Expert Logger
the controller channel directly with an analogue output, you must enter the
same scaling 0...100 % or -100...+100 %.
Main settings tab
Output range
0...100 % or -100...+100 %.
Input range
cess variable (x) to the internal operating range of the controller. Import-
ant: The setpoint variable (w) and process variable (x) must match one
another.
Setpoint variable (w)
logue input, a marker or the output of another controller (cascade) is nor-
mally used as the source channel. Ensure in the case of a cascade that the
Delphin Technology AG
: Set the required output range for the final control element:
: Match the input range of the setpoint variable (w) and pro-
: Source channel for the setpoint variable. An ana-
