value is exceeded. You can reduce the number of values which are dir-
ected into a memory group.
You can specify the tolerance in the electric unit of the channel or as a per-
centage in relation to the signal's scaling. In the example, values are only
output if they deviate from the previously output value by more than 1 mV.
4.11.27

Trigger

This software channel uses the signal of an (analogue) source to generate
a logic signal for further processing. Its output is active ("On") after a trig-
ger event (
(both)
). With
Every low
Refer also to
Expert Logger Manual
Januar 2018
High level Low level
,
Every high
, every value unequal to 0 is a trigger, and with
, every value equal to 0 is a trigger.
Trigger options
Rising edge Falling edge
, ,
.
171
Edges
