between pages Printed divider sheets are printed from the secondary tray, and may be added for the following cases: at the end of a job at the end of a copy every “x”...
  • Page 62: Editing Job Properties

    Editing job properties When a job appears in the Loaded Jobs list, it has been defined and you do not have to redefine it. But after you print and evaluate a proof, you might decide that some of the job properties needs to be redefined.
  • Page 63: Job Look-Up Tables (Luts)

    LUT editing enables you to control the dot gain for every dot size individually. HP Indigo supplies several tailored LUTs, ranging from linear to Chromalin, with Chromalin applying the biggest dot gain. You can also create your own LUT or set a customized LUT as the default.
  • Page 64: Screening

    HDI set 2 – an average of 250 lpi You can print a separation several times to enhance density. HP Indigo supplies you with alternative color order to support transparency printing. Inks “double-hit” printing Some Ink Mixing System inks require double-hit printing in order to achieve the desired color saturation, and this feature performs double-hit printing without screening artifacts (patterns).
  • Page 65: Color Match

    To obtain the double-hit feature, open the Job Properties window, and select the desired color. Click Edit, and select the Double Hit check box. Figure 6-16. Double Hit check box Color match Color matching is the tool to use when color intensity needs to be changed. Unlike changing a LUT where every dot size can be manipulated individually, color matching is a fast but rougher tool.
  • Page 66: Annotation

    Annotation Annotation marks allow non-job-related data to be added to the final print. Select a ready-made annotation template Figure 6-17. Annotation Marks tab The print data may include fixed or dynamic data read during the print process. You may use a ready-made annotation template, or create a new template. To create an annotation template, click Options, Press Configuration, and select Annotation Marks.
  • Page 67 Click the Template Manager button in Figure 6-18 to open the annotation window (Figure 6-19). Tool bar Figure 6-19. Job Editor window – tool bar usage The toolbar in Figure 6-19 is used to create the following annotations: • text •...
  • Page 68: Service Operations

    You may preview or edit new annotations using the Job Editor. Click View and Annotation Marks to activate this feature. Figure 6-20. Job Editor window – tool bar usage Service operations Control pad button During servicing operations, frequently use the control pad buttons to rotate the press and cut off power to the subsystems.
  • Page 69: Emergency Stop Buttons

    Emergency Stop buttons The Emergency Stop buttons are red buttons that cut off power to the main engine and to the high-voltage power supply (they do not cut off power to the computer or to the writing head). The machine comes to an immediate halt when an Emergency Stop button is pushed.
  • Page 70: Sample Tray Button

    Sample Tray button The Sample Tray button is used to move a print sample from the printer to the sample tray. Sample tray button Sample tray Figure 6-23. Sample tray button To configure the sample tray option, check the sample tray window by clicking Consumables, Substrate, and Sample Tray.
  • Page 71: Consumables Overview

    The sections are arranged in order of their frequency of occurrence. Ink replenishment HP Indigo ElectroInk is a patented liquid ink composed of a suspension of imaging oil and solid pigment particles. The concentration of the ink (ink density) decreases as part of the pigment adheres to the printed substrate.
  • Page 72: Paper Transport Adjustment

    Note The press can print for eight additional hours before you need to replenish the imaging oil supply. You should replenish imaging oil at the end of the day or before a long break so that the imaging oil temperature will not be affected by the newly added imaging oil. Paper transport adjustment Every job is printed on a particular type of paper (or any printable substrate).
  • Page 73: Impression Paper Maintenance

    Impression paper maintenance The impression drum creates pressure on the substrate against the ITM drum to allow transfer, and to carry the sheet from the input tray to the exit tray. The sheet is held firmly by the grippers throughout the one to seven press revolutions of the printing process. The impression paper protects the drum from ink.
  • Page 74: Color Adjust

    Color Adjust The purpose of the color adjust procedure is to adjust the press to guarantee color repeatability across the run and between runs. The procedure allows you to set the density of the 100 percent dot and the 50 percent dot without altering the color reproduction curve.
  • Page 75: Calibrating The Machine Lut

    Click Get Ready. The press changes to the Ready state. Figure 6-28. Custom Color Adjustment wizard (second step) Select the Start with the default parameters check box. Select the Include Velectrode Calibration check box. Click Next. Press F1. The online help opens. Follow the online help instructions.
  • Page 76: Substrate-Related Parameters

    Click Adjustments, and Machine LUT Generation to open the Machine LUT Generation window. Figure 6-29. Machine LUT Generation window Click Adjustments and Machine LUT Validation to open the Machine LUT Validation window. Figure 6-30. Machine LUT Generation window The validation will check that the Job LUT specified in the Machine LUT Validation window is printed to an accuracy within ±5 percent.
  • Page 77 1.45 1.45 1.75 HP Indigo Ink Mixing System inks will calibrate the optical density specified in the HP Indigo Ink Mixing System file. If you are not sure what substrate gloss level to define for a specific substrate, perform the following steps: Perform a color adjustment on a glossy substrate.
  • Page 78: Workflow For Machine Lut Generation And Substrate-Related Parameters

    Each time a substrate is replaced, a pop-up message appears, reminding you to perform the color adjustment. Defining a different substrate type (gloss level) will automatically adjust the optical densities. List of machine LUT values from other substrates Figure 6-31. Edit substrate definition window It is possible to assign a LUT to a substrate according to another substrate.
  • Page 79 Perform a machine LUT for all substrates used. Perform a machine LUT for all screens used. Perform a Color Adjust for each substrate type. High accuracy workflow For a high accuracy workflow, perform the following: Perform a machine LUT on a weekly basis (50,000 to 150,000 impressions), and/or when the software recommends it.
  • Page 80 Last machine LUT generation The last machine LUT generation provides a machine LUT that is calibrated according to the last machine LUT calibration performed. Allows the use of default LUT curves for all inks for a selected screen Last machine LUT generation Enables LUT generation for Time of calibration inks separately, or together...
  • Page 81: Calibrating The Inline Densitometer

    The Last Machine LUT Validation Results window shows the last Job LUT validation performed. The laser power, developer The results of the last voltage, and solid optical density machine LUT generation at the time of the validation Date and time for The number of impressions the last validation performed since the last validation...
  • Page 82: Performing The Full Densitometer Calibration

    Follow the online help instructions. Performing the full densitometer calibration Perform the full densitometer calibration when you suspect that the quick densitometer calibration has not calibrated the densitometer. On the Adjustments menu, select Color Adjustment and Calibration. The Color Adjustment and Calibration Wizard Manager opens. Figure 6-35.
  • Page 83 82 Chapter 6 Operating the press ENWW...
  • Page 84: Operator Routines

    Operator routines This chapter contains the following sections: Overview Start-of-day routine End-of-day routine Weekly routines Monthly routines Mechanical system lubrication ENWW...
  • Page 85: Overview

    Overview This chapter provides an overview of the daily, weekly, and monthly routines that you should perform for proper maintenance of the HP Indigo press 3050. The following procedures are guidelines to performing press maintenance. All procedures must be performed in accordance with the full procedures provided in the maintenance sections of this guide.
  • Page 86: Power-Up Procedure

    Power-up procedure Perform the following steps one after another with no delay between steps. Close all the doors. Turn on the Main Power switch. Wait for the press control panel to appear. Press the Power Enable switch. In the control panel, click Get Ready. End-of-day routine If your press prints three shifts a day, lubricate the required components once a day as described in ‘Mechanical system lubrication’...
  • Page 87: Monthly Routines

    13 Check the paper feed suction cups for dirt and tears. Clean with IPA. If necessary, replace the suction cups. See ‘Setting suction fingers’ on page 162. 14 Clean the upper feed roller with IPA. 15 Drain the solid air compressor. See ‘Draining the solids air compressor’ on page 259. 16 Clean the black ink BID using the cleaning foil.
  • Page 88 The lubrication points are described in sequence by press side: front, right (paper feed), left (paper exit), and rear sections (see Figure 7-1). Rear Paper exit Front Paper feed Input conveyor Figure 7-1. Press sides The following symbols are used in Figure 7-2 through Figure 7-21 to indicate the required lubricant: O —...
  • Page 89: Paper Feed Unit

