Expert Logger
The trigger (blue
a rising edge. Then comes the reset (purple
high level ("high") remains, no further pulses are generated (Reset =
High level ). Meanwhile, the trigger channel switches to a low level
("Low"). However, because the reset channel remains at a high level
as before, the trigger channel's edge has no effect. The pulse gen-
erator does not re-start even when the reset channel reverts to a low
level as it is only re-started with an edge in the trigger channel. The
pulse generator restarts only once the trigger channel has a (rising)
edge.
c)
Trigger and reset are triggered by channels and are set to Level high.
The pulse generator (red
(blue
put is set to "low" and no further pulses are generated. When the
reset signal resets to "Low", the pulse generator re-starts (10:25:25)
because the trigger channel remains at a high level. In the second
example, no further pulses are generated because the trigger chan-
nel has meanwhile gone to "low".
d)
The trigger is triggered by a channel and has been set to High level.
The reset is also triggered by a channel, but has been set to Edges
(both).
Delphin Technology AG
curve) starts the pulse generator (red
curve) is started by the trigger channel
curve). When a reset signal (purple
130
curve) with
curve). Because the
curve) is received, the out-
