Expert Logger
Main settings for user-defined input channels are given using the two tabs:
1. Main settings tab
Contains settings for the data type and the scaling of received data.
2. Input tab
Contains settings for receiving frequency, poll string and decoding (fil-
tering) of received data.
The other tabs contain standard settings. Refer also to
logues
.
Main settings tab
Use this tab to set how received (user) data is to be converted into a meas-
urement value. Use the
be converted (by setting filter and offset).
Delphin Technology AG
Input
tab if not all the characters/bytes sent are to
232
Settings for all dia-
Expert Logger Manual
Januar 2018