    Paper feed unit All moving parts in the machine are covered either with doors or with guards. The following figures illustrate all the lubrication points in the paper feed unit, behind both front and rear covers. Figure 7-2. Input tray chain (inside front and rear) Figure 7-3.
  • Page 90 Figure 7-4. Elevator motor gear (use the grease on the outer front cover) Figure 7-5. Suction fingers bar (inner rear wall) Figure 7-6. Suction fingers bar (inner front wall) Mechanical system lubrication 89 ENWW...
  • Page 91 Figure 7-7. Inner front wall 90 Chapter 7 Operator routines ENWW...
  • Page 92 For cams located behind three cam wheel see Figure 7-9 Figure 7-8. Paper feed unit motor (outer rear wall) Figure 7-9. Cams behind three cam wheel Mechanical system lubrication 91 ENWW...
  • Page 93: Input Conveyor

    Figure 7-10. Stack centering screw (inside rear and front walls) Input Conveyor Lubricate the input conveyor side jogger and static side guide. The following figures illustrate all the lubrication points in the conveyor on the front and rear sides. Figure 7-11. Rear side jogger 92 Chapter 7 Operator routines ENWW...
  • Page 94: Front Section

    Figure 7-12. Front static guide Front section All moving parts in the machine are covered either with doors or with guards. The following figures illustrate all the lubrication points in the front behind the ink concentrate cans. Figure 7-13. Front of press Mechanical system lubrication 93 ENWW...
  • Page 95 Figure 7-14. Front scorotron lubrication points Figure 7-15. PIP drum gear drum Figure 7-16. Paper input side 94 Chapter 7 Operator routines ENWW...
  • Page 96: Paper Exit

    Note: BG-87 Molykote or equivalent grease is used for the PIP, ITM, and impression drums Figure 7-17. Impression drum gear Paper exit WARNING! Turn off the Power Enable switch before performing this procedure. To access the paper exit bay, see ‘Accessing the impression drum area’ on page 175. Use a flathead screwdriver to remove the cap...
  • Page 97: Rear Section

    Rear section Open the rear press door. WARNING! Turn off the Power Enable switch before performing this procedure. Impression engage motor – see Figure 7-21 Figure 7-19. Rear (fly wheel and belt) Figure 7-20. Rear (scorotron bridge) 96 Chapter 7 Operator routines ENWW...
  • Page 98 Figure 7-21. Rear (impression engage motor) WARNING! Ensure that all equipment, tools, and materials are removed from the unit and that all doors are closed before operating the machine. Mechanical system lubrication 97 ENWW...
  • Page 99 98 Chapter 7 Operator routines ENWW...
  • Page 100: Handling Ink

    Handling ink This chapter contains the following sections: Overview Draining the ink tank Replacing ink cans and rebuilding ink Adjusting ink density Adjusting ink conductivity Viewing the ink can log Cleaning the ink pump ENWW...
  • Page 101: Overview

    Overview HP ElectroInk, the ink used on the press, is mixed on the press from three components: imaging oil, imaging agent, and ink concentrate. Ensure a constant supply of both the imaging oil and the ink concentrate. The press system automatically identifies shortages of either of the two components, and prompts you to take the correct course of action.
  • Page 102: Draining The Ink Tank

    The ink constantly circulates between the ink tanks and the BID. To compensate for the ink adhering to the PIP, the press system supplies ink concentrate from the ink cans. The imaging oil tank supplies the imaging oil when triggered by the level sensors. The press supplies imaging agent to the ink tank when the conductivity value in the tank is low.
  • Page 103: Replacing Ink Cans And Rebuilding Ink

    11 Dispose of ink in accordance with your local waste disposal requirements. Drained ink that is not contaminated can be stored in sealed containers for later use. 12 Release the Emergency Stop by turning the knob until it is released. WARNING! Ensure that all equipment, tools, and materials are removed from the unit and that all doors are closed before operating the press.
  • Page 104: Rebuilding The Ink In A Tank

    Dispose of empty cans according to your local waste disposal requirements. Locate a new can of HP ElectroInk and shake it well. Remove the foil from the can. With the nozzle down, insert the new can in the holder. Push up and in. Fit the nozzle in the O-ring in the base.
  • Page 105 On the control panel, click the Consumables menu, and then select Ink Cans. The Ink Cans window opens. Figure 8-6. Ink cans window Click the panel below the name of the ink can that requires rebuilding. Click Rebuild. The word Yes appears in the Rebuild Ink field. The next time the press is in the Getting Ready state, ink concentrate is added at the required density to the tank.
  • Page 106: Adjusting Ink Density

    Figure 8-8. Adding imaging agent Note Newly rebuilt ink is ready for use an hour or more after you have rebuilt it. Adjusting ink density Calibrating ink density wizard On the Control Panel, click Consumables, and Install Ink. The Density Calibration Wizard Manager window opens.
  • Page 107: Adjusting Ink Conductivity

    If the ink density keeps rising above 2.0, clean the pump and density sensor, and then check the density again. See ‘Cleaning the ink pump’ on page 109. If the problem persists, call your HP Indigo service center. Adjusting ink conductivity The ink conductivity in the ink tanks should be between 90 to 100 pmho/cm at a working temperature of 30°...
  • Page 108: Adding Imaging Agent

    Adding imaging agent Ink conductivity is monitored by the system. Imaging agent is added automatically from the imaging agent container. Note The following warning message appears when the imaging agent container is empty: Some of the ink tank is not reaching the desired conductivity. Add imaging agent.
  • Page 109: Viewing The Ink Can Log

    Check the ink conductivity again. Note If ink conductivity keeps rising above 110 pmho/cm, call your HP Indigo service center. Viewing the ink can log Use the ink log to track ink can replacements and the number of impressions for each replaced ink can.
  • Page 110: Cleaning The Ink Pump

    Clean ink pumps for the four process colors (cyan, magenta, yellow, and black) once a month. Clean ink pumps for the HP IndigoChrome spot colors once a week. Before carrying out this procedure, make sure to have the following items:...
  • Page 111 Note Make sure the press is off. Take out the ink can. Pull the unit by the front handle until it comes free and lift it out (Figure 8-15). Figure 8-15. Ink pump removal Place the unit in the wash basin or in a plastic-lined tray. Note Don’t remove the filter from the pump.
  • Page 112 Pump motor housing TCU board Level sensor Conductivity sensor Ink concentrate Impeller ink outlet inlet O-ring Impeller housing Filter Magnets Figure 8-16. Ink pump Clean the filter using imaging oil. Use a nylon brush to clean the inside of the ink outlet. Use clean imaging oil to remove the ink waste.
  • Page 113 11 Insert the paper into the density sensor slit which is located at the back of the electronic board on the pump unit. Remove the paper. Density sensor Figure 8-17. Density sensor cleaning 12 Clean the sensor with imaging oil. Note Do not use the same paper twice.
  • Page 114: Blanket

    Blanket This chapter contains the following sections: Overview Replacing the blanket Cleaning the blanket Shifting separations ITM temperature sensor First pressure adjustment Removing the ITM hood ENWW...
  • Page 115: Overview

    Overview The press blanket transfers ink from the photo-conductive image plate (PIP) to the printed substrate. At the end of each machine revolution, both the PIP and the blanket are completely clean and ready for the next separation. For the blanket to function properly: the blanket pins should be inserted in the intermediate transfer media (ITM) drum slots, the blanket should be stretched on the ITM drum, and you should keep the blanket clean at all times.
  • Page 116 Place the ITM hood in the maintenance position. ITM hood Figure 9-2. ITM hood (maintenance position) Press the Inching button to advance the ITM drum until the leading edge of the blanket is in view. ITM drum Blanket leading edge Figure 9-3.
  • Page 117 Cut the blanket with a knife just above the outside metal clamp. Angle the knife upwards as shown in Figure 9-4. ITM drum Outside Metal width metal clamp behind the blanket Blanket leading edge Cut here Side view Figure 9-4. Leading edge of blanket Insert the needlenose pliers between the blanket and the ITM drum on the rear side above the metal fastener bar.
  • Page 118: Installing A New Blanket

