Page 12: Introduction
Web User Interface (Web UI). The Web UI is the secondary management interface to the DXS-3600 Series switch, which will be generally be referred to simply as the “switch” within this manual. This manual is written in a way that assumes that you already have the experience and knowledge of Ethernet and modern networking principles for Local Area Networks.
Page 13 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide NOTE: A note indicates important information that helps you make better use of your device. NOTICE: A notice indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.
Page 14: Web-Based Switch Configuration
Opera (version 12 and later), or Netscape (version 8 and later). Connecting using the Web User Interface Most software functions of the DXS-3600 Series switches can be managed, configured and monitored via the embedded web-based (HTML) interface. Manage the switch from remote stations anywhere on the network through a standard web browser.
Page 15 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide NOTE: The default IP address of this switch is 10.90.90.90, with a subnet mask of 255.0.0.0. Figure 2-1 Displays entering the IP address in Internet Explorer This will open the user authentication window, as seen below.
Page 16: Web User Interface (Web Ui)
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Web User Interface (Web UI) The user interface provides access to various switch configuration and management windows, to view performance statistics, and permits you to graphically monitor the system status.
Page 17: System
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide System Device Information System Information Settings Peripheral Settings Port Configuration System Log Time and SNTP Time Range Device Information On this page, the Device Information, Temperature status, CPU, Usage status, System Log, Fan status, and Memory usage status are displayed.
Page 18: Temperature Status
The temperature of the switch is mainly influenced by two factors: (1) the environment, and (2) the internal air-flow of the switch. In the DXS-3600 Series Hardware Installation Guide, there are some guidelines that can assist the user with the installation of this switch in a temperature friendly environment.
Page 19: Cpu Status
In the CPU section, the user can view a real-time display of the switch’s CPU usage. There are a number of factors that can influence a depleted CPU usage. One of those factors is network broadcasts. In the DXS-3600 Series CLI Reference Guide there is an abundance of features that can be enabled to prevent this problem from occurring.
Page 20: System Log Entries
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 3-4 CPU Status Window In the CPU section, the following display parameters are available: Parameter Description Percentage Display In this graphic, the reading is divided into percentage sections. This area ranges from 0% to 100%.
Page 21 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 3-5 System Log Window In the System Log section, the following display parameters are available: Parameter Description Entry Number Every log entry has a specific entry number, generated when the log entry was added to the System log entry display.
Page 22: Fan Status
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 3-6 System Log (More) Window Click the Close button to exit the larger display. Fan Status In the Fan section, the user can view a real-time display of the switch’s fan(s) status. A maximum of 3 fans can be installed in this switch.
Page 23: Flash, Sd Card, And Memory Status
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide In the Fan section, the following display parameters are available: Parameter Description Fan Number At the top of this graphic, the list of installed fans is displayed. After clicking on any specific fan icon, the real-time RPM gauge of that fan will be displayed.
Page 24: System Information Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide System Information Settings This window is used to view and configure the system information settings and management interface configuration settings. To view the following window, click System > System Information Settings, as shown below:...
Page 25: Port Configuration
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 3-10 Peripheral Settings Window The fields that can be configured in Environment Trap Settings are described below: Parameter Description Fan Trap Click to enable or disable the fan trap state for waning fan event (fan failed or fan recover).
Page 26 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide To view the following window, click System > Port Configuration > Port Settings, as shown below: Figure 3-11 Port Settings Window The fields that can be configured are described below:...
Page 27: Port Status
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Options to choose from are Auto, 10M, 100M, 1000M, 1000M Master, 1000M Slave, 10G, 10G Master, 10G Slave, and 40G. The Master setting will allow the port to advertise capabilities related to duplex, speed and physical layer type.
Page 28: Port Gbic
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 3-12 Port Status Window The fields that can be configured are described below: Parameter Description Unit Select the stacking unit ID of the switch that will be displayed here.
Page 29: Port Auto Negotiation
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 3-13 Port GBIC Window The fields that can be configured in Port GBIC are described below: Parameter Description Unit Select the switch unit that will be used for this display here.
Page 30: Error Disable Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 3-14 Port Auto Negotiation Window The fields that can be configured are described below: Parameter Description Unit Select the stacking unit ID of the switch that will be displayed here.
Page 31: Jumbo Frame
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 3-15 Error Disable Settings Window The fields that can be configured in Error Disable Recovery Settings are described below: Parameter Description ErrDisable Cause Select the error disabled cause here. Options to choose from are Port Security, Storm Control, BPDU Attack Protection, Dynamic ARP Inspection, DHCP Snooping, and Loopback Detect.
Page 32: System Log
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 3-16 Jumbo Frame Window The fields that can be configured are described below: Parameter Description Unit Select the stacking unit ID of the switch that will be configured here.
Page 33 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 3-17 System Log Settings Window The fields that can be configured for Log State are described below: Parameter Description Log State Select the enable or disable the system log feature’s global state here.
Page 34: System Log Discriminator Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description 3 (Errors), 4 (Warnings), 5 (Notifications), 6 (Informational), and 7 (Debugging). Discriminator Name Enter the discriminator name used here. This name can be up to 15 characters long.
Page 35: System Log Server Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 3-18 System Log Discriminator Settings Window The fields that can be configured are described below: Parameter Description Discriminator Name Enter the discriminator name here. This name can be up to 15 characters long.
Page 36: System Log
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 3-19 System Log Server Settings Window The fields that can be configured are described below: Parameter Description Host IPv4 Address Enter the system log server’s IPv4 address here.
Page 37: System Attack Log
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide System Attack Log This window is used to view and clear the system attack log. To view the following window, click System > System Log > System Attack Log, as shown below:...
Page 38 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide To view the following window, click System > Time and SNTP > Time Zone Settings, as shown below: Figure 3-23 Time Zone Settings Window The fields that can be configured are described below:...
Page 39: Sntp Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description To: Day of the Week Select the day of the week that summer time will end. To: Month Select the month that summer time will end.
Page 40: Time Range
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description 99999 seconds. The default interval is 720 seconds. Click the Apply button to accept the changes made. The fields that can be configured in SNTP Server Settings are described below:...
Page 41 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Delete Periodic button to delete the periodic entry. Click the Delete button to delete the specified entry.
Page 42: Management
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Management User Account Settings Password Encryption Login Method SNMP RMON Telnet/Web Session Timeout DHCP DHCP Auto Configuration IP Source Interface File System Physical Stacking Virtual Stacking (SIM) SMTP Settings...
Page 43: Password Encryption
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description between 1 and 15. Password Type Select the password type for this user account here. Options to choose from are None, Plain Text, and Encrypted. Password After selecting either Plain Text or Encrypted as the password type, enter the password for this user account here.
Page 44: Snmp
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 4-4 Login Method Window The Login Method section will only be available when Authentication, Authorization, and Accounting (AAA) feature is disabled. The fields that can be configured in Login Method are described below:...
Page 45 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide a standard presentation of the information controlled by the on-board SNMP agent. SNMP defines both the format of the MIB specifications and the protocol used to access this information over the network.
Page 46: Snmp Global Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide SNMP settings are configured using the menus located on the SNMP V3 folder of the Web manager. Workstations on the network that are allowed SNMP privileged access to the Switch can be restricted with the Management Station IP Address menu.
Page 47: Snmp Linkchange Trap Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Port Link Down Tick this option to control the sending of port link down notifications. A linkDown trap is generated when the device recognizes a failure in one of the communication links.
Page 48: Snmp Community Table Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 4-7 SNMP View Table Settings Window The fields that can be configured in SNMP View Settings are described below: Parameter Description View Name Type an alphanumeric string of up to 32 characters. This is used to identify the new SNMP view being created.
Page 49: Snmp Group Table Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 4-8 SNMP Community Table Settings Window The fields that can be configured in SNMP Community Settings are described below: Parameter Description Key Type Select the key type for the SNMP community. Options to choose from are Plain Text, and Encrypted.
Page 50 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 4-9 SNMP Group Table Settings Window The fields that can be configured in SNMP Group Settings are described below: Parameter Description Group Name Enter the group name of a maximum of 32 characters. The syntax is general string that does not allow space.
Page 51: Snmp Engine Id Local Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide SNMP Engine ID Local Settings The Engine ID is a unique identifier used for SNMP V3 implementations on the Switch. To view the following window, click Management > SNMP > SNMP Engine ID Local Settings, as shown...
Page 52 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description SNMP Version Select the SNMP version. Options to choose from are v1, v2c, and v3. SNMP V3 Encryption When selecting v3 in the SNMP Version drop-down list, this option is available.
Page 53: Snmp Host Table Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide SNMP Host Table Settings This window is used to view and configure the recipient of the SNMP notification. To view the following window, click Management > SNMP > SNMP Host Table Settings, as shown...
Page 54: Rmon
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Delete button to remove the specified entry. RMON RMON Global Settings This window is used to enable or disable remote monitoring (RMON) for the rising and falling alarm trap feature for the SNMP function on the Switch.
Page 55: Rmon History Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Delete button to remove the specified entry. Click the Show Detail button to see the detail information of the specific port. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Page 56: Rmon Alarm Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Enter a page number and click the Go button to navigate to a specific page when multiple pages exist. After clicking the Show Detail button, the following window will appear.
