range overrun" or "scale range underrun" when not within the range. Chan-
nel status values are available in the table in
166
.
feed voltage
The
data. Where possible, enter the maximum voltage in the nominal range of
the sensor's feed voltage.
4.10.2
Configuring digital inputs
Refer also to
Your device has ports that can be used only as digital inputs and ports that
can be used both as inputs and as outputs. As long as you choose
input
as
Method for digital inputs
1. Specify the logical level for the input (normal or inverted).
2. Indicate which replacement value is to be used if the input fails. Refer to
"Additional settings tab" on page 48.
3. Sets how the input should be used: for counting or for frequency meas-
urement.
Main settings tab
Expert Logger Manual
Januar 2018
graphic display area. The channel receives the status "scale
is based on the sensor's values specified in the technical
Settings for all dialogues
mode
for these ports, these are identical to the pure inputs.
"Status monitoring" on page
Galvanic isolation
,
105
digital
