Expert Logger
Main settings tab
Function code
permitted data will be available, for example FC01 to FC04 for the inputs
and FC05/06 as well as FC15/16 for the outputs. The setting influences the
values that can be configured in Data type settings.
Reference
: The number in front of the input field indicates the memory
page and thus the tab type.
Input is made in decimal form by default, and is restricted to valid values.
Show as
Using
Address or
(Hex) notation.
Data type settings
Delphin Technology AG
: Select what is to be read (input) or written (output). Only
you can specify whether the input is to be used
as a Tab
, and whether it should follow decimal or hexadecimal