    Gently pull the leading edge of the blanket. BLANKET REMOVAL2A1 Figure 9-6. Lift the leading edge with the needlenose pliers 10 Using the needlenose pliers, lift up the metal fastener bar. WARNING! The bar is extremely hot and can cause injury. 11 Press the Inching button to advance the machine slowly.
  • Page 119 13 Clean the ITM drum with a lint-free wipe dampened with imaging oil. To clean all sides, advance the ITM drum intermittently with the Inching button. Imaging oil dries rapidly. Wipe off any residue oil before it dries. Installing a new blanket After cleaning the ITM drum, advance the machine so that the ITM slot is in view.
  • Page 120 Insert the metal fastener bar pins into the slots in the ITM drum. Press the leading edge of the blanket against the drum so that it is flush with the surface. Figure 9-10. Insert the pins in slots in the ITM drum Press the Inching button to advance the machine.
  • Page 121: Cleaning The Blanket

    12 Click the Replacement Cause drop-down list. Select the reason for replacement. If none of the options are applicable, select Other and enter your reason. Avoid using Other as much as possible. If you must use it, give a specific reason for the PIP replacement.
  • Page 122: Recovering The Blanket Surface

    Gently rub the blanket with the folded wipe, change the wipe’s side when one side gets dirty. Figure 9-13. Fold the pad four times If the blanket is still soiled, soak the lint-free wipe in imaging oil and rub the blanket until the ink residue and other contamination are removed.
  • Page 123 Recovering the blanket surface Perform this procedure whenever a paper jam occurs. Immediately check for paper or ink residues on the blanket. Residues can damage the blanket if not removed immediately, while the blanket is still hot. The following procedure depends on the time elapsed since the paper jam occurred to the time the Print Cleaner function is activated.
  • Page 124: Automatic Blanket Cleaner Page

    If not already selected, select the Paper Jam Handling mode check box. Figure 9-15. Print Cleaner wizard If the time allocated by the software for handling a paper jam has expired, you are notified to clean the blanket manually before proceeding. Figure 9-16.
  • Page 125 Automatic blanket cleaner page The cleaner page is generated after a pre-set number of separations, for the following cases: At the end of a job When pausing the print When switching a job The cleaner page may also be inserted in the middle of a job (useful for long jobs). To activate this option, click Consumables and Blanket to open the Blanket window.
  • Page 126 Disabling the automatic cleaner page option Use one of the following methods to disable the automatic cleaner page option: Method 1 On the control panel, click the Consumables menu, and then select Blanket. The Blanket window opens. Click the Cleaner Page tab. Select the Bypass Cleaner Page check box.
  • Page 127: Shifting Separations

    Shifting separations The separation placement procedure shifts the selected separation vertically in relation to the other separations. Perform this procedure to overcome registration problems. Perform this procedure after replacing a blanket. Seasoned blankets require less separation shifting. You can shift any separation if your user level is set to Supervisor or higher. For simplex printing On the control panel, click Pause.
  • Page 128: Itm Temperature Sensor

    ITM temperature sensor The infrared (IR) temperature sensor reads the ITM drum temperatures. The temperature sensor readings are used to turn the ITM heating on and off to keep the blanket at a pre-set temperature. Clean the ITM shoulder below the IR temperature sensor using a lint-free wipe soaked with imaging oil.
  • Page 129: First Pressure Adjustment

    First pressure adjustment Overview When the PIP drum or ITM drum pressure is adjusted in the press, you achieve full transfer of both the highlights (small dots) and the solids (100 percent dots). Adjust the pressure between the PIP and ITM drums on the front and rear controls using the First Transfer Calibration.
  • Page 130 When the following conditions occur, use the First transfer Calibration: After you change the blanket. When the ink coverage is partial and blank patches in the shape of white clouds appear on either side of the printed image. When the highlight dots (small dots) do not transfer to the substrate. Use the following procedure to adjust the first transfer pressure: On the control panel, click the Adjustments menu and select First Transfer Calibration.
  • Page 131 Click Next. Front Rear Figure 9-22. First transfer Wizard (define the correct pressure here) 130 Chapter 9 Blanket ENWW...
  • Page 132 Click Finish. Figure 9-23. Calibration completed Figure 9-24 through Figure 9-27 illustrates how first transfer calibration decisions are made. The illustrations are prints taken during a First Transfer Calibration procedure. In the samples, nine sheets of the First Transfer Calibration job were printed. Figure 9-24 through Figure 9-27 show sheets number 4 to number 6.
  • Page 133: Removing The Itm Hood

    Figure 9-26. Spread 6 (correct rear Figure 9-27. Spread 7 (too much pressure) pressure) Spread 5 is the first one to print 3 triangles in the left column and spread 6 is the first to print in the right column. See Figure 9-22. Removing the ITM hood Perform the following procedure to remove the ITM hood and allow access to the cleaning station, replace the PIP, or allow access for maintenance procedures.
  • Page 134 To open the ITM hood, pull the ITM latch, hold the ITM hood knob and pull it forward. Lift the input paper conveyor. Upper feed door Front door Input conveyor Figure 9-28. Press doors and conveyor ITM hood upper bar ITM hood lock ITM hood ITM latch...
  • Page 135 Remove the left side (front) first and then the right side (rear). Hood upper bar ITM hood Figure 9-30. Removing the ITM hood Install the ITM hood by reversing the steps above. 134 Chapter 9 Blanket ENWW...
  • Page 136: Pip

    This chapter contains the following sections: Overview Replacing the PIP ENWW...
  • Page 137: Overview

    Overview Images are written on the photo-conductive imaging plate (PIP). Images are erased from the PIP with each revolution. To work efficiently, the PIP must be capable of charging and discharging continuously and to support sharp image definition. To prolong the PIP’s longevity, handle it with care, keep it as clean as possible, and protect it from direct light.
  • Page 138 Use the following procedure to lift the scorotron bridge lever: Holding the scorotron bridge lever, push lightly upwards and rotate it towards you to loosen it. Once the lever is free, push all the way up. Lock the lever by rotating it away from you. Make sure the lever studs at both ends are inserted into their sockets.
  • Page 139 Open the front door. Front door Emergency Stop button Work table Figure 10-3. Front door Remove the cleaning station blade. Cleaning station blade holder Handwheel Figure 10-4. Remove cleaning station blade (behind front door) 138 Chapter 10 PIP ENWW...
  • Page 140 10 Soak a lint-free wipe with imaging oil, clean the cleaning station blade, and lay it aside on a clean surface. Cleaning station blade Figure 10-5. Clean the cleaning station blade 11 On the control pad, press the Inching button to advance the press until the PIP trailing edge is in view.
  • Page 141: Installing The New Pip

    13 Remove the used PIP’s leading edge from the slot and hold it away from the PIP drum. Figure 10-8. Remove leading edge 14 Press the Inching button to advance the machine and lift off the PIP as the drum rotates.
  • Page 142 Gently pull the PIP out of its protective cover. Wipe the cartridge clean with a lint-free wipe soaked in imaging oil. This prevents particles from being transferred from the cartridge to the PIP. Pull out the leading edge about 10 cm (4 inches). Remove the self-adhesive pull-tab.
  • Page 143 10 Continue rinsing the exposed underlayer surface. Rinse all dry sections until the entire drum has been thoroughly rinsed and the PIP’s holder is visible. 11 Place the PIP trailing edge over the leading edge. Trailing edge Figure 10-12. Place PIP trailing edge over leading edge 12 Place the scorotron bridge in working position (see Figure 10-1).
  • Page 144: Replacing The Pip Underlayer

    Replacing the PIP underlayer Special Tools and Jigs PIP underlayer installation jig PIP underlayer scraper Procedure Press the Emergency Stop button. Remove the following: Cleaning blade from the cleaning station ITM hood Cleaning station Air knife Lift up the scorotron bracket. Note Two persons will be required for this procedure.
  • Page 145 PIP drum PIP groove Cleaning paper Figure 10-14. Drying the PIP holder slit 13 Thoroughly wash the PIP underlayer installation jig with imaging oil to clean the jig’s surface. 14 Install sleeves on each end of the PIP underlayer installation jig. Sleeves Figure 10-15.
  • Page 146 16 After the jig is in place, push the sleeves on either side of the jig outward, and lock them in place with the latches on the outside walls. Latch for jig sleeves Jig sleeve Figure 10-17. Jig latches Mounting tab White strip attached to mylar side PIP underlayer...
  • Page 147 PIP drum PIP groove PIP underlayer installation jig Layer roll with transparent protective coating (mylar) on top Figure 10-19. Mounting the PIP underlayer Rotate the drum clockwise and at the same time unrolling the PIP underlayer until the PIP holder slit is above the jig surface. Fold the PIP underlayer sheet between the metal and plastic of the mounting strip over the jig and set the sheet edge parallel to the jig surface.
  • Page 148 • Do not stop the drum during the rotation and application of the PIP underlayer. CAUTION The PIP underlayer should not overlap the shoulders. Make sure that no debris sticks to the PIP underlayer. PIP drum Tape PIP holder slit PIP underlayer installation jig DSC9...
  • Page 149: Updating Your System

