Expert Logger
Gateway
The views and functions for setting the gateway correspond to those for set-
ting the IP address (see above).
Note: A gateway address is required only if connections are to be estab-
lished to other networks.

4.3 Configuring and operating the display

In addition to the network configuration described in the previous Section,
various additional information is available via the navigation area at the
top right of the device display, which is described in this Section.
Homescreen
Tap the top
Configure the lines shown here in System
figurator, see
Channel view
Tapping the
channel contents:
Delphin Technology AG
right hand corner to call up the start (home) page:
Display
. Seven lines can be displayed.
icon takes you to a view containing the current device
→
Display in DataService Con-
32
Expert Logger Manual
Januar 2018
