Delphin Expert Logger Manual page 164

Expert Logger
Selection
run
Hardware
error
Simulated
value
No number
(NAN = Not A
Number)
Infinite value
(INF = infin-
ity)
Inactive
Scale range
overrun
Scale range
underrun
Trigger block
end
Input value
outside the
(permissible)
range
Recursion
Overload
Delphin Technology AG
ative range.
Error in the hardware, please contact the service of
phin
.
An internally generated value for testing, for example
from the PROFIBUS.
A calculation has not returned a valid number, for
example root of negative numbers.
A calculation is infinite, for example division by zero.
This is set when a channel that is output, calculated or
used in any other way is not active at the start of a meas-
urement. Thus, you can see at run time which channels
are inactive.
Scaling range exceeded.
Scaling range not met.
End of a trigger block (data storage).
The source channel value cannot be processed, there is a
parameter error. Check the parameters specified.
When a channel is used for a calculation and the input sig-
nal of that channel depends on the calculation, there is a
loop and thus a recursion. The
nises this; the calculation is terminated and this status is
set.
An analogue or digital input or output is overloaded. For
example, the power source for a Pt100 sensor may be
overloaded at one input. The load resistance could be too
small at one output, resulting in an excessive current.
164
Description
MetiOS
software recog-
Expert
Del-
Logger Manual
Januar 2018