    Updating your system On the control panel, click the Consumables menu, and then select PIP. The PIP window opens. Figure 10-22. PIP window Click the Replace PIP tab. In the Serial No field, type the serial number for the new PIP. Click the Replacement Cause drop-down list.
  • Page 150: Paper Transport

    Paper transport This chapter contains the following sections: Overview Paper transport subsystems Paper transport control pads Adjusting the paper transport system Defining substrate type Loading a substrate Adjusting the input tray Adjusting the double feed sensor Adjusting the conveyor belts Adjusting the front static guide and rear jogger Testing the substrate transport system Sample tray configuration...
  • Page 151: Overview

    90 to 350 g/m (60 lb text to 130 lb cover) uncoated papers 80 to 300 g/m (55 lb text to 130 lb cover) plastics (types qualified by HP Indigo) — transparencies (types qualified by HP Indigo— — must include a non-transparent edge)
  • Page 152: Grain Direction

    Duplex placement accuracy Range of point on back 0.8 mm (0.03 inch) 0.8 mm (0.03 inch) 0.4 mm (0.015 inch) Point on front Maximum back-to-front point deviation—0.4 mm (0.015 inch) Figure 11-1. Duplex placement accuracy Grain direction For duplex or simplex printing, use long-grain sheets for paper types lighter than 170 g/m (115 lb text/63 lb cover).
  • Page 153: Grippers

    Sheet alignment ensures cross-run registration. When properly adjusted, the image is placed in the same position in relation to the leading edge and the top left corner of the sheet on all of the printed sheets in one press run. Grippers The grippers hold the paper sheet firmly during the printing process.
  • Page 154 reverse inch the paper feed unit (elevator and conveyor only) move the paper elevator up and down Elevator Up Paper Feed Elevator Cont. Inching Forward Elevator Down Inching Reverse Figure 11-3. Main tray paper feed unit control pad You can move the elevator in continuous mode by pressing the Elevator Cont. button, while pressing the Elevator Up or the Elevator Down buttons.
  • Page 155: Press

    adjust suction finger flow rate adjust front and side blowers flow rate adjust trailing edge blower flow rate Trailing edge blower Side and leading edge blowers Suction fingers flow rate Figure 11-5. Blower suction flow rate control pad] Double feed sensor control pad Use the double feed sensor control pad to control the following movements: adjust double feed sensor inch (paper feed unit only)
  • Page 156: Adjusting The Paper Transport System

    Exit control pad Use exit control pad to control the following movements: light the exit area inch (press and paper feed unit) lift the paper tray lower the paper tray Light switch Inching Lift up Lift down Figure 11-8. Exit control pad Adjusting the paper transport system At your workstation You can control the paper transport system through the press software interface.
  • Page 157: Paper Path Adjustments

    On the control panel, click the Maintenance menu, and then select Transport. The Substrate transport window opens. Figure 11-9. Substrate transport window Define all paper transport settings to test the paper transport system in any desired configuration. Note Feeding the substrate is cannot be performed in the inching mode. Paper path adjustments Adjust the paper transport subsystems in the order they appear in this guide: beginning with the input paper tray and ending with the exit tray.
  • Page 158: Defining Substrate Type

    front side blower (height and blowing adjustment) top paper guides double feed sensor (adjustment to paper thickness or weight) conveyor belts placement first friction wheels placement metal strips placement rear jogger placement front static guide adjustment Exit unit The exit unit requires the exit elevator to be in the up position. Defining substrate type Before you start loading a substrate, define the type of substrate on the press.
  • Page 159: Loading A Substrate

    Click the Machine Parameters tab. Figure 11-11. Substrate window, Machine Parameters tab If you do not want to automatically use paper to clean the blanket, select the Bypass Cleaner Page check box. Select this option when paper is limited or costly. In the PFU Rate (Impr per hour) section, select 4000, unless printing a simplex monochrome job.
  • Page 160 Remove the paper tray base plate. Trailing edge Figure 11-12. Paper tray base plate On the underside of the paper tray, loosen and release the butterfly screws. Butterfly screws Slide butterfly screws to adjust to base plate size Trailing edge Figure 11-13.
  • Page 161: Loading A New Substrate In The Main Tray

    Loading a new substrate in the main tray On the control panel, click Standby. The press changes to the Standby state. On the feed control pad, press the Elevator Down button to lower the paper tray (see Figure 11-15). Release the Elevator Down button to stop the elevator. Turn the stack centering knob counterclockwise to allow more space between the side guides.
  • Page 162: Adjusting The Input Tray

    Lift the side guide lock handle to release the side guide. Stack height adjustment Trailing edge paper Trailing edge knob guide blower Trailing edge blower valve Vacuum valve Leading edge and side blowers valve Side guide lock Paper guide frame handle Figure 11-16.
  • Page 163: Adjusting Paper Tray Guides

    Check that all sheet separators form a 90° angle between the sheet separator and its bracket. If needed, replace a sheet separator. See ‘Replacing the sheet separators on the Paper Feed Unit’ on page 181. Sheet separator 90° angle Sheet separator bracket Sheet separator set screw...
  • Page 164: Adjusting Suction And Blower Flow Rate

    Lower the paper guide frame. Top paper guides Adjustment knobs Front guide adjustment knob Rear guide Side springs Trailing edge guide Trailing edge blower Figure 11-19. Paper guide frame Adjust the rear guide position until it touches the paper and supports the stack. Adjust the front paper guide frame side spring bar.
  • Page 165: Adjusting The Top Paper Guides

    For substrate heavier than 135 g/m (90 lb text/50 lb cover), turn the vacuum knob one click clockwise. For substrate lighter than 135 g/m (90 lb text/50 lb cover), turn the vacuum knob one click counterclockwise. Check that the top sheet floats and touches all sheet separators evenly without flexing.
  • Page 166 Turn the double feed sensor adjustment screw clockwise to feed heavy stock. Place folded sheet here, Double-feed sensor housing above plate and under first friction wheels Figure 11-21. Double feed sensor Fold one sheet across its long axis. Place the sheet on the feed conveyor next to the double feed sensor. Double feed adjustment knob Inching Forward Inching Reverse...
  • Page 167: Adjusting The Conveyor Belts

    Adjusting the conveyor belts Conveyor belts carry paper from the paper elevator to the printing nip. You can adjust the belts to the width of the sheets. Distribute the belts evenly across the sheet width to ensure a smooth transport. Conveyors belts Rear jogger Ball drive...
  • Page 168: Adjusting The First Friction Wheels

    Move the belt holder to the desired position on the conveyor underside. Turn knob to adjust belt placement Figure 11-25. Conveyor belt holders (conveyor underside) On both the feed and exit sides of the conveyor, pull the belt to the desired position. Verify that the belts are evenly distributed across the sheet and that all the belts are parallel to each other.
  • Page 169: Adjusting The Front Static Guide And Rear Jogger

    Adjusting the front static guide and rear jogger The rear jogger pushes the sheet against the front static guide to ensure cross-run registration. It pushes the sheet as it is aligned against the head stopper. Adjust the front static guide and the rear jogger so that the sheet is aligned to the center of the press. The press is equipped with a scale to facilitate sheet alignment.
  • Page 170 Take a sheet of paper from the Paper Feed Unit input tray, and fold it in half, and crease it near one end. Crease Insert into Paper Feed Unit input tray, creased side first Figure 11-29. Fold paper in half, along its long axis, to crease it Insert the creased paper into the Paper Feed Unit, creased side first.
  • Page 171 You have a choice of three different flat springs to use, depending on the tension desired: • Soft – up to 135 g/m (90 lb text/50 lb cover) stock paper • Medium – 135 to 250 g/m (90 lb text/50 lb cover to 94 lb cover) stock paper •...
  • Page 172: Testing The Substrate Transport System