Page 57: Rmon Event Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Add button to add a new entry based on the information entered. Click the Delete button to remove the specified entry. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Page 58: Telnet/Web
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Back button to return to the previous window. Telnet/Web This window is used to view and configure Telnet and Web settings on the switch. To view the following window, click Management > Telnet/Web, as shown below:...
Page 59: Session Timeout
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Session Timeout This window is used to view and configure the session timeout settings. To view the following window, click Management > Session Timeout, as shown below: Figure 4-22 Session Timeout Window...
Page 60: Dhcp Class Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in Service DHCP are described below: Parameter Description Service DHCP State Select this option to enable or disable the DHCP relay service.
Page 61: Dhcp Server
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in DHCP Class Option Settings are described below: Parameter Description Option Enter the DHCP option number. The range is from 1 to 255.
Page 62 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description DHCP Use Class State Select to enable or disable the feature where the DHCP server uses a class. Click the Apply button to accept the changes made.
Page 63 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 4-28 DHCP Server Pool Settings (Edit Class) Window The fields that can be configured in DHCP Server Pool Class Settings are described below: Parameter Description Class Name Select an existing DHCP class’...
Page 64 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Apply button to accept the changes made. Click the Delete button to remove the specified entry. Click the Back button to return to the previous window.
Page 65 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description server configured later will be added to the default interface list. Netbios Node Type Select the NetBIOS node type for Microsoft DHCP clients here. Options to choose from are Broadcast, Peer To Peer, Mixed, and Hybrid.
Page 66 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide DHCP Server Manual Binding This window is used to view and configure the DHCP server feature’s manual binding settings. With a manual binding entry, the IP address can be either be bound with a client-identifier or bound with the hardware address of the host.
Page 67 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description VRF Name Enter the VRF instance’s name that will be used here. This name can be up to 12 characters long. IP Address Enter the binding entry’s IPv4 address here.
Page 68: Dhcpv6 Server
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 4-35 DHCP Server Statistic Window Click the Clear button to clear the statistics information displayed here. DHCPv6 Server DHCPv6 Server Pool Settings This window is used to view and configure the DHCPv6 server pool settings.
Page 69 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 4-37 DHCPv6 Server Pool Settings (Configure) Window The fields that can be configured in DHCPv6 Server Pool Configure are described below: Parameter Description Address Prefix Select and enter the DHCPv6 server pool’s IPv6 network address and prefix length here.
Page 70 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description than the preferred lifetime. The range is from 60 to 4294967295 seconds. By default, this value is 2592000 seconds (30 days). Preferred Lifetime Enter the preferred lifetime value here. The range is from 60 to 4294967295 seconds.
Page 71 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide assigned to clients. Use this window to exclude a single IPv6 address or a range of IPv6 addresses. The excluded addresses are only applied to the pool(s) for address assignment.
Page 72: Dhcp Relay
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide To view the following window, click Management > DHCP > DHCPv6 Server > DHCPv6 Server Interface Settings, as shown below: Figure 4-41 DHCPv6 Server Interface Settings Window The fields that can be configured in DHCPv6 Server Interface Settings are described below:...
Page 73 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 4-43 DHCP Relay Pool Settings Window The fields that can be configured in DHCP Relay Pool Settings are described below: Parameter Description Pool Name Enter the address pool name with a maximum of 32 characters.
Page 74 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 4-45 DHCP Relay Pool Settings (Destination Edit) Window The fields that can be configured in DHCP Relay Pool Destination Settings are described below: Parameter Description Relay Destination Enter the relay destination DHCP server IP address.
Page 75 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 4-47 DHCP Relay Pool Settings (Class Edit, Edit) Window The fields that can be configured in DHCP Relay Pool Class Edit Settings are described below: Parameter Description...
Page 76 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description relay option is left unchanged and directly relayed to the DHCP server. • Replace - Select that the DHCP request packet that already has the relay option will be replaced by a new option.
Page 77: Dhcpv6 Relay
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 4-50 DHCP Local Relay VLAN Window The fields that can be configured in DHCP Local Relay VLAN Settings are described below: Parameter Description DHCP Local Relay VID List Enter the VLAN ID for DHCP local relay.
Page 78: Dhcp Auto Configuration
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Option remote ID Option 37 during the relay of DHCP for IPv6 request packets. Click the Apply button to accept the changes made. DHCPv6 Relay Interface Settings This window is used to view and configure the DHCPv6 relay interface settings.
Page 79: Dns
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in DHCP Auto Configuration are described below: Parameter Description Auto Configuration State Select this option to enable or disable the auto-configuration function.
Page 80: Dns Name Server Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 4-54 DNS Global Settings Window The fields that can be configured in DNS Global Settings are described below: Parameter Description IP DNS Lookup Static State Select to enable or disable the IP DNS lookup static state here.
Page 81: Dns Host Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide DNS Host Settings This window is used to view and configure the static mapping entry for the host name and the IP address in the host table. To view the following window, click Management > DNS > DNS Host Settings, as shown below:...
Page 82 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 4-57 IP Source Interface Window The fields that can be configured in IP TFTP Source Interface are described below: Parameter Description Source Interface State Select to enable or disable the IP TFTP source interface’s state here.
Page 83: File System
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide File System This window is used to view, manage and configure the switch’s file system. To view the following window, click Management > File System, as shown below:...
Page 84: Physical Stacking
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide NOTE: If the boot configuration file is damaged, the Switch will automatically revert back to the default configuration. NOTE: If the boot image file is damaged, the Switch will automatically use the backup image file in the next boot up.
Page 85 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide • Duplex Ring - The duplex ring stacks switches in a ring or circle format where data can be transferred in two directions. This topology is very resilient due to the fact that if there is a break in the ring, data can still be transferred through the stacking cables between switches in the stack.
Page 86 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Backup Master - The Backup Master is the backup to the Primary Master, and will take over the functions of the Primary Master if the Primary Master fails or is removed from the Stack. It also monitors the status of neighboring switches in the stack, will perform commands assigned to it by the Primary Master and will monitor the running status of the Primary Master.
Page 87 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide If the Backup Master has been hot removed, a new Backup Master will be chosen through the election process previously described. Switches in the stack will clear the configurations of the unit removed, and dynamically learned databases, such as ARP, will be cleared as well.
Page 88: Virtual Stacking (Sim)
Click the Apply button to accept the changes made. Virtual Stacking (SIM) D-Link Single IP Management (SIM) is a concept that will stack switches together over Ethernet instead of using stacking ports or modules. There are some advantages in implementing the Single IP Management feature: •...
Page 89 The CaS can be configured through the CS to become a MS. After configuring one switch to operate as the CS of a SIM group, additional DXS-3600 Series switches may join the group by manually configuring the Switch to be a MS. The CS will then serve as the in band entry point for access to the MS.
Page 90: Single Ip Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The user may zoom in and zoom out when utilizing the topology window to get a better, more defined view of the configurations. Single IP Settings This window is used to view and configure the SIM settings. The switch is set as a Candidate (CaS) as the factory default configuration and Single IP Management is disabled.
Page 91: Topology
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Hold Time Enter the hold-time in seconds. The range is from 100 to255. Management VLAN Enter the single IP management message VLAN ID. Click the Apply button to accept the changes made.
Page 92 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Local Port Display the number of the physical port on the CS that the MS or CaS is connected to. The CS will have no entry in this field.
Page 93 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Icon Description Icon Description Layer 2 commander switch Member switch of other group Layer 3 commander switch Layer 2 candidate switch Commander switch of other group Layer 3 candidate switch...
Page 94 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 4-68 Port Speed Utilizing the Tool Tip Right-Click Right-clicking on a device will allow the user to perform various functions, depending on the role of the Switch in the SIM group and the icon associated with it.
Page 95 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 4-70 Property Window The fields that can be displayed are described below: Parameter Description Device Name Display the Device Name of the switches in the SIM group configured by the user.
Page 96 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 4-72 Right-clicking a Member icon The following options may appear for the user to configure: • Collapse - To collapse the group that will be represented by a single icon.
Page 97: Firmware Upgrade
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide File • Print Setup - Will view the image to be printed. • Print Topology - Will print the topology map. • Preference - Will set display properties, such as polling interval, and the views to open at SIM startup.
Page 98: Configuration File Backup/Restore
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 4-78 Firmware Upgrade Window The fields that can be configured in Firmware Upgrade are described below: Parameter Description TFTP Server IP Enter the TFTP server IP address.
Page 99: Smtp Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 4-80 Upload Log File Window The fields that can be configured in Upload Log File are described below: Parameter Description TFTP Server IP Enter the TFTP server IP address.
Page 100: Nlb Fdb Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description SMTP IP Select the SMTP server’s IP address type here. Options to choose from are IPv4 and IPv6. SMTP IPv4 Server Address After selecting IPv4 as the SMTP IP type enter the SMTP server’s IPv4 address here.
Page 101 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide clients will be forwarded to all the servers, but will only be processed by one of them. The server can work in two different modes: • Unicast mode: The client uses a unicast MAC address as the destination MAC address to reach the server.
Page 102: Layer 2 Features
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Layer 2 Features VLAN VLAN Tunnel ERPS (G.8032) Loopback Detection Link Aggregation L2 Protocol Tunnel L2 Multicast Control LLDP Static FDB Unicast Static FDB This window is used to view and configure the static unicast forwarding settings on the switch.
