4.11 Configuring software channels

Settings for all dialogues
Refer also to
Software channels are calculations or functions that are performed within
Delphin
the device. In previous device families from , such channels were
also called virtual channels. Any number of channels can be created. This
is a standard feature of the device.
Software channels
Display the in the context menu (DataService tab
Channels Channel group Analogue
). You can then either create a (e.g.
channels
in the example) to group together created channels, or select
one of the available channel operations. The context menu contains all
available calculations and functions.
Alternatively, software channels can be created via the context menu of a
Create dependent channel.
hardware channel as In contrast to creation
Software channel
via , the source channel is already selected within the
dialogue and the channel is (initially) located directly under the hardware
channel. Following creation, the user-defined view enables channels to be
moved and grouped differently.
Another option enables the linking of a channel. The original channel
remains in the original position, but creates in another location an entry
that is linked to this channel.
Linking channels
