4.4.2.1 System report
Provides a detailed overview of the system for fault diagnosis by
Support. Send the file to the Support team. The system report can be gen-
erated only through the Web interface.
After clicking
seconds to acquire all the information and record it to a ZIP file. Depending
on your browser settings, the following dialog for example is then dis-
played to select the file save location. The file name is made up of the cur-
rent date and time and the network identifier of the device.
4.4.2.2
PROFIBUS GSD file
The PROFIBUS GSD file is required to configure the device in the
PROFIBUS configuration software of the PROFIBUS Master.
PROFIBUS GSD file
Click
click and select Save as from the context menu to save the file and to
enable it to be copied to a PC with your PROFIBUS configuration program.
The saved bitmaps optional for correct graphical representation of the
device in the PROFIBUS configuration program.
The following is an example of a GSD file (only the beginning is shown):
Delphin Technology AG
System report
to display the GSD file in your browser. Right
Download the GSD file via the Web interface or copy it from the /firm-
ware directory of the installation CD.
, the device requires approximately 15