Page 103: Mac Address Table Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Multicast Static FDB This window is used to view and configure the multicast static FDB settings. To view the following window, click L2 Features > FDB > Static FDB > Multicast Static FDB, as shown...
Page 104: Mac Address Table
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Aging Destination Hit Select to enable or disable the aging destination hit function. Click the Apply button to accept the changes made. After selecting the MAC Address Learning tab option, at the top of the page, the following page will be available.
Page 105: Mac Notification
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-5 MAC Address Table Window The fields that can be configured are described below: Parameter Description Port Select the stacking unit ID and the port number of the switch that will be configured here.
Page 106 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-6 MAC Notification (MAC Notification Settings) Window The fields that can be configured are described below: Parameter Description MAC Address Notification Select to enable or disable MAC notification globally on the switch Interval Enter the time value between notifications.
Page 107: Vlan
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-7 MAC Notification (MAC Notification History) Window On this page, a list of MAC notification messages will be displayed. VLAN 802.1Q VLAN This window is used to view and configure the VLAN settings on this switch.
Page 108 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide To view the following window, click L2 Features > VLAN > 802.1v Protocol VLAN > Protocol VLAN Profile, as shown below: Figure 5-9 Protocol VLAN Profile Window The fields that can be configured are described below:...
Page 109: Gvrp
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description be configured here. Profile ID Select the 802.1v protocol VLAN profile ID here. Enter the VLAN ID used here. Priority Select the priority value used here. This value is between 0 and 7. This parameter is specified to re-write the 802.1p default priority previously...
Page 110 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-12 GVRP Port Window The fields that can be configured are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 111 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-13 GVRP Advertise VLAN Window The fields that can be configured are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 112: Mac Vlan
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description From Port ~ To Port Select the range of ports that will be used for this configuration here. Action Select the forbidden VLAN to port mapping action that will be taken here.
Page 113: Vlan Interface
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-16 MAC VLAN Window The fields that can be configured are described below: Parameter Description MAC Address Enter the unicast MAC address. Enter the VLAN ID that will be used.
Page 114 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here. Click the View Detail button to view more detailed information about the VLAN on the specific interface.
Page 115 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description between 1 and 4094. Clone Select this option to enable the clone feature. From Port ~ To Port Select the range of ports that will be used in the clone feature here.
Page 116 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Back button to discard the changes made and return to the previous page. When Trunk was selected as the VLAN Mode, the following page will appear.
Page 117 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-22 VLAN Interface (802.1Q-Tunnel) Window The fields that can be configured are described below: Parameter Description VLAN Mode Select the VLAN mode option here. Options to choose from are Access, Hybrid, Trunk, 802.1Q-Tunnel, Promiscuous, Host, Trunk...
Page 118 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description VLAN Mode Select the VLAN mode option here. Options to choose from are Access, Hybrid, Trunk, 802.1Q-Tunnel, Promiscuous, Host, Trunk Promiscuous, and Trunk Secondary. Acceptable Frame Select the acceptable frame behavior option here.
Page 119 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-25 VLAN Interface (Trunk Promiscuous) Window The fields that can be configured are described below: Parameter Description VLAN Mode Select the VLAN mode option here. Options to choose from are Access, Hybrid, Trunk, 802.1Q-Tunnel, Promiscuous, Host, Trunk...
Page 120: Subnet Vlan
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-26 VLAN Interface (Trunk Secondary) Window The fields that can be configured are described below: Parameter Description VLAN Mode Select the VLAN mode option here. Options to choose from are Access, Hybrid, Trunk, 802.1Q-Tunnel, Promiscuous, Host, Trunk...
Page 121: Super Vlan
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-27 Subnet VLAN Window The fields that can be configured are described below: Parameter Description IPv4 Network Prefix / Prefix Select and enter the IPv4 address and prefix length value for the Length subnet VLAN here.
Page 122: Private Vlan
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in Add Super VLAN are described below: Parameter Description Super VID List Enter the VLAN ID(s) of the VLAN that will be used as a super VLAN here.
Page 123 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description VID List Enter the private VLAN ID list here. State Select to enable or disable the private VLAN state here. Type Select the type of private VLAN that will be created here. Options to choose from are Community, Isolated, and Primary.
Page 124: Vlan Tunnel
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide VLAN Tunnel Dot1q Tunnel This window is used to view and configure the 802.1Q VLAN tunnel’s settings. An 802.1Q tunnel port behaves as an UNI port of a service VLAN. The trunk ports which are tagged members of the service VLAN behave as the NNI ports of the service VLAN.
Page 125: Vlan Mapping
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-31 Dot1q Tunnel Settings (Dot1q Tunnel Port Settings) Window The fields that can be configured in Dot1q Tunnel Port Settings are described below: Parameter Description Unit Select the switch’s unit ID that will be used here.
Page 126: Vlan Mapping Profile
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-32 VLAN Mapping Settings Window The fields that can be configured in VLAN Mapping Settings are described below: Parameter Description Unit Select the switch’s unit ID that will be used here.
Page 127 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-33 VLAN Mapping Profile Window The fields that can be configured in VLAN Mapping Profile are described below: Parameter Description Profile ID Enter the ID of the VLAN mapping profile here. A lower ID has a higher priority.
Page 128 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description is from 1 to 10000 Src-MAC Address Enter the source MAC address here. Dst-MAC Address Enter the destination MAC address here. Priority Select the 802.1p priority value here. The range is from 0 to 7. A lower value has a higher priority.
Page 129 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description DSCP Enter the DSCP value here. The range is from 0 to 63. Source Port Enter the source TCP/UDP port’s number here. The range is from 1 to 65535.
Page 130 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description of the matched packets. New Outer VID Enter the new outer VLAN’s ID here. The range is from 1 to 4094. 802.1P Priority Select the 802.1p priority value here. The range is from 0 to 7. A lower value has a higher priority.
Page 131: Stp
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Action Select the action that will be taken here. Options to choose from are Dot1q-Tunnel and Translate. • Dot1q-Tunnel: Specifies that the outer-VID will be added for matched packets.
Page 132 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured for STP Traps are described below: Parameter Description STP New Root Trap Select to enable or disable the STP new root trap option here.
Page 133: Stp Port Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description tree region before the BPDU (bridge protocol data unit) packet sent by the switch will be discarded. Each switch on the hop count will reduce the hop count by one until the value reaches zero. The switch will then discard the BDPU packet and the information held for the port will age out.
Page 134: Mst Configuration Identification
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Link Type Select the link type option here. Options to choose from are Auto, P2P, and Shared. A full-duplex port is considered to have a point-to- point (P2P) connection.
Page 135: Stp Instance
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-40 MST Configuration Identification Window The fields that can be configured for MST Configuration Identification are described below: Parameter Description Configuration Name Enter the MST. This name uniquely identifies the MSTI (Multiple Spanning Tree Instance).
Page 136: Mstp Port Information
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-41 STP Instance Window Click the Edit button to re-configure the specific entry. MSTP Port Information This window is used to view and configure the MSTP port information settings.
Page 137 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-43 ERPS Window The fields that can be configured in ERPS Global Settings are described below: Parameter Description ERPS Trap Status Select to enable or disable the ERPS trap status here.
Page 138 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Sub Ring Name Select the checkbox and enter the physical ring’s sub-ring name here. This name can be up to 32 characters long. Select the Specify radio button to configure this parameter as per normal.
Page 139 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Edit Instance button to configure the ERP instance. After click the Edit Instance button, the following window will appear. The fields that can be configured in Ethernet Instance Settings are described below:...
Page 140: Erps Profile
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description configured as the RPL port. RPL Owner Select the checkbox and then select whether this node is the RPL owner or neighbor. Options to choose from are Enabled and Disabled.
Page 141: Loopback Detection
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in Ethernet Profile Settings are described below: Parameter Description TCN Propagation Select the checkbox and then select the TCN propagation state. Options to choose from are Enable and Disabled. This function is used to enable the propagation of the topology change notifications from the sub-ERP instance to the major instance.
Page 142: Link Aggregation
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in Loopback Detection Global Settings are described below: Parameter Description Loopback Detection State Select to enable or disable loopback detection. The default is Disabled.
Page 143 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-50 Example of Port Trunk Group The switch treats all ports in a trunk group as a single port. Data transmitted to a specific host (destination address) will always be transmitted over the same port in a trunk group. This allows packets in a data stream to arrive in the same order they were sent.
Page 144 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide This window is used to view and configure the link aggregation settings. To view the following window, click L2 Features > Link Aggregation, as shown below: Figure 5-51 Link Aggregation Window...
Page 145: L2 Protocol Tunnel
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Delete Channel button to delete the specified channel group. Click the Channel Detail button to view more detailed information about the channel. After clicking the Channel Detail button, the following page will be available.
Page 146 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-53 L2 Protocol Tunnel (L2 Protocol Tunnel Global Setting) Window The fields that can be configured for L2 Protocol Tunnel Global Settings are described below: Parameter Description CoS for Encapsulated Select the CoS value for encapsulated packets here.
Page 147: L2 Multicast Control
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Protocol MAC After selecting the Protocol MAC option as the Tunneled Protocol, the following option will be available. Select the protocol MAC option here. Options to choose from are 01-00-0C-CC-CC-CC and 01-00-0C- CC-CC-CD.
