Expert Logger
Value source
: Select an available channel whose value is to be output
Channel Manual value Applic-
using , or enter a constant value ( ). Selecting
ation
enables the output value to be manually set via the DataService Con-
figurator or automatically set via a ProfiSignal application.
Inverted
: When enabled, this option inverts a 'high' level to a 'low' level at
the output (measurement signal in device) and vice versa.
Pulse stretching
: With this option you can ensure that at least one output
pulse of this length is output, even if the specified value source has issued
a shorter duration signal.
PWM mode