    21 Repeat steps 6 through 8. Verify that the paper feeds past the flat spring of the front static guide, make sure that there is a gap of 2 mm (0.078 inch) between the paper and the tip of the spring. 2 mm (0.078 inch) gap Front static Paper...
  • Page 173: Front-To-Back Registration

    Select the following Transport Parameters: • In the Feed section, select On. • In the Speed section, select Normal. • In the Separation section, select Multi separation. • In the Duplex section, select Simplex. Figure 11-33. Substrate Transport window Click Run. The press streams the substrate. To stop the press, click Stop. Watch the sheets behavior.
  • Page 174 Shift side 2 to align with side 1. Figure 11-34. Image Placement tab Adjust the deviation according to your measurement. Figure 11-35 shows the image movement in relation to the printed sheet. Click Center to centers the image in relation to the sheet. Select the Joined check box to shift the image so that both sides of the sheet are parallel.
  • Page 175: Sample Tray Configuration

    Sample tray configuration The Sample Tray window provides you with new options for configuring the handling of substrates. Click Consumables, Substrate, and select the Sample Tray tab to open the Sample Tray window, Select to print more than one copy to the sample tray.
  • Page 176: Accessing The Impression Drum Area

    It is possible to proof more than one copy to the sample tray. Click Options, and Press Configuration to obtain the Press Configuration window. Select Job Handling, and Default Parameters to obtain the window containing the Proof Properties panel. Select to proof more than one copy to the sample tray Figure 11-37.
  • Page 177: Clearing Paper Jams

    Impression drum Figure 11-39. Impression drum access Clearing paper jams When a paper jam occurs, the system warning indicator appears in the control panel. A warning symbol appears in the schematic window indicating the paper jam location. WARNING! Press an Emergency Stop button before performing this procedure. On the control panel, click the warning symbol.
  • Page 178: Maintaining The Paper Transport System

    • Gripper never opened, or Gripper never closed Remove jammed paper from the press. Run the paper transport and check its operation. Note When any service door is opened, the press state automatically changes to Hold. After completing any of the above procedures, close all the doors. If necessary, immediately click Get Ready on the control panel to reset the system (return it to its home position).
  • Page 179 Figure 11-40 through Figure 11-46 show the paper monitoring sensors. Gripper sensors Skew and Intermediate rotor jam (upper/lower) encoder sensors sensor Duplex conveyor jam sensor Perfector jam Sample tray sensor sensor 1 Exit tray sensor Perfector jam sensor 2 Figure 11-40. Overview of sensor locations Sensor TWISTER-358 Figure 11-41.
  • Page 180 Figure 11-43. Perfector jam sensors Jam sensor (behind this plate) Rotor Figure 11-44. Intermediate rotor jam sensor Sensor Figure 11-45. Exit tray sensor Maintaining the paper transport system 179 ENWW...
  • Page 181 Sensor Figure 11-46. Sample tray sensor Skew sensor Encoder sensor Figure 11-47. Encoder and skew sensors Upper gripper sensor Lower gripper sensor Figure 11-48. Gripper sensors 180 Chapter 11 Paper transport ENWW...
  • Page 182: Cleaning The Paper Transport Rollers

    Cleaning the paper transport rollers Paper transport rollers can get covered with paper dust and lose their ability to transport paper efficiently. Rollers should be cleaned using IPA. Clean rollers weekly or whenever you suspect a paper delivery problem. Clean the following rollers: paper feed rollers –...
  • Page 183 Press the Elevator Down button on the Paper Feed Unit until you can easily see the sheet separators. Open the paper feed unit main door. The sheet separators are attached to the front ruler. Suction fingers Sheet separator protruding tongue Feed roller Sheet separator Sheet separator bracket locking...
  • Page 184: Removing Paper Jammed Under Cleaning Station

    Set the new sheet separator so the protruding tongue is in the middle of the bracket’s slot, between the top notch and the one below it. Set sheet separator protruding tongue in the middle of the slot Set sheet separator protruding tongue between the second and third notch Figure 11-54.
  • Page 185 Press an Emergency Stop button. Open the front door and upper feed door. Open the ITM hood and lift input paper conveyor. Upper feed door Input conveyor Front door Figure 11-56. Press doors Remove the ITM hood. See ‘Removing the ITM hood’ on page 131. Stand facing the front door, hold the cleaning station blade knob, and remove the blade.
  • Page 186 Disconnect the cleaning station connector. PIP drum Cleaning station connector Cleaning station imaging oil inlet ITM drum Figure 11-58. Cleaning station connector On the feed side, lift the cleaning station latch and pull out the cleaning station. Slide the cleaning station along the groove on the press inside walls. Cleaning station groove Cleaning station...
  • Page 187: Removing Paper Shreds Under The Air Knife

    Insert the cleaning station. Slide the cleaning station studs into the cleaning station grooves on the press inside walls. Cleaning station studs Figure 11-60. Cleaning station (facing the PIP) Lock the cleaning station latch. Replace the ITM hood. Insert the side facing the rear wall first. See ‘Removing the ITM hood’...
  • Page 188 Disconnect the air knife connector. Number 5 electrical connection Air knife latch Number 4 air hoses Figure 11-61. Air knife Disconnect both air hoses. Disconnect the electrical connector. Press the air knife latch and pull the unit out. You can now access the PIP. Remove any loose paper shreds. PIP surface (check this area for paper shreds)
  • Page 189 188 Chapter 11 Paper transport ENWW...
  • Page 190: Impression Drum

    Impression drum This chapter contains the following sections: Overview Replacing the impression paper ENWW...
  • Page 191: Overview

    Overview The impression drum creates pressure on the substrate against the ITM drum to allow transfer and to carry the sheet from the input tray to the exit tray. The sheet is held firmly by the grippers throughout the one to six press revolutions of the printing process. The impression paper protects the drum from ink.
  • Page 192 On the Maintenance menu, select Gripper Cleaning. The Grippers Cleaning window opens. Figure 12-1. Grippers Cleaning window Advance the press using the handwheel until you see the grippers and impression paper holder. You can reach the impression drum from the input side at this angle. Loosen the two low head screws in the front of the impression paper holder, and pull out the old impression paper.
  • Page 193 On a new impression paper, remove all the paper knock-outs. Knock-outs removed Gripper window (lower side) L mark faces user when paper is installed Figure 12-3. Knock-outs removed Loosen the special low head screws two turns using a 3-mm Allen key (Figure 12-2), and insert the impression paper with the L mark shown on the left side of the impression paper, facing you.
  • Page 194: Imaging Oil

    Imaging oil This chapter contains the following sections: Overview Imaging oil filters Imaging oil cleanness sensor ENWW...
  • Page 195: Overview

    Overview The press uses imaging oil as the base carrier for the ink pigment particles. Because only pigment particles stay on the printed sheet, the press constantly monitors the relationship of imaging oil to ink pigments. The ink cans supply the ink pigments and the imaging oil tank supplies the imaging oil.
  • Page 196: Refilling The Imaging Oil Tank

    Refilling the imaging oil tank The imaging oil tank has a capacity of about 15 liters. The imaging oil tank supplies the ink tanks and the cleaning station with fresh imaging oil. Once the imaging oil tank level drops below 10 liters, the system displays the following message. clean imaging oil level is too low Do not fill the tank while the press is printing.
  • Page 197: Replacing The Imaging Oil Filters

    Pour in the contents of one 4 liter (1.06 gallon) imaging oil container. Figure 13-4. Four liter imaging oil container Replace the imaging oil tank cap on and then close it. Close the imaging oil tank door. Replacing the imaging oil filters The press contains two imaging oil filters connected in a row.
  • Page 198 There are two imaging oil filters. Remove the one on your right first, and then remove the one on your left. Fit the filter extractor over the filter. Figure 13-5. Filter extractor Tighten the filter extractor over the filter. Remove first, mount second Remove second, mount first...
  • Page 199 Drain the filters in accordance with your local waste disposal regulations. See ‘Disposing of consumables and cleaning materials’ on page 34. Figure 13-8. Remove filter on the left Mount the left filter first, and then the right one. Make sure the rubber gasket is in place.
  • Page 200: Imaging Oil Cleanness Sensor