Page 148 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in VLAN Status Settings are described below: Parameter Description Enter a VLAN ID from 1 to 4094, and select to enable or disable IGMP snooping on the VLAN.
Page 149 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-57 IGMP Snooping Settings (Modify, Edit) Window The fields that can be configured in IGMP Snooping VLAN Settings are described below: Parameter Description Minimum Version Select the minimum version of IGMP hosts that is allowed on the VLAN.
Page 150 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Proxy Reporting Select this option to enable or disable the proxy-reporting function. Source Address Enter the source IP of proxy reporting. This is available when Enabled is selected in Proxy Reporting.
Page 151 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the View All button to view all the entries. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Page 152 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description available if the Port option was selected as the action below. Limit Number Enter the limit number here. This is to configure the rate of IGMP control packets that the switch can process on a specific interface.
Page 153 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description ACL Name Enter the standard IP access list’s name here. This is used to permit users to join a group (*, G), specify “any” in source address field and G in destination address field of the access list entry.
Page 154 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Apply button to accept the changes made. Click the Delete button to remove the specified entry. The fields that can be configured in IGMP Snooping Mrouter Table are described below:...
Page 155: Mld Snooping
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Enter a VLAN ID between 1 and 4094. This is available when VLAN is selected in the Find Type drop-down list. Unit Select the switch unit that will be used for this configuration here. This is available when Port is selected in the Find Type drop-down list.
Page 156 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide MLD Snooping Settings This window is used to view and configure the MLD snooping settings. To view the following window, click L2 Features > L2 Multicast Control > MLD Snooping > MLD...
Page 157 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-63 MLD Snooping Settings (Show Detail) Window The window displays the detail information about MLD snooping VLAN. Click the Modify button to edit the information in the following window.
Page 158 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Fast Leave Select this option to enable or disable the MLD snooping fast leave function. If enabled, the membership is immediately removed when the system receive the MLD leave message.
Page 159 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-65 MLD Snooping Groups Settings Window The fields that can be configured in MLD Snooping Static Groups Settings are described below: Parameter Description Enter the VLAN ID of the multicast group here. The range is from 1 to 4094.
Page 160 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide To view the following window, click L2 Features > L2 Multicast Control > MLD Snooping > MLD Snooping Filter Settings, as shown below: Figure 5-66 MLD Snooping Filter Settings Window...
Page 161 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description From Port ~ To Port Select the appropriate port range used for the configuration here. Limit Number Enter the limit number here. This is used to set the limitation on the number of MLD cache entries that can be created.
Page 162 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide MLD Snooping Mrouter Settings This window is used to view and configure the specified interface(s) as the router ports or forbidden to be IPv6 multicast router ports on the VLAN interface on the Switch.
Page 163: Multicast Vlan
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide To view the following window, click L2 Features > L2 Multicast Control > MLD Snooping > MLD Snooping Statistics Settings, as shown below: Figure 5-68 MLD Snooping Statistics Settings Window...
Page 164 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide To view the following window, click L2 Features > L2 Multicast Control > Multicast VLAN > Multicast VLAN Settings, as shown below: Figure 5-69 Multicast VLAN Settings Window...
Page 165 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Apply button to accept the changes made. Click the Delete button to delete an entry based on the information entered. Click the Add button to add a new entry based on the information entered.
Page 166 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Action Select Add to add a new entry based in the information entered. Select Delete to delete an entry based in the information entered. Address Type Select the address type here.
Page 167 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-70 Multicast VLAN Group Settings Window The fields that can be configured in Group Profile Settings are described below: Parameter Description Profile Name Enter the group profile name for the multicast VLAN feature here. This name can be up to 32 characters long.
Page 168: Multicast Filtering
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Apply button to accept the changes made. The fields that can be configured in Group Profile Table are described below: Parameter Description Profile Name Enter the group profile name for the multicast VLAN feature here. This name can be up to 32 characters long.
Page 169: Lldp
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Apply button to accept the changes made. LLDP LLDP Global Settings This window is used to view and configure the LLDP global settings. To view the following window, click L2 Features > LLDP > LLDP Global Settings, as shown below:...
Page 170: Lldp Port Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in LLDP-MED Settings are described below: Parameter Description Fast Start Repeat Count Enter the LLDP-MED fast start repeat count value. This value must be between 1 and 10.
Page 171: Lldp Management Address List
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Notification Select to enable or disable the notification feature here. Subtype Select the subtype of LLDP TLV(s). Options to choose from are MAC Address, and Local.
Page 172: Lldp Dot1 Tlvs Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Switch always included mandatory data in its outbound advertisements. There are four optional data types that can be configured for an individual port or group of ports to exclude one or more of these data types from outbound LLDP advertisements.
Page 173: Lldp Dot3 Tlvs Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-76 LLDP Dot1 TLVs Settings Window The fields that can be configured in LLDP Dot1 TLVs Settings are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 174: Lldp-Med Port Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-77 LLDP Dot3 TLVs Settings Window The fields that can be configured in LLDP Dot3 TLVs Settings are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 175: Lldp-Dcbx Port Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-78 LLDP-MED Port Settings Window The fields that can be configured in LLDP-MED Port Settings are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 176: Lldp Statistics Information
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-79 LLDP-DCBX Port Settings Window The fields that can be configured in LLDP-DCBX Port Settings are described below: Parameter Description Unit Select the switch’s unit ID that will be used here.
Page 177: Lldp Local Port Information
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 5-80 LLDP Statistics Information Window The fields that can be configured in LLDP Statistics Ports are described below: Parameter Description Unit Select the switch unit that will be used here.
Page 178 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in LLDP Local Port Brief Table are described below: Parameter Description Unit Select the switch unit that will be displayed. Port Select the port number that will be displayed.
Page 179: Lldp Neighbor Port Information
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Back button to return to the previous window. LLDP Neighbor Port Information This window is used to display the information learned from the neighbors. The switch receives packets from a remote station but is able to store the information as local.
Page 180: Layer 3 Features
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Layer 3 Features Gratuitous ARP IPv6 Neighbor Interface UDP Helper IPv4 Static/Default Route IPv4 Route Table IPv6 Static/Default Route IPv6 Route Table Route Preference ECMP Load Balancing Settings...
Page 181: Proxy Arp
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide To view the following window, click L3 Features > ARP > Static ARP, as shown below: Figure 6-2 Static ARP Window The fields that can be configured are described below:...
Page 182: Arp Table
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description the source IP and destination IP are in the same interface. Click the Edit button to re-configure the specific entry. Click the Apply button to accept the changes made.
Page 183: Ipv6 Neighbor
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Generally, a device use the gratuitous ARP request packet to discover whether the IP address is duplicated by other hosts or to preload or reconfigure the ARP cache entry of hosts connected to the interface.
Page 184: Interface
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-6 IPv6 Neighbor Window The fields that can be configured in IPv6 Neighbor Settings are described below: Parameter Description Interface VLAN Enter the VLAN interface’s ID here.
Page 185 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Find button to locate a specific entry based on the information entered. Click the Edit button to re-configure the specific entry. Click the Delete button to remove the specific entry.
Page 186: Ipv6 Interface
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Secondary Tick this option to use the IPv4 address and mask as the secondary interface configuration. Click the Apply button to accept the changes made. Click the Delete button to remove the specific entry.
Page 187 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-10 IPv6 Interface Window The fields that can be configured are described below: Parameter Description Interface VLAN Enter the VLAN interface’s ID that will be associated with the IPv6 entry.
Page 188 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Apply button to accept the changes made. The fields that can be configured for IPv6 Address Autoconfig are described below: Parameter Description State Select to enable or disable the automatic configuration of the IPv6 address using the stateless auto-configuration feature here.
Page 189 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description maximum value. RA Max Interval Enter the maximum RA interval time value here. The range is from 4 to 1800 seconds. RA Lifetime Enter the RA lifetime value here. The range is from 0 to 9000 seconds.
Page 190: Loopback Interface
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Client State Select to enable or disable the DHCPv6 client service here. Select the Rapid Commit option to proceed with two-message exchange for address delegation. The rapid-commit option will be filled in the Solicit message to request two messages handshake.
Page 191: Null Interface
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-16 Loopback Interface (Edit) Window The fields that can be configured are described below: Parameter Description State Select to enable or disable the loopback interface here. Description Enter the description for the loopback interface here.
Page 192: Udp Helper
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide After clicking the Edit button, the following page will appear. Figure 6-18 Null Interface (Edit) Window The fields that can be configured are described below: Parameter Description Description Enter the description for the NULL interface here.
Page 193: Ip Helper Address
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide IP Helper Address This window is used to add or remove a target address for the forwarding of UDP broadcast packets. This feature takes effect only when the received interface has an IP address assigned.
Page 194: Ipv4 Route Table
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-21 IPv4 Static/Default Route Window The fields that can be configured are described below: Parameter Description VRF Name Enter the VRF instance name used here. This name can be up to 12 characters long.
Page 195: Ipv6 Static/Default Route
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-22 IPv4 Route Table Window The fields that can be configured are described below: Parameter Description VRF Name Enter the VRF name here. This name can be up to 12 characters long.
Page 196: Ipv6 Route Table
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-23 IPv6 Static/Default Route Window The fields that can be configured are described below: Parameter Description IPv6 Address/Prefix Length Enter the IPv6 address and prefix length for this route here. Tick the Default Route option to use this route as the default route.
