Once the pulse generator starts (
second, the pulse duration is set to 2 seconds (
pulses, the reset channel (
pulse generator issues no more pulses (the next pulse would be due at
8:49:30). Pulses begin again only after deleting the reset signal (level =
"Low"). The cycle time indicates that the next pulse will be output at
08:49:50.
Example 2
