Explanation of options
Setting
Rising
edge
Falling
edge
Edge
(both)
High
level
Low
level
Every
high
Every
low
Every
value
4.7.7 Inherit status
This option sets whether the source's status as well as its value is to be
used for the function. This can be used, for example, to prevent invalid
input values in the calculation. Channel status values are available in
status monitoring.
An example of inheriting: The case of an analogue input exceeding a range
is displayed in the software channel as a wire break.
Expert Logger Manual
Januar 2018
Level
The event is triggered when changing from "Low" to "High"
The event is triggered when changing from "High" to "Low"
The event is triggered at every change
The event is triggered when (and for as long as) the level is
"High"
The event is triggered when (and for as long as) the level is
"Low"
The event is triggered for each value larger than 0. The function
is generally only recommended with digital signals.
The event is triggered for each value that is 0. The function is
only recommended with digital signals.
The event is triggered as soon as there is a (new) value.
Edge
Edge (full)
(basic)
Description