Page 197: Route Preference
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description IPv6 Address Select and enter the IPv6 address to display here. IPv6 Address/Prefix Length Select and enter the IPv6 address and prefix length to display here.
Page 198: Ecmp Load Balancing Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide After clicking the Please Select button, the following page will appear. Figure 6-26 Route Preference (Please Select) Window The fields that can be configured are described below: Parameter Description Select the VRF instance from the list that will be used here.
Page 199: Ipv6 General Prefix
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Apply button to accept the changes made. IPv6 General Prefix This window is used to view and configure the VLAN interface’s IPv6 general prefix settings. To view the following window, click L3 Features > IPv6 General Prefix, as shown below:...
Page 200 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in IP Tunnel Settings are described below: Parameter Description Interface Tunnel ID Enter the IP tunnel interface’s ID here. The range is from 0 to 9999.
Page 201: Urpf Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Destination IPv6 Address Select and enter the destination IPv6 address for the tunnel interface here. Network Address Enter the network address(es) in the spaces provided here.
Page 202 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description URPF State Select to globally enable or disable the URPF feature here. Click the Apply button to accept the changes made. The fields that can be configured in URPF Port Default Settings are described below:...
Page 203: Vrf
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide VRF Settings This window is used to view and configure the Virtual Routing and Forwarding (VRF) settings. After a new VRF instance is created, a new VRF routing table will be created. When a VRF instance is deleted, the related VRF routing table will be deleted at the same time and all routing instances based on this VRF will be destroyed.
Page 204 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-33 VRF Settings (Edit) Window The fields that can be configured in VRF Max Routes Settings are described below: Parameter Description Max Routes Enter the maximum number of routes allowed within the VRF instance here.
Page 205 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description One VRF has only one route distinguisher and cannot be changed if it has been set to one value. Specify an RD in one of the following two forms: •...
Page 206: Vrf Interface Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-35 VRF Settings (Show Detail, Show Detail) Window Click the Back button to return to the previous window. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Page 207: Rip
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in VRF Loopback Interface Settings are described below: Parameter Description Loopback Interface Enter the loopback interface’s ID that will be associated with this VRF instance here.
Page 208 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description VRF Name Enter the VRF instance’s name that will be used here. This name can be up to 12 characters long. Click the Apply button to accept the changes made.
Page 209: Rip Distribute List
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Update Time Enter the update interval in seconds at which the update message is sent. The range is from 1 to 65535 seconds. Select the Default option to use the default value here which is 30 seconds.
Page 210: Rip Interface Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Apply button to accept the changes made. Click the Distribute Detail button to view more detailed information about the distribute list configuration. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Page 211: Rip Database
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide RIP Database This window is used to display the Routing Information Protocol (RIP) routing database. Summary address entries will appear in the database only if relevant child routes exist and are being summarized.
Page 212 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-43 RIPng Settings Window The fields that can be configured in RIPng Global Settings are described below: Parameter Description Global State Select to globally enable or disable the RIPng feature here.
Page 213: Ripng Interface Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Poison Reverse Select to enable or disable the poison reverse feature here. When poison reverse is enabled, the routes learned from an interface will be advertised out to the same interface with an unreachable metric.
Page 214: Ripng Database
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description routing table. Use this option to influence the metric of routes received on different interfaces and thus influence the preference of the route. Select the Default option to use the default metric offset value, which is 1.
Page 215 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in OSPF Process Settings are described below: Parameter Description VRF Name Enter the VRF instance’s name that will be used here. This name can be up to 12 characters long.
Page 216 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description OSPF State Select to enable or disable the OSPFv2 feature’s state on the specified VRF instance. Router ID Enter the router ID in the IPv4 address format here. The router ID is a 32-bit number assigned to each router running the OSPF protocol.
Page 217 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-49 OSPFv2 Process Settings (VRF) Window Click the OK button to close the window and return to the previous page. OSPFv2 Distribute List This window is used the view and configure the OSPFv2 distribute list settings.
Page 218 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description from the list. ACL Name Enter the access list’s name that will be used here. This name can be up to 32 characters long. Interface Name Enter the interface’s name that will be used here.
Page 219 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-53 OSPFv2 Passive Interface Settings Window The fields that can be configured in OSPF Passive Interface Settings are described below: Parameter Description Enter the VRF instance’s name that will be used here. This name can be up to 12 characters long.
Page 220 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-55 OSPFv2 Area Settings Window The fields that can be configured in OSPF Area Settings are described below: Parameter Description Enter the VRF instance’s name that will be used here. This name can be up to 12 characters long.
Page 221 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-56 OSPFv2 Area Settings (Select VRF) Window The fields that can be configured are described below: Parameter Description Select the VRF instance from the list that will be used here.
Page 222 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in OSPF Interface Table are described below: Parameter Description VRF Name Enter the VRF instance’s name that will be used here. This name can be up to 12 characters long.
Page 223 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-59 OSPFv2 Redistribute Settings Window The fields that can be configured in OSPF Redistribute Settings are described below: Parameter Description VRF Name Enter the VRF instance’s name that will be used here. This name can be up to 12 characters long.
Page 224 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Select the VRF instance from the list that will be used here. Click the OK button to accept the changes made. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Page 225 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description specified for the virtual link, the password authentication type for the area will be used. Password After selecting the Simple Password authentication type, enter the password used for password authentication here. This password can be up to 8 characters long.
Page 226 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-63 OSPFv2 LSDB Table Window The fields that can be configured in OSPF LSDB Table are described below: Parameter Description Enter the VRF instance’s name that will be used here. This name can be up to 12 characters long.
Page 227 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide OSPFv2 Neighbor Table This window is used to display information of OSPF neighbors. To view the following window, click L3 Features > OSPF > OSPFv2 > OSPFv2 Neighbor Table, as...
Page 228 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide OSPFv2 Host Route Settings This window is used to view and configure the OSPFv2 feature’s host route settings. The router will advertise specific host routes as the router’s LSA for a stub link.
Page 229: Ospfv3
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-68 OSPFv2 Host Route Settings (Select VRF) Window The fields that can be configured are described below: Parameter Description Select the VRF instance from the list that will be used here.
Page 230 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-70 OSPFv3 Process Settings (Edit) Window The fields that can be configured in OSPFv3 Process Table are described below: Parameter Description Router ID Enter the router ID for the OSPF process here.
Page 231 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-71 OSPFv3 Process Settings (Process ID) Window Click the OK button to close the window and return to the previous window. OSPFv3 Passive Interface Settings This window is used to view and configure the OSPFv3 feature’s passive interface settings. If an interface is passive, the OSPF routing update packets are not sent nor received through the specified interface.
Page 232 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide OSPFv3 Area Settings This window is used to view and configure the OSPFv3 area’s settings. To view the following window, click L3 Features > OSPF > OSPFv3 > OSPFv3 Area Settings, as shown...
Page 233 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in OSPFv3 Area Table are described below: Parameter Description Process ID Enter the process ID of the OSPF area used here. The range is from 1 to 65535.
Page 234 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Delete button to delete the specified entry. After clicking the Process ID link (1) button, the following page will appear. Figure 6-75 OSPFv3 Interface Settings (Process ID) Window...
Page 235 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Transmit Delay Enter the transmit delay value here. The range is from 1 to 65535 seconds. LSUs must have their ages incremented by the amount specified in the seconds argument before transmission. The value assigned should take into account the transmission and propagation delays for the interface.
Page 236 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description IPv6 OSPF. Metric Enter the metric value here. This value is used when redistributing other processes to an IPv6 OSPF process. The range is from 0 to 16777214.
Page 237 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description from 1 to 65535 seconds. Select the Default option to use the default value, which is 40 seconds. Transmit Delay Enter the transmit delay value here that the router uses to wait before it transmits a packet.
Page 238 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-79 OSPFv3 LSDB Table Window The fields that can be configured in OSPFv3 LSDB Table are described below: Parameter Description Process ID Enter the ID for an IPv6 OSPF routing process here. It is locally assigned and should be unique for each IPv6 OSPF routing process on the router.
Page 239 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-80 OSPFv3 Neighbor Table Window The fields that can be configured in OSPFv3 Neighbor Table are described below: Parameter Description Process ID Enter the ID for an IPv6 OSPF routing process here. It is locally assigned and should be unique for each IPv6 OSPF routing process on the router.
Page 240: Ip Multicast Routing Protocol
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide IP Multicast Routing Protocol IGMP IGMP Interface Settings The window is used to find and display the Internet Group Management Protocol (IGMP) feature’s interface settings. To view the following window, click L3 Features > IP Multicast Routing Protocol > IGMP > IGMP...
Page 241 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Apply button to accept the changes made. Click the Find button to locate a specific entry based on the information entered. Click the View All button to display all the entries.
Page 242 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-85 IGMP SSM Mapping Settings Window The fields that can be configured in IGMP SSM Mapping Settings are described below: Parameter Description SSM Mapping State Select to enable or disable the SSM mapping feature for IGMPv1 or IGMPv2 hosts.
Page 243: Mld
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-86 IGMP SSM Mapping Settings (Select) Window The fields that can be configured are described below: Parameter Description ACL Type Select the ACL type that will be used to display the type of existing access lists in the table here.
Page 244 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Interface VLAN Enter the associated VLAN ID of the interface here. The range is from 1 to 4094. Click the Find button to locate a specific entry based on the information entered.