    Imaging oil cleanness sensor Clean the imaging oil sensor to ensure a precise imaging oil cleanness reading. Before you perform this procedure, make sure to have a clean cotton swab available. Perform the following procedure monthly: Press an Emergency Stop button. Open the rear press door.
  • Page 201 To remove the mounting bracket, loosen the screw which holds it, slide the bracket toward you, and lift it up. Mounting screw Figure 13-11. Removing the cleanness sensor mounting bracket Clean both sensor faces on the printed circuit board. Sensor faces Cotton swab Figure 13-12.
  • Page 202: Cleaning Station

    Cleaning station This chapter contains the following sections: Overview Cleaning the cleaning station blade Rotating and replacing the cleaning station blade Sponge roller replacement ENWW...
  • Page 203: Overview

    Overview The press cleaning station is located behind the front door, next to the PIP drum (see Figure 14-2). The cleaning station cools the PIP and cleans it after the first transfer. It does this by wetting the PIP with imaging oil and removing the ink debris with a flexible blade.
  • Page 204 Remove the cleaning station blade holder. Cleaning station blade holder Handwheel Figure 14-2. Remove the cleaning station blade (behind the front door) Clean the wiper with a lint-free wipe soaked in imaging oil. Cleaning station blade Figure 14-3. Wipe the cleaning station blade Cleaning the cleaning station blade 203 ENWW...
  • Page 205: Rotating And Replacing The Cleaning Station Blade

    Replace the cleaning station blade. Mount the cleaning station groove on the rail. If the blade is not inserted completely when the press system tries to change to the Ready state, the following message appears: Blade is not in place or unlocked Make sure that the cleaning station blade is completely inserted.
  • Page 206 Hold the cleaning station blade housing and press the metal bars, as shown in Figure 14-5. This releases pressure on the blade. Pull the blade out. Cleaning station blade Blade edge number Press here to remove or insert Cleaning station knob a cleaning station blade Figure 14-5.
  • Page 207: Removing The Cleaning Station

    Removing the cleaning station Press an Emergency Stop button. Open the front door and upper feed door. Open the ITM hood and lift the input paper conveyor. Upper feed door Input conveyor Front door Figure 14-7. Press doors Remove the ITM hood. See ‘Removing the ITM hood’ on page 132. Stand facing the press front door, hold the cleaning station blade knob and remove the blade.
  • Page 208 Disconnect the cleaning station connector. PIP drum Cleaning station connector Cleaning station imaging oil inlet ITM drum Figure 14-9. Cleaning station connector At the feed side, lift the cleaning station latch and pull out the cleaning station. Slide the cleaning station along the groove on the press inside walls. Cleaning station groove Cleaning station latch Cleaning station...
  • Page 209: Installing The Cleaning Station

    Installing the cleaning station Insert the cleaning station. Slide the cleaning station studs into the cleaning station grooves on the press inside walls. Cleaning station studs Figure 14-11. Cleaning station (facing the PIP) Lock the cleaning station latch. Connect the cleaning station connector to the cleaning station. Replace the ITM hood.
  • Page 210 Remove the timing belt. 3-mm Allen screw Front locking plate Timing belt Figure 14-13. Timing belt, 3-mm Allen screw, and front locking plate Remove the old sponge roller by pulling the roller to the right, and then forward. Install the new sponge roller. Slide the roller into the housing assembly, right side first.
  • Page 211 Push the roller as indicated to fit it into the left end cap. Push roller as indicated to fit it into the left end cap Figure 14-15. Fitting sponge roller into the housing Place the roller so that its slots sit on the housing. Re-install the front locking plate and the 3-mm Allen screw.
  • Page 212: Scorotron

    Scorotron This chapter contains the following sections: Overview Scorotron maintenance procedures ENWW...
  • Page 213: Overview

    A periodic check of the corona - left, central, right, HVPS current failed Try printing again, if happens again call HP. 212 Chapter 15 Scorotron ENWW...
  • Page 214: Replacing The Scorotron Corona

    Replacing the scorotron corona Replace the scorotron corona when you clean or replace the corona wire and the corona grids in the scorotron unit. When replacing the corona wire, also replace the scorotron damper. Note The corona wire is advanced automatically to expose new wire after 4500 to 6000 impressions. Before performing this procedure, make sure you have the following items: Corona bobbin with wire Empty PVC bobbin...
  • Page 215 Remove the grid by pressing the springy grid latch towards the grid, releasing it from the fixed hook and releasing the latch Grid latch Bobbin cover with a Phillips screw Grids Fixed hooks Figure 15-3. Scorotron unit Slide one of the grids out. Release it from the fixed hook on the other end, and then slide it all the way out Figure 15-4.
  • Page 216 13 Use the following procedure to set the wire in the path (see Figure 15-5): Pass the wire from the supply bobbin through the tension pulley at the other end of the unit (not shown in figure). Route the wire over the pulley (1), under the guide (2), and over the plastic damper (3).
  • Page 217: Replacing The Damper

    Replacing the damper Perform the following procedure after replacing a corona wire. Remove the scorotron unit. Remove the grids. Remove the bobbin cover. Release the Phillips screw, removing the damper clamp and the damper. Phillips screw Damper clamp Damper Figure 15-7. Scorotron dampers Discard the damper.
  • Page 218: Maintaining The Scorotron

    Troubleshooting One of the following error messages might appear after you maintain the scorotron: A periodic check of the corona_# HVPS current failed Try printing again. If happens again, call service A periodic check of the grid_# HVPS current failed Try printing again.
  • Page 219 218 Chapter 15 Scorotron ENWW...
  • Page 220: Binary Ink Developer (Bid)

    Binary ink developer (BID) This chapter contains the following sections: Overview Replacing the BID Reusing the BID unit Adjusting the BID to the PIP pressure Adjusting the BID engage and disengage angle Press long-term shutdown maintenance Bellows position BID troubleshooting BID Washer Cleaning the ink tank...
  • Page 221: Overview

    Overview The press uses binary image development (BID) in the image generation process. The press builds ink inside the BID and transfers the ink to the image areas on the PIP. The excess ink flows inside the BID and out to the ink tank. Each BID participates in the generation of a different separation, although the units are identical.
  • Page 222: Replacing The Bid

    Replacing the BID Replace the BID station when the following occurs: image quality deteriorates change of ink color is required Before you start this procedure, make sure that you have the following items: A new BID BID stand 3-mm Allen key Lint-free wipe Imaging oil Diagnostics...
  • Page 223: Removing The Bid Unit

    Click the Inks Preparation start button, and wait a few minutes until the ink parameters are adjusted. Click here Figure 16-3. BID Diagnostic Wizard – Inks Preparation window Click Next after the ink parameters are adjusted. After the test is completed, the results will show in the status bars. The test may take a few minutes.
  • Page 224 On the Consumables menu, select BID Units and Dry. The BID Units window opens. Select this check box to dry Click here to start clean the Black BID, for the manual BID example cleaning procedure Figure 16-5. BID Units window Click the Dry BID Units tab.
  • Page 225 Use the following procedure to remove the BID ink supply assembly: Release the set screw. Pull the ink supply latch to the right. Hold the ink supply assembly and pull it out. Ink inlet Set screw Ink supply latch Ink outlet Figure 16-7.
  • Page 226: Installing The Bid Unit

    13 Place the BID on the BID stand. Figure 16-9. BID stand Installing the BID unit Remove the new BID unit from its case and place it on the packaging provided, or on a BID stand. The developer roller is wrapped with a protective paper sheet fastened with adhesive tape.
  • Page 227 If a BID washer is available, use it to clean the BID. If not, use a lint-free wipe soaked in imaging oil to wipe the surface of the developer roller. Keep rotating the developer until its surface is clean. CAUTION Do not handle the BID by its motor, which may be hot.
  • Page 228: Registering Bid Replacement

    Note The newly installed BID will automatically rotate for three minutes after installation after the press is turned on. This process, called BID conditioning, prepares the BID for printing. Registering BID replacement Release the Emergency Stop button. In the control panel, click the Consumable menu, and then select BID Units. The BID Units window opens.
  • Page 229: Returning The Bid

