Expert Logger
Method for digital inputs
1. Specify the logical level for the input (normal or inverted).
2. Indicate which replacement value is to be used if the input fails.
3. Specify whether it requires dependent channels to enable further eval-
uation. Most of the calculations which are also present in the software
channels are available to you.
4.10.1 Analogue inputs (
Refer also to
Method
1. Specify the sensor type and sensor measurement range settings in the
Propertiescontext menu of the respective inputs. Configuration options in
the Main settings tab of the dialog depend on the sensor type, and are
explained in the following separate sections:
2. If necessary, enter on the Sensor compensation tab a characteristic curve
correction, see "Sensor compensation tab" on page 50.
3. Specify on the Additional settings tab replacement value, validity range
and data reduction, see "Additional settings tab" on page 48.
4. Check whether, on the Advanced settings tab, you need to enter inform-
ation, for example, for monitoring the signal, see Advanced settings tab.
