Expert Logger
DHCP
Use as the access point then generally assigns addresses . Then
SSID
give the
encryption
the
Ad hoc
With an ad hoc connection, you have to firstly set up your PC for con-
nection.
PC setup
1. Open the Network connections window via Windows' Start Menu and Set-
tings.
2. Right click "Wireless Network Connection" and select Properties.
3. Find the Wireless Networks tab.
4. Create the network for the Delphin device: Click Add and specify the
name of the network (network name, SSID) in the following dialogue, e.g.
DelphinDevice.
5. Enable the option Connect even if the network is not broadcasting in the
Association tab.
6. Select the option This is a computer-to-computer ad hoc network. Wire-
less access points are not used.
7. We recommend setting an encryption for the network, even though the
less secure WEP is only possible with ad hoc networks: Enter Open with
network authentication and WEP for data encryption.
8. Enter the network key which you have given to the Delphin device.
9. Go to the Connection tab and activate Connect automatically when this net-
work is in range.
10. Close the dialogue with OK.
The network should now appear in the list of networks and should be lis-
ted automatically behind the network name CX22.
11. Go the the General tab, select Internet Protocol (TCP/IP) in the list and
click Properties.
12. Activate Obtain an IP address automatically and Obtain DNS server
address automatically in the following dialogue.
13. Close all dialogues to the wireless connection by clicking OK a nd Close.
Preparing Delphin
DHCP
Use and establish the
DelphinDevice
tion
(WEP) and the
Creating a connection via WLAN and ad hoc network
1. Start up the PC on which a connection is to be created.
2. Right click on the symbol for WLAN, which is displayed in the information
panel of the Windows task list and select View available wireless networks.
Delphin Technology AG
of your access point, the password (
(mostly WPA2) and the
device
SSID
. Then set the password (
channel
.
244
PSK
channel
.
of your access points, e.g.
PSK
, Preshared Key), the
, Preshared Key),
encryp-