    Perform the Custom Color Adjust wizard and include the Velectrode calibration procedure. 10 Return old BIDs to HP Indigo in accordance with the information provided below. The BID Return form which came in the BID package should be completed and mailed back to HP Indigo.
  • Page 230: Reusing The Bid Unit

    Fill the BID Return Feedback Form and attach it with the BID. Insert the container in the box. Return the box to HP Indigo using the Return Materials Application (RMA) procedure. Reusing the BID unit Store the BID unit for future use when you replace an ink.
  • Page 231: Adjusting The Bid To The Pip Pressure

    Place the BID unit on the BID stand (or on the specially designed BID holder provided with new BID units). Insert a 3-mm Allen key into the Allen bolt and turn it clockwise. See Figure 16-18. Using a lint-free wipe soaked in imaging oil, wipe the surface of the developer roller and squeegee roller.
  • Page 232 12 On the Diagnostics menu, click BID. The BID window opens. 13 Select the required color and click Engage. Check that the BID unit actually engages and disengages. If the BID does not disengage from the PIP drum, contact your customer engineer.
  • Page 233: Adjusting The Bid Engage And Disengage Angle

    Adjusting the BID engage and disengage angle During printing the BID unit presses against the PIP, and then disengages. The BID to PIP engagement duration must be sufficient to cover the maximum image length (437 mm, 17.2 inches). Each BID unit should be adjusted individually because the BID angular position varies from one unit to another other.
  • Page 234: Adjusting Bid Engage/Disengage

    Adjusting BID engage/disengage On the control panel, click the Adjustments menu, and then select BID Engage. The Calibrate BID Engage/Disengage window opens If the leading edge is uneven, select the Engage - check leading edge check box. If the trailing edge is uneven, select the Disengage - check trailing edge check box. If both Leading and Trailing edge are uneven, select both check boxes.
  • Page 235 Click Print. Two BID engage test jobs are printed. Evaluate the first copy. The Analyze window opens. Value field Do not enter this value Enter this value In the Analyze window, enter the higher value of the adjusted BID color bar Figure 16-25.
  • Page 236 When adjusting the trailing edge, enter the value of the shortest bar. The lower value is for the bar edge, which is closest to the sheet center. In the Analyze window, enter the higher value of the adjusted BID Do not enter this value Enter this value Figure 16-27.
  • Page 237 Evaluate the first copy. Color bars of the same length (437mm, 17.20 inches) indicate correct engage calibration for all the BID units. Color bars of the same length (437mm) are an indication to a well adjusted BID engage/disengage 437mm (17.2 inches) Figure 16-28.
  • Page 238: Correcting An Inkless Spot On The Leading Edge

    Correcting an inkless spot on the leading edge Use the BID engage calibration to change an inkless spot in the 25 mm (1 inch) strip at the leading edge. 10 mm (0.39 inch) 25 mm (1 inch) Leading edge Remove an inkless spot in this area Trailing edge...
  • Page 239: Press Long-Term Shutdown Maintenance

    Press long-term shutdown maintenance Remove the BID units from the press to avoid BID deterioration when the BIDs are not in use. Clean the developer and squeegee rollers. Perform the following procedure on all BID units. A long-term shutdown is defined as more than four days. WARNING! Electrical and mechanical hazard: Before performing this steps, press an Emergency Stop button.
  • Page 240: Bellows Position

    Bellows position Make sure the BID bellows are positioned correctly. Incorrect positioning can hinder the rate of ink flow. Do not stretch the bellows. Figure 16-32. Correct Figure 16-33. Incorrect Full ink coverage may not be achieved if the ink bellows is not straight. If you do not obtain full ink coverage of the image and the BID engage screw is turned clockwise all the way, contact your customer engineer.
  • Page 241 Use the following table to analyze and troubleshoot BID problems. Problem / Symptoms and solutions Resultant image Reason for replacement Partial coverage No image at leading or trailing edge: Perform a BID Engage Calibration wizard. No image at the front or rear side: Check the ink coupling bellows tension.
  • Page 242 Problem / Symptoms and solutions Resultant image Reason for replacement Image memory Ghosting occurs: LEADING EDGE Perform this check in a single color at 100 percent coverage. If ghosting occurs in more than one color, then the problem is probably not related to the BID.
  • Page 243 Problem / Symptoms and solutions Resultant image Reason for replacement Banding – Thick horizontal line repeats in cycles of horizontal lines 133, 53, and 33 mm (5.24, 2.09, and 1.3 inches): Check the BID connector. Replace the BID. Call customer engineer if the problem persists Streaks (mostly Vertical lines along the print black ink...
  • Page 244 If you follow all instructions, and error messages still appear, call HP Indigo customer service. Note Some print quality problems may not be BID related. To isolate the problem, make sure that all process parameters are set at the correct values and all process subsystems are adjusted and calibrated.
  • Page 245: Black Bid Cleaning Procedure

    Black BID cleaning procedure Waste may occasionally accumulate in the black BID. This may cause streaks on the printed page, as shown in the example shown in Figure 16-34. Leading edge Figure 16-34. Streaks on print Follow the procedure, ‘Removing the BID unit’ on page 222, to remove the black BID. Perform the BID dry cleaning procedure on the black BID before removing it.
  • Page 246 Hold the BID cleaning foil with the adhesive strip facing down and towards the developer roller. Figure 16-36. BID cleaning foil Attach the foil to the center of the BID developer roller. Use a 3-mm Allen key to rotate the BID developer roller one rotation towards you. Wipe waste from the roller as you rotate it.
  • Page 247: Checking Ink Flow

    Lift up the adhesive strip, and pull off the cleaning foil as you rotate the developer roller. Figure 16-38. Removing the cleaning foil 10 After the cleaning foil is removed, rotate the developer roller, and clean it. Reinstall the black BID (refer to the section ‘Installing the BID unit’ on page 225, for details).
  • Page 248 Click the Flow Detection button. Figure 16-40. Ink Flow Calibration – Adjust Ink Flow window Open and close the valve until the bar is in the center of the green area. The location of the valve is described below, under ‘Setting the ink pump flow rate’ on page 248. Opening the flow valve will shorten the flow time, and closing the flow valve with lengthen it.
  • Page 249: Calibrating Ink Density Using An External Densitometer

    10 In the Inks Properties window, turn the pump off. Setting the ink pump flow rate Ink flow rate is controlled by the ink pump valves. They are located behind the ink cans (see Figure 16-42). Rotating a valve counterclockwise opens the valve and increases the ink flow.
  • Page 250: Manual Bid Control

    When the conductivity level is too high, refer to the section ‘Decreasing ink conductivity’ on page 107. Note If ink conductivity keeps rising above 110 pmho/cm, call your HP Indigo service center. Manual BID control The BID may be manually engaged and disengaged using the window shown below. Do not use this window for testing other BID functions, but rather, use the BID Diagnostic Wizard.
  • Page 251 Note Never wipe the developer roller with a dry wipe, as you will scratch it. Connect hoses to the BID simulator. Latch the BID simulator into place. Filter Figure 16-44. Fast ink replacement filter The fast ink replacement filter is attached as shown in Figure 16-45. The BID ink pump is activated, and is allowed to run for ten minutes.
  • Page 252: Procedure For Activating Bid Ink Pump

    Procedure for activating BID ink pump From Consumables, click Install Ink. From the Ink Installation Manager window, click Ink Replacement. Figure 16-46. Ink Installation Manager – Ink replacement window Click Ink Replacement, and the Ink Removing window appears. Put the system in standby, then sequentially step through each of the functions indicated at the top of the window, performing the necessary operations for each one.
  • Page 253 Follow the instructions on the window, then click Start Cleaning to activate the BID pump. Figure 16-48. Ink Removing – Cleaning Cycle window After cleaning out the tank, the BID simulator is removed, and an ink stopper is placed over it. See illustration below. BID latch —...
  • Page 254: Pre-Transfer Erase (Pte)

    Pre-transfer erase (PTE) This chapter contains the following sections: Overview Cleaning the PTE cover ENWW...
  • Page 255: Overview

