Pin assignment 9-pole Sub-D socket
Pin
Housing Shield
1
2
3
4
5
6
7
8
9
No galvanic isolation between CAN1 and COM1 or CAN2 and
COM2.
CANHL/CANH have an integrated terminating resistor of 120 Ω.
COM3
Pin assignment 9-pole Sub-D plug
Pin
Housing Shield
1
2
Delphin Technology AG
Description COM1/2 RS-485
Signal
Shield / protective ground, refer to
Shield
Shield / protective ground, refer to
CANL —
RxD/TxD- Receive/transmit data-Plus
P/B (RS-485)
Control signal for repeaters
RTS
(TTL)
GND/C Data reference potential/mass
VP Supply voltage/Plus (5 V)
CANH —
RxD/TxD- Receive/transmit data-Minus
N/A (RS-485)
— Not connected
Description COM3 DIN 41 652, Part 1
Signal
Shield / protective ground, refer to
DCD Received signal level, Data Carrier Detect (RS-232)
RxD Receive Data (RS-232)
(IEC 61158)
(ISO 4902)
24
Description
CAN1/2
(CiA DS102-1)
Earthing
Earthing
CAN bus low
—
—
—
—
CAN bus high
—
Earthing
