Status monitoring
This software channel monitors the source and becomes active (switches
to " On" ) when the source assumes the specified status.
Refer also to
Available status functions and their meaning
Selection
Wire break
Configuration
error
Invalid value
Measuring
range over-
run
Measuring
range under-
run
Hardware
error
Simulated
Delphin Technology AG
End of a trigger block (data storage).
The source channel value cannot be processed, there is a
parameter error. Check the parameters specified.
When a channel is used for a calculation and the input sig-
nal of that channel depends on the calculation, there is a
loop and thus a recursion. The
nises this; the calculation is terminated and this status is
set.
An analogue or digital input or output is overloaded. For
example, the power source for a Pt100 sensor may be
overloaded at one input. The load resistance could be too
small at one output, resulting in an excessive current.
Status filter Status generator
,
Wire break in monitored channel.
Error in monitored channel configuration.
Invalid value in monitored channel.
The measured value is outside the (positive) measuring
range of the A/D converter, that is, it is too high in the pos-
itive range.
The measured value is outside the (negative) measuring
range of the A/D converter, that is, it is too high in the neg-
ative range.
Error in the hardware, please contact the service of
phin
.
An internally generated value for testing, for example
