Enter information about the device's Location and its function (Description).
l
For example, enter the location of the device or of the object from which data
is being acquired.
Changing device ID.
l
Device ID
The DataService uses device ID to uniquely identify a device and its chan-
nels. The factory setting for the device ID is its serial number.
The device ID is displayed as the main part of the
column with the same name in DataService. The column can be displayed
View
via
The device ID requires amending when copying the configuration from one
device to another and then running both devices together on the same
DataService. Both devices would then have identical device IDs and the
DataService would not be able to distinguish between them.
Method
1. Open the Device properties dialogue.
2. Enable User-defined device ID.
3. Enter a new ID (e.g. the device's " old" serial number).
The device ID is in hexadecimal format. Valid inputs include numbers from
0 to 9 and letters from 'a–f' or 'A–F' (no distinction is made between upper
case and lower case letters). If a sufficient number of characters is
entered, preceding zeroes are removed. A valid input changes the input
font from red to black.
After amending the device ID, the connection to the d evice is briefly inter-
rupted before being restored again.
Refer also to
4.8.2
Saving and loading device configurations
Save configuration
Open the dialog via the device's context menu.
Enter the destination file in the file dialog. Thereafter you can enter a
description of the configuration to be saved (comment). This will be dis-
played when you load the file.
Load configuration
Open the dialog via the device's context menu.
Select the configuration file to be loaded. You may only load configurations
you have generated using the Save configuration menu. Configuration
