Expert Logger
Protocols
RS 232/485
CAN
TCP/IP
Dimensions/weight
Mounting
Signal connections
Temperature range
Supply voltage
Power input normal operation
Power input sleep mode
Backup battery
Display
Type
Resolution
Colour depth
Touch
Backlight
3 LEDs red/green
Power LED blue/red
Ethernet
Delphin Technology AG
Modbus RTU
SCPI
ASCII
CAN Raw
Delphin CAN Protocol
Modbus TCP
OPC UA Server
General technical information
210 mm x 80 mm x 125 mm/750 g
Mounting rail DIN EN 60715 or screw fastening
Pluggable screw terminals
96 terminals in 2 series
Conductor cross-section max. 1.5 mm²
-20 ... 50°C
12 ... 24 VDC / ± 10%
max. 10 W
5 mW @ 12 V, 10 mW @ 24 V
Lithium battery 3V Varta CR-2450
Lifespan: 10 years
LC display
320 × 240 pixels
18 bit
Resistive
Brightness adjustable
LEDs
Function customer-programmable
Identification/voltage OK/undervoltage/overvoltage
Link, speed, traffic
272
