4.10.1.1 Voltage sensor type
The example means: 0 mV corresponds to 0 bar, 5 V corresponds to 10
bar.
Mode
unipolar
bipolar
Measuring range
Select a measuring range that is equal to or greater than the signal from
the sensor or signal source to prevent A/D converter overload. The chan-
nel receives the status 'Measurement range overrun/underrun' for
Expert Logger Manual
Januar 2018
: Measuring only positive signals.
: Measuring positive and/or negative signals.