    Overview The PTE lamp discharges the PIP to enable the recording of a new image (that is the next separation). The PTE lamp is made from an array of LEDs located below the PIP drum, mounted on top of the air knife. BID # 7 PIP drum PTE lamp cover...
  • Page 256 Pull the plastic tab below the PIP. PTE cover Air knife hoses Figure 17-2. PTE cover Clean the PTE cover using a lint-free wipe. If necessary, use IPA. Replace the PTE cover. Close the front door. Release the Emergency Stop button. Cleaning the PTE cover 255 ENWW...
  • Page 257 256 Chapter 17 Pre-transfer erase (PTE) ENWW...
  • Page 258: Blower Cabinet

    Blower cabinet This chapter contains the following sections: Overview Draining the cooler waste Draining the solids air compressor...
  • Page 259: Overview

    Overview The press operates in humid and warm environment. Humid air is condensed in the blower cabinet. A warning message appears when the drain cooler storage is full. Drain the cooler waste whenever the following message appears: Cooler condensation container is full, please drain. Draining the cooler waste Open the drain cooler door.
  • Page 260: Draining The Solids Air Compressor

    Draining the solids air compressor The solids compressor supplies air pressure to inject solid ink from the ink can to the ink tank. Drain the solids air compressor once a week. Before you perform this procedure, make sure that you have a 200 ml (7 oz) or more plastic waste container.
  • Page 261 Water flows into the waste container. Leave the valve open for about one minute. Turn the compressor drain valve counterclockwise. Remove the plastic waste container. Close all the doors. 260 Chapter 18 Blower cabinet...
  • Page 262: Chiller

    Chiller This chapter contains the following sections: Overview Warnings Operating conditions Control panel Maintenance Troubleshooting Chiller timer ENWW...
  • Page 263: Overview

    Contact your local HP Indigo service center for specific inspection and maintenance procedures for the chiller. Note For Orion chillers used in Japan, refer to the Orion chiller user guide, or contact your local HP Indigo service center. Electrical connection The required electrical supply for each version is listed below.
  • Page 264: Operating Conditions

    Operating conditions The control thermostat in the chiller will control it in order to maintain the preset cold water temperature. Water temperature at the inlet: Nominal: 15° C (60° F) Maximum: 30° C (86° F) Cold water temperature at the outlet: Nominal: 10°...
  • Page 265: Control Panel

    7° C (45° F). To be able to reach temperatures below that, contact your HP Indigo service center. Low refrigerant pressure alarm indicator: This indicator is lit when the pressure of the refrigerating circuit is below the minimum allowed.
  • Page 266: Control Thermostat

    Control thermostat During normal operating conditions, the display of the control thermostat shows the cold water temperature measured by the probe. In the 50 Hz version, the display shows the temperature in degrees Celsius, and in the 60 Hz version, it shows it in degrees Fahrenheit.
  • Page 267: Troubleshooting

    If the problem persists, contact your HP Indigo service center. Alarm due to low Gas leakage Contact your HP Indigo The low pressure safety pressure of the service center switch (SLP) refrigerant automatically resets itself when the pressure returns to normal.
  • Page 268: Chiller Timer

    For additional support, please contact your HP Indigo service center. Chiller timer When the time required by the chiller to reach working temperature hinders productivity, you can turn the chiller on before the start of the shift. Use the chiller timer to turn the chiller on before the press is turned on.
  • Page 269: Setting The Timer

    Setting the timer Remove chiller timer cover. Press the transparent cover up and out. Display panel Entire week Days of the week Always on Figure 19-4. Chiller timer control panel (two models) Setting time and day To clear all memory settings, press the following buttons simultaneously: , d, and m.
  • Page 270 If you need to change the time setting, press h and d to set the new time, and then press Deleting a command Press the Prog button to display the command to delete. Press the h and m buttons concurrently, and then press The displayed command is deleted.
  • Page 271 270 Chapter 19 Chiller ENWW...
  • Page 272: Long-Term Shutdown

    Long-term shutdown This chapter contains the following section: Long-term shutdown ENWW...
  • Page 273: Long-Term Shutdown

    Long-term shutdown When the press system is inactive for four days or more, ink waste and dried ink can accumulate in the ink flow system. If the press is going to be inactive, you must first clean and flush the ink flow system. Use the following procedure when you need to shut down the press system for four days or more.
  • Page 274: Glossary

    Glossary This glossary contains terms and definitions found throughout the HP Indigo press 3050 documentation package. Term Definition blanket A fabric coated with natural or synthetic rubber, which is clamped around the blanket cylinder, and which transfers the ink from the press plate to the substrate.
  • Page 275: 21 Glossary

    Term Definition densitometer A device that measures the density and dot size of ink to make certain they are consistent throughout the run. If they are not consistent, it adjusts the press to compensate for deviation. duplex conveyor The conveyor that receives paper from the perfector and transfers it to the grippers in duplex printing.
  • Page 276 A Page Description Language (PDL) created by Adobe® Systems for describing graphic information. print cleaner An HP Indigo press function that cleans the blanket without manual intervention. process The printing from a series of four or more separations in order to produce intermediate colors, shades, and tones.
  • Page 277 A single physical sheet of paper composed of several imposed pages. simplex One-sided printing. spread One side of the printing sheet. writing head An HP Indigo press subsystem composed of laser diodes that defines the image on the PIP. 276 Chapter 21 Glossary ENWW...
  • Page 278: A Parts And Supplies

    Parts and supplies This appendix contains the following sections: Imaging products Operator maintenance parts Special tools and jigs Supplies...
  • Page 279: Imaging Products

    (10 cans) MPS-3125-43 HP imaging oil (4 bottles, 4 liter) MPS-3017-43 HP imaging agent (250 ml) MCH-1651-41 HP impression paper (10) MCH-3032-41 BID unit MPT-1511-57 For use only in HP IndiChrome ink mixing systems. 278 Chapter A Parts and supplies...
  • Page 280: Operator Maintenance Parts

    Operator maintenance parts Description Part number Suction fingers (PFU) MCC-2247-01 Bobbin wire with damper kit MKT-1106-05 Scorotron grid MPX-1998-04 Imaging oil filter (10 microns, diameter 5.1 inches, length 10.7 inches) MFL-1014-01 Cleaning station wiper (length 2 mm [0.08 inch]) MPT-1515-01 PIP underlayer MCH-1490-41 Sheet separator...
  • Page 281: Supplies

    Note For lubricants, contact your local HP supplier. Note For supplies required for the HP IndiChrome ink mixing system, refer to the HP IndiChrome ink mixing system user guide. Note Orders for supplies may be handled through the HP Indigo portal: www.hp.com\go\indigo...
  • Page 282: Index

    Index accessing cabinet, blower 257 impression drum area 175 Calibration job editor 49 machine LUT 74 accessories (list) 280 calibration adding imaging agent 107 full densitometer 81 adjusting ink density 248 BID engage/disengage 233 inline densitometer 80 BID engage/disengage angle 232 press colors 72–...
  • Page 283 38 functions 49 reference guide 37 using 48 hotfolder, configuring 49 job manager window 46 HP Indigo press 3050 jobs 16 jobs annotation 65 archiving 48 changing order of print queue 47 image current print job panel 43...
  • Page 284 printing 56– 60 inline densitometer calibration 80 retained 48 photo imaging plate (PIP) 135– 148 sorting 47 adjusting BID to PIP pressure 230 charging and discharging 18 inking 19 loaded jobs list 47 installing new 140 loading substrate 158 maintenance 72 long-term press shutdown maintenance 238 removing old 136 long-term shutdown 272...
  • Page 285 ink cans and rebuilding ink 102 PIP 136 tables, look-up 62 PIP underlayer 143 testing substrate transport system 171 scorotron corona 213 timer, chiller 267 sheet separator on the Paper Feed Unit 181 setting 268 sponge roller 208 top paper guides, adjusting 164 replenishing transfer to the blanket 20 imaging agent 107...
  • Page 286: B Service And Support

    Service and support To obtain service, please contact the customer care center (CCC) within your country/region: North America Hewlett-Packard Company Indigo Division 550 King Street Littleton, MA 01460 Tel: +1 978 506 7425 Fax: +1 978 506 7417 International Hewlett-Packard Company Indigo Division Limburglaan 5 6221 SH Maastricht...
