Expert Logger
channel does not start the programmer while pause state is active.
Edge
For settings, the setpoint is retained from the onset of the edge until
the next edge. An event here is also unable to give priority to a start chan-
nel over a pause state.
Reset
: A reset event from the specified channel sets the program to the
beginning but does not start it. The reset channel has the highest priority,
i.e. the reset condition prevents starting by a start event and cancels a
pause state.
Refer also to
Table tab (only for local table)
The setpoint table contains the value pairs of time and value. Each row of
the table describes a program step with a
value
y (fixed or variable). If a variable is used, it requires configuring via
Variables
the
the selected channel.
Delphin Technology AG
Trigger options
.
tab. This applies even when using a global setpoint table for
time
t (fixed or variable) and a
