Expert Logger
If you entered in the free setting, for example,
EventVar <test@delphin.de>
sent in addition as a name to be displayed.
Incorporate channel values in the text to be sent
To do this, switch to the Variables/Mail server tab and press the Add variable but-
ton.
A new line appears. Now name the variable and select the appropriate source chan-
nel.
To use the newly created variable in the message text, please switch back to
theBasic Settings tab.
In the message content, a variable can be used according to the following scheme:
%variablen_name.variablen_attribut%
For variablen_name, please insert the previously selected variable name.
The following options are available for variablen_attribut:
Attribute
Surname
id
value (int)
value (float)
value (string)
flags.l
Example
For example, if you want to monitor a temperature, you can trigger an event by
exceeding a limit.
Assuming an analogue input measures the ambient temperature by thermocouple.
This analogue input is monitored by limit channel. This limit channel is configured
to 35 °C. The limit channel serves as the source for an event channel. As variables
in the event channel, the analogue input is configured as var0 and the limit chan-
nel is configured as var1.
Below is the example configuration of the message content:
Die Temperaturmessung an %var0.name% meldet eine Überschreitung des Gren-
zwertes von %var1.value(int)%°C!
Die derzeitig gemessene Temperatur beträgt %var1.value(float)% °C.
The resulting mail/SMS thus contains the following, for example:
Die Temperaturmessung an Analogeingang #03 - Thermoelement meldet eine
Überschreitung des Grenzwertes von 35°C!
Die derzeitig gemessene Temperatur beträgt 36,565°C.
Delphin Technology AG
will be sent, that is, the channel name is
Source channel name
Hexadecimal ID of the source channel
Integer value of the source channel
(
floating) comma number of the source channel
Text value of the source channel
Flags of the source channel
118
test@delphin.de
Displayed value