Page 245 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Last Listener Query Interval Enter the interval for the amount of time between group-specific or group-source-specific queries here. When an MLD querier receives a packet to leave the specific group or channel, it will send a group specific query or group source specific query.
Page 246 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-90 MLD SSM Mapping Settings Window The fields that can be configured in MLD SSM Mapping Settings are described below: Parameter Description SSM Mapping State Select to enable or disable the Source Specific Multicast (SSM) mapping feature for groups in the configured SSM range.
Page 247: Igmp Proxy
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-91 MLD SSM Mapping Settings (Select) Window The fields that can be configured are described below: Parameter Description ACL Type Select the ACL type that will be used to display the type of existing access lists in the table here.
Page 248 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-92 IGMP Proxy Settings Window The fields that can be configured in IGMP Proxy Global Settings are described below: Parameter Description Global State Select to globally enable or disable the IGMP proxy feature here.
Page 249 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description multiple IGMP-based forwarders, IGMP proxy uses the IGMP querier election to elect a single forwarder on a LAN. Use this option to make a non-querier device as forwarder. Use the configuration in the appropriate topology.
Page 250: Mld Proxy
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the View All button to display all the entries. MLD Proxy MLD Proxy Settings This window is used to view and configure the MLD proxy settings. The MLD proxy only works in a simple tree topology.
Page 251 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in MLD Proxy Downstream Settings are described below: Parameter Description Interface VLAN Enter the VLAN interface’s ID here. The range is from 1 to 4094.
Page 252: Dvmrp
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide To view the following window, click L3 Features > IP Multicast Routing Protocol > MLD Proxy > MLD Proxy Forwarding Table, as shown below: Figure 6-97 MLD Proxy Forwarding Table Window...
Page 253 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-99 DVMRP Interface Settings (Edit) Window The fields that can be configured in the table are described below: Parameter Description Neighbor Timeout Enter the neighbor’s lifetime value here. If the router has not received a probe message from a neighbor after the neighbor timeout interval, the neighbor is supposed to be down.
Page 254: Pim
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the View All button to display all the entries. DVMRP Neighbor Table This window is used to find and display DVMRP neighbor information. To view the following window, click L3 Features > IP Multicast Routing Protocol > DVMRP > DVMRP...
Page 255 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Mode Select the operation mode of PIM entries used in this filtered search here. Options to choose from are Dense Mode, Sparse Mode, and Sparse-Dense Mode.
Page 256 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description PIM Passive Select to enable or disable the PIM passive feature here. When the passive mode is enabled, the interface will neither send PIM messages out nor accept PIM messages from this interface. The router will act as if it is the only PIM router on the network.
Page 257 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide address and the addresses of the candidate RPs from the maps, and gives as an output one RP address to be used. To view the following window, click L3 Features > IP Multicast Routing Protocol > PIM > PIM for IPv4 >...
Page 258 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide To view the following window, click L3 Features > IP Multicast Routing Protocol > PIM > PIM for IPv4 > PIM RP Address, as shown below: Figure 6-105 PIM RP Address Window...
Page 259 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Find button to display a list of access lists based on the selection made. Click the View All button to display all configured access lists. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Page 260 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Add button to add a new entry based on the information entered. Click the Delete button to delete an entry based on the information entered. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Page 261 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description RP Hash Enter the RP hash address here. Click the Find button to display a list of access lists based on the selection made. Click the View All button to display all configured access lists.
Page 262 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description will start the suppression timer. During the suppression period, a DR stops sending the register message to the RP. Use this feature on the first hop router. The value of the register probe...
Page 263 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide PIM SPT Threshold Settings This window is used to view and configure the PIM SPT threshold settings. Use this feature on the last hop of the router. In the PIM-SM mode, initially the multicast traffic from the source will be flowing along the RPT share tree to the receiver.
Page 264 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description 232/8. Click the Add button to add a new entry based on the information entered. Click the Delete button to delete an entry based on the information entered.
Page 265 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in Neighbor Information Table are described below: Parameter Description Interface Name Enter the VLAN interface’s name here to display PIM-SM neighbor information.
Page 266 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-117 PIM for IPv6 Interface (Edit) Window The fields that can be configured in PIM for IPv6 Interface Detail are described below: Parameter Description Mode Select the IPv6 PIM mode used in this interface here. Options to choose from are None and Sparse Mode.
Page 267 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description For SM-mode, the router will periodically send the join message based on this interval. The hold-time in a Join/Prune message is 3.5 times the join-prune-interval. The receiving router will start a timer based on this hold-time, and prune the interface if no join message is received on this interface.
Page 268 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description with the same seed hash (correspond) to the same RP. Therefore one RP can be derived for multiple groups. Select the Default option to use the default value, which is 126.
Page 269 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-120 PIM for IPv6 RP Address Window The fields that can be configured in RP Address Settings are described below: Parameter Description RP Address Enter the RP’s IPv6 address here.
Page 270 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description ACL List Select the radio button of the access list in the table that will be used here. Click the Find button to display a list of access lists based on the selection made.
Page 271 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Enter a page number and click the Go button to navigate to a specific page when multiple pages exist. After clicking the Show List button, the following page will appear.
Page 272 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Interval Enter the RP candidate’s advertisement interval value here. The range is from 1 to 16383 seconds. Priority Enter the RP’s priority value here. The range is from 0 to 255.
Page 273 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Source Select the source to display here. Options to choose from are Bootstrap, Embedded RP, and Static. • Bootstrap: Specifies to display ranges learned through the BSR.
Page 274 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Register Suppression Enter the register suppression timeout value here. The range is from 3 to 65535 seconds. When a DR receives the register-stop message, it will start the suppression timer. During the suppression time a DR will stop sending Register-encapsulated data to the RP.
Page 275 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide To view the following window, click L3 Features > IP Multicast Routing Protocol > PIM > PIM for IPv6 > PIM for IPv6 SSM Settings, as shown below:...
Page 276 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide PIM for IPv6 (S,G) Keepalive Time This window is used to view and configure the IPv6 PIM (S,G) keep-alive time settings. This feature is used to configure the keep-alive timer, which is the period during which the PIM router will maintain the (S, G) state in the absence of explicit (S, G) local membership or (S, G) join messages received to maintain it.
Page 277: Ipmc
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-133 PIM for IPv6 Neighbor Table Window The fields that can be configured in Neighbor Information Search are described below: Parameter Description Interface Name Enter the VLAN interface’s name used in this display here.
Page 278 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Apply button to accept the changes made. The fields that can be configured in IP Multicast Table Lookup Mode are described below: Parameter Description Table Lookup Mode Select the IP multicast table lookup mode here.
Page 279 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-135 IP Multicast Global Settings (Please Select) Window The fields that can be configured are described below: Parameter Description ACL List Select the radio button of the access list in the table that will be used here.
Page 280 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Summary Selecting this option specifies to display a one-line, abbreviated summary of each entry in the IP multicast routing table. Static Selecting this option specifies to display the multicast static routes.
Page 281 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in IP Multicast Forwarding Table are described below: Parameter Description Group Address Enter the multicast group’s IP address here. Source Address Enter the multicast source’s IP address here.
Page 282: Ipv6Mc
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the View All button to display all the entries. IPv6MC IPv6 Multicast Global Settings This window is used to view and configure the IPv6 multicast feature’s global settings.
Page 283 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-141 IPv6 Static Multicast Route Settings Window The fields that can be configured in IPv6 Static Multicast Route Settings are described below: Parameter Description IPv6 Address/Prefix Length Enter IPv6 network address and prefix length for the multicast source here.
Page 284 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description of each entry in the IPv6 multicast routing table. Click the Find button to locate a specific entry based on the information entered. Click the View All button to display all the entries.
Page 285: Bgp
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide BGP Global Settings This window is used to view and configure the Border Gateway Protocol (BGP) feature’s global settings. To view the following window, click L3 Features > BGP > BGP Global Settings, as shown below:...
Page 286 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description periodically check whether there is a route to reach the next hop in the routing table. Keep-alive Interval Enter the keep-alive interval value here. This is used to send keep- alive messages to BGP peers.
Page 287: Bgp Aggregate Address Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description neighbors. Restart Time Enter the maximum time needed for neighbors to restart here. The range is from 1 to 3600 seconds. By default, this value is 120 seconds.
Page 288: Bgp Network Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide After clicking the Please Select button, the following page will appear. Figure 6-147 BGP Aggregate Address Settings (Please Select) Window The fields that can be configured are described below:...
Page 289: Bgp Route Redistribution Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Route Map Name Enter the route map’s name here. The configured network must be permitted by the specified route map to be advertised. This name can be up to 16 characters long.
Page 290 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Address Family Select the address family used here. Options to choose from are IPv4 Unicast and IPv4 VRF. After selecting the IPv4 VRF option, enter the VRF instance’s name that will be used here.
Page 291: Bgp Route Preference Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Metric Enter the BGP metric value for the redistributed routes here. The range is from 0 to 4294967295. Route Map Name Enter the route map’s name here used to filter the networks to be redistributed.
Page 292 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide As the time passed, the penalty of the route decreased. If the penalty of the route falls below the re-use threshold, the route will be restored as a normal route and update message will be sent for the route.
