Expert Logger
Function code
: Select what is to be read (input) or written (output). Only
permitted data will be available, for example FC01 to FC04 for the inputs
and FC05/06 as well as FC15/16 for the outputs. The setting influences the
values that can be configured in Data type settings.
Reference
: The number in front of the input field indicates the memory
page and thus the tab type.
Input is made in decimal form by default, and is restricted to valid values.
Show as as an
Using you can specify whether the input is to be used
as a Tab
Address or , and whether it should follow decimal or hexadecimal
(Hex) notation.
Data type settings
