Expert Logger
8. Enter the IP address of the device in the dialogue, for example,
192.168.251.252.
9. If the device's User management is enabled, enter your login data under
Username and Password.
10. For time signals and spectra, you have the option to compress acquired
measurement values. Compression reduces memory requirements sig-
nificantly and comes with losses.
Note: Compression can cause the min/max characteristic values to not
exactly match the time signal or spectrum.
11. Click OK to create the connection.
12. While you have a connection, set your device address to an IP address that
is suitable for your network, as described above. However do not forget to
reset your PC to the original address.
Offline configuration
If you want to work with a saved
Add Delphin device and your device type.
Delphin Technology AG
Configuration
offline, select Connect