Page 293: Bgp Dampening Dampened Paths Table
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in BGP Dampening Settings are described below: Parameter Description Half Life Time Enter the half-life time value here after which the accumulated penalty of the route is decreased by half.
Page 294: Bgp Dampening Flap Statistics Table
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-154 BGP Dampening Dampened Paths Table Window The fields that can be configured in BGP Dampening Dampened Paths Table are described below: Parameter Description Address Family Select the address family used here. Options to choose from are IPv4 Unicast and IPv4 VRF.
Page 295: Bgp Reflector Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description provided. Click the Clear button to clear the entries based on the information specified. BGP Reflector Settings This window is used to view and configure the BGP reflector settings. In a large scale BGP network, route reflection is a mechanism used to reduce the needs of fully mesh of iBGP sessions.
Page 296: Bgp Confederation Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description the space provided that will act as the route reflector client. State Select to enable or disable the BGP route reflector client feature for neighbors here.
Page 297: Bgp Community List Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-158 BGP AS Path Access List Settings Window The fields that can be configured in BGP AS Path Access List Settings are described below: Parameter Description List Name Enter the access list’s name here that will be used in the AS path...
Page 298 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-159 BGP Community List Settings Window The fields that can be configured in BGP Community List Settings are described below: Parameter Description List Name Enter the access list’s name here that will be used in the BGP community list configuration.
Page 299: Bgp Extended Community List Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide BGP Extended Community List Settings This window is used to view and configure the BGP feature’s extended community list settings. The extended community attribute is used for implementing policy routing. It is an optional, transitive attribute and facilitates transfer of local policies through different autonomous systems.
Page 300: Bgp Clear Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description from a numbering space that is administered by the user. The number’s range is from 1 to 4294967295 for 2-bytes AS number and 1 to 65535 for 4-bytes AS number.
Page 301: Bgp Summary Table
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description After selecting the IPv4 VRF option, enter the VRF instance’s name that will be used here. This name can be up to 12 characters long. Alternatively, click the Please Select button to open a new window to select and use a configured VRF instance from the list.
Page 302: Bgp Routing Table
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Address Family Select the address family used here. Options to choose from are IPv4 Unicast, VPNv4 All, VPNv4 RD, and VPNv4 VRF. The type of address family determines the routing table that is displayed.
Page 303 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description window to select and use a configured VRF instance from the list. Type Select the type of BGP routing information that will be displayed here. Option to choose from are IP Address, Network, Route Map, CIDR Only, Community, Community List, Filter List, Inconsistent AS, and Quote Regexp.
Page 304 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Find button to generate a display based on the information entered/selected. After clicking the Route Map option and the Type, the following page will appear. Figure 6-166 BGP Routing Table (Type, Route Map) Window...
Page 305 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-168 BGP Routing Table (Type, Community) Window The fields that can be configured are described below: Parameter Description Community Set Enter the community (32-bit integer) here. It can be a user-specified...
Page 306 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Community List Enter the community list’s name here. This name can be up to 16 characters long. Exact Match Selecting this option specifies to display only routes that are an exact match.
Page 307: Bgp Labels Table
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-172 BGP Routing Table (Type, Quote Regexp) Window The fields that can be configured are described below: Parameter Description Regexp Enter regular expression used here. This is used to display routes matching the AS path regular expression.
Page 308: Bgp Neighbor
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide BGP Neighbor Neighbor This window is used to view and configure the BGP neighbor settings. To view the following window, click L3 Features > BGP > BGP Neighbor > Neighbor, as shown below:...
Page 309 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Address Family Select the address family used here. Options to choose from are IPv4 Unicast, VPNv4 All, VPNv4 RD, and VPNv4 VRF. • IPv4 Unicast: Specifies to display information related to the IPv4 unicast address family.
Page 310 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Peer Group This window is used to view and configure BGP neighbor peer group settings. To view the following window, click L3 Features > BGP > BGP Neighbor > Peer Group, as shown...
Page 311 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Alternatively, click the Please Select button to open a new window to select and use a configured VRF instance from the list. • VPNv4: Select to use the VPNv4 address family here.
Page 312 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Neighbor Activate This window is used to activate the exchange of routing information with a specified BGP neighbor. To view the following window, click L3 Features > BGP > BGP Neighbor > Neighbor Activate, as...
Page 313 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Neighbor There are two neighbor options here, IPv4 Address and Peer Group. Select the IPv4 Address option and enter the IP address of the neighbor peer here.
Page 314 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in Neighbor Map Settings are described below: Parameter Description Address Family Select the address family used here. Options to choose from are IPv4 Unicast, IPv4 VRF, and VPNv4.
Page 315 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-182 Neighbor Filter Settings Window The fields that can be configured in Neighbor Filter Settings are described below: Parameter Description Address Family Select the address family used here. Options to choose from are IPv4 Unicast, IPv4 VRF, and VPNv4.
Page 316 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Prefix List Name Enter the prefix list’s name here. This name can be up to 16 characters long. Capability ORF Prefix List Select to enable or disable the capability ORF prefix list action here.
Page 317 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Prefix Warning Only Select to enable or disable the prefix warning feature here. This specifies only to generate a system log message when the threshold is exceeded.
Page 318 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description • VPNv4: Select to use the VPNv4 address family here. Neighbor There are two neighbor options here, IPv4 Address and Peer Group. Select the IPv4 Address option and enter the IP address of the neighbor peer here.
Page 319 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description the Default option to use the default value. Password Enter the BGP neighbor or peer group’s clear text password here. The password is used when the TCP connection between BGP neighbors is established.
Page 320: Ip Route Filter
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-185 Neighbor General Settings (Please Select) Window The fields that can be configured are described below: Parameter Description Select the VRF instance from the list that will be used here.
Page 321: Route Map
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Sequence ID Enter the sequence ID for this rule here. The range is from 1 to 65535. IP Network Address Enter the starting and ending IPv4 addresses in the range used here.
Page 322 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide After clicking the Edit button in the Match Clauses column, the following page will appear. Figure 6-188 Route Map (Match Clauses, Edit) Window The fields that can be configured are described below:...
Page 323 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description community based on the standard or extended IP/IPv6 access list. Extcommunity Select and enter the standard or extended IP/IPv6 access list’s name here. This option is used to define a clause to match the route’s extended community based on the standard or extended IP/IPv6 access list.
Page 324 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Action Select Add to add a new entry based in the information entered. Select Delete to delete an entry based in the information entered. IP Default Next Hop Enter the default next-hop IP addresses in the spaces provided that will be used to route the packet.
Page 325: Policy Route
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description where we can enter value here. They are listed below in order from top to bottom: • Half-Life: Enter the half-life time value here after which the penalty of the reachable routes is decreased by half.
Page 326: Vrrp Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 6-191 Policy Route (Edit) Window The fields that can be configured are described below: Parameter Description Route Map Enter the route map’s name here that will be used in this policy route entry.
Page 327 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description SNMP Server Traps VRRP Select to enable or disable the SNMP server traps feature for the new New master VRRP master. If enabled, once the device has transitioned to the master state, a trap will be sent out.
Page 328 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description Advertisement Interval Enter the advertisement interval value here. This is the time interval between successive VRRP advertisements by the master router. The range is from 1 to 255 seconds.
Page 329: Quality Of Service (Qos)
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Quality of Service (QoS) Basic Settings Advanced Settings QoS PFC WRED Basic Settings Port Default CoS This window is used to view and configure the port’s default CoS settings.
Page 330 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 7-2 Port Scheduler Method Window The fields that can be configured are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 331: Queue Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description different based on the user configuration. To set a CoS queue in the SP mode, any higher priority CoS queue must also be in the strict priority mode.
Page 332: Cos To Queue Mapping
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description WRR Weight Enter the WRR weight value here. This value must be between 0 and 127. To satisfy the behavior requirements of Expedited Forwarding (EF), the highest queue is always selected by the Per-hop Behavior (PHB) EF and the schedule mode of this queue should be strict priority scheduling.
Page 333: Queue Rate Limiting
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 7-5 Port Rate Limiting Window The fields that can be configured are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 334 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 7-6 Queue Rate Limiting Window The fields that can be configured are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 335: Advanced Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Advanced Settings DSCP Mutation Map This window is used to view and configure the Differentiated Services Code Point (DSCP) mutation map settings. When a packet is received by an interface, based on a DSCP mutation map, the incoming DSCP can be mutated to another DSCP immediately before any QoS operations.
Page 336: Dscp Cos Mapping
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 7-8 Port Trust State and Mutation Binding Window The fields that can be configured are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 337: Cos Color Mapping
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 7-9 DSCP CoS Mapping Window The fields that can be configured are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 338: Dscp Color Mapping
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 7-10 CoS Color Mapping Window The fields that can be configured are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 339: Class Map
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here. From Port ~ To Port Select the range of ports that will be used for this configuration here.
Page 340: Aggregate Policer
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description None Select this option to match nothing to this class map. Specify Select the option to match something to this class map.
Page 341 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Aggregate Policer Name Enter the aggregate policer’s name here. Average Rate Enter the average rate value here. This value must be between 0 and 10000000 kbps.
Page 342 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description transmit value in the space provided. This value sets the 802.1p value and transmits the packet with the new value. • When selecting the Set-DSCP-1P option, enter the IP DSCP and 1P transmit values in the spaces provided.
Page 343 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description DSCP value in the space provided. This value sets the IP differentiated services code point (DSCP) value and transmits the packet with the new IP DSCP value.
Page 344: Policy Map
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Policy Map This window is used to view and configure the policy map settings. To view the following window, click QoS > Advanced Settings > Policy Map, as shown below:...
Page 345: Qos Pfc
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 7-17 Policy Binding Window The fields that can be configured are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 346: Network Qos Policy Map
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Network QoS Class Map Enter the network QoS class map’s name to be associated with a Name traffic policy here. This name can be up to 32 characters long.
Page 347 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in Create/Delete Network QoS Policy Map are described below: Parameter Description Network QoS Policy Map Enter the network QoS policy map’s name here. This name can be up name to 32 characters long.
Page 348: Network Qos Policy Binding
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Network QoS Policy Binding This window is used to view and configure the network QoS policy’s binding settings. To view the following window, click QoS > QoS PFC > Network QoS Policy Binding, as shown below:...
Page 349 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 7-23 WRED Profile Window The fields that can be configured are described below: Parameter Description Profile Enter the WRED profile’s ID here. The range is from 1 to 128.
Page 350: Wred Queue
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Find button to locate a specific entry based on the information entered. Click the Delete button to reset the configuration on the specified entry. WRED Queue This window is used to view and configure the WRED feature’s queue settings.
Page 351: Wred Drop Counter
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide WRED Drop Counter This window is used to view and clear the WRED feature’s drop counter information. To view the following window, click QoS > WRED > WRED Drop Counter, as shown below:...
Page 352: Ets Recommend Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in ETS Port Settings are described below: Parameter Description Unit Select the switch’s unit ID that will be used here. From Port ~ To Port Select the switch’s port range that will be used here.
Page 353: Qcn
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 7-28 ETS Recommend Settings Window The fields that can be configured are described below: Parameter Description Unit Select the switch’s unit ID that will be used here.
Page 354: Qcn Cnpv Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide QCN is a form of end-to-end congestion management defined in IEEE 802.1.Qau. The purpose of QCN is to ensure that congestion is controlled from the sending device to the receiving device in a dynamic fashion that can deal with changing bottlenecks.
Page 355 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description QCN CNPV Select the IEEE 802.1p priority value to be the Congestion Notification Priority Value (CNPV) here. The range is from 0 to 7. Select the None option to use the default value.
Page 356: Qcn Cnpv Interface Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Apply button to accept the changes made. QCN CNPV Interface Settings This window is used to view and configure the QCN CNPV interface settings. To view the following window, click QoS > QCN > QCN CNPV Interface Settings, as shown below:...
Page 357: Qcn Cnpv Interface Simple
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description • Edge: Specifies that the priority parameter of frame input at this priority is remapped to an alternate value. Frames at other priorities are not remapped to this priority and the frames are transmitted without a CN-TAG.
Page 358 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 7-34 QCN CP Interface Settings Window The fields that can be configured in QCN CP Interface Settings are described below: Parameter Description Unit Select the switch’s unit ID that will be used here.
Page 359: Qcn Cp Counters
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide QCN CP Counters This window is used to view and clear the QCN CP counters. To view the following window, click QoS > QCN > QCN CP Counters, as shown below:...
Page 360 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in QCN CPID Table are described below: Parameter Description QCN CPID Enter the Congestion Point Identifier (CPID) to get the corresponding interface ID and CP index. This ID is 16 hexadecimal digits long.
Page 361: Access Control List (Acl)
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Access Control List (ACL) ACL Configuration Wizard ACL Access List ACL Interface Access Group ACL VLAN Access Map ACL VLAN Filter CPU ACL ACL Configuration Wizard This window is used to guide the user to create a new ACL access list or configure an existing ACL access list.
Page 362: Step 2 - Select Packet Type
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description configuration wizard. ACL Name Enter the new ACL’s name here. This name can be up to 32 characters long. Update Select this option to update an existing ACL access list. Select the existing ACL in the table to process with the update.
Page 363 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-4 ACL Configuration Wizard (Create, Packet Type, MAC) Window The fields that can be configured are described below: Parameter Description Sequence No. Enter the ACL rule number here. This value must be between 1 and 65535.
Page 364 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description be between 0x0 and 0xFFFF. When any Ethernet type profile is selected in the Specify Ethernet Type drop-down list, the appropriate hexadecimal value will automatically be entered.
Page 365 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Sequence No. Enter the ACL rule number here. This value must be between 1 and 65535. Select Auto Assign to automatically generate an ACL rule number for this entry.
Page 366 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description bitmap. The bit corresponding to the bit value 1 will be ignored. The bit corresponding to the bit value 0 will be checked. Destination Select and enter the destination information here. Options to choose from are Any, Host, and IP.
Page 367 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-7 ACL Configuration Wizard (Create, Packet Type, IPv4, UDP) Window The fields that can be configured in Assign rule criteria are described below: Parameter Description Source Select and enter the source information here. Options to choose from are Any, Host, and IP.
Page 368 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Destination Port Select and enter the destination port value here. Options to choose from are =, >, <, ≠, and Range. When selecting the = option, the specific selected port number will be used.
Page 369 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-8 ACL Configuration Wizard (Create, Packet Type, IPv4, ICMP) Window The fields that can be configured in Assign rule criteria are described below: Parameter Description Source Select and enter the source information here. Options to choose from are Any, Host, and IP.
Page 370 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description After selecting the IP precedence value, select the Type-of-Service (ToS) value that will be used here. Options to choose from are 0 (normal), 1 (min-monetary-cost), 2 (max-reliability), 3, 4 (max- throughput), 5, 6, 7, 8 (min-delay), 9, 10, 11, 12, 13, 14, and 15.
Page 371 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description destination traffic will be evaluated according to the conditions of this rule. When the Host option is selected, enter the destination host’s IP address here. When the IP option is selected, the Wildcard option will also be available.
Page 372 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description are Any, Host, and IP. When the Any option is selected, any source traffic will be evaluated according to the conditions of this rule. When the Host option is selected, enter the source host’s IP address here.
Page 373 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-11 ACL Configuration Wizard (Create, Packet Type, IPv4, GRE) Window The fields that can be configured in Assign rule criteria are described below: Parameter Description Source Select and enter the source information here. Options to choose from are Any, Host, and IP.
Page 374 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Back button to return to the previous window. Click the Next button to continue. Protocol Type - IGMP After selecting the IGMP option as the Protocol Type, the following section will appear.
Page 375 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description throughput), 5, 6, 7, 8 (min-delay), 9, 10, 11, 12, 13, 14, and 15. DSCP Select or enter the DSCP value used here. This value must be between 0 and 63.
Page 376 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description also be available. Enter the group of destination IP addresses by using a wildcard bitmap. The bit corresponding to the bit value 1 will be ignored. The bit corresponding to the bit value 0 will be checked.
Page 377 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description When the IP option is selected, the Wildcard option will also be available. Enter the group of source IP addresses by using a wildcard bitmap. The bit corresponding to the bit value 1 will be ignored. The bit corresponding to the bit value 0 will be checked.
Page 378 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in Assign rule criteria are described below: Parameter Description Source Select and enter the source information here. Options to choose from are Any, Host, and IP. When the Any option is selected, any source traffic will be evaluated according to the conditions of this rule.
Page 379 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-16 ACL Configuration Wizard (Create, Packet Type, IPv4, IP-in-IP) Window The fields that can be configured in Assign rule criteria are described below: Parameter Description Source Select and enter the source information here. Options to choose from are Any, Host, and IP.
Page 380 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Back button to return to the previous window. Click the Next button to continue. Protocol Type - PCP After selecting the PCP option as the Protocol Type, the following section will appear.
Page 381 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description throughput), 5, 6, 7, 8 (min-delay), 9, 10, 11, 12, 13, 14, and 15. DSCP Select or enter the DSCP value used here. This value must be between 0 and 63.
Page 382 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description also be available. Enter the group of destination IP addresses by using a wildcard bitmap. The bit corresponding to the bit value 1 will be ignored. The bit corresponding to the bit value 0 will be checked.
Page 383 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description When the IP option is selected, the Wildcard option will also be available. Enter the group of source IP addresses by using a wildcard bitmap. The bit corresponding to the bit value 1 will be ignored. The bit corresponding to the bit value 0 will be checked.
Page 384 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide IPv6 After clicking the IPv6 radio button and the Next button, the following window will appear. Figure 8-20 ACL Configuration Wizard (Create, Packet Type, IPv6) Window The fields that can be configured are described below:...
Page 385 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-21 ACL Configuration Wizard (Create, Packet Type, IPv6, TCP) Window The fields that can be configured in Assign rule criteria are described below: Parameter Description Source Select and enter the source information here. Options to choose from are Any, Host, and IPv6.
Page 386 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description port number(s) is/are not available in the drop-down list. Destination Port Select and enter the destination port value here. Options to choose from are =, >, <, ≠, and Range. When selecting the = option, the specific selected port number will be used.
Page 387 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-22 ACL Configuration Wizard (Create, Packet Type, IPv6, UDP) Window The fields that can be configured in Assign rule criteria are described below: Parameter Description Source Select and enter the source information here. Options to choose from are Any, Host, and IPv6.
Page 388 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Destination Port Select and enter the destination port value here. Options to choose from are =, >, <, ≠, and Range. When selecting the = option, the specific selected port number will be used.
Page 389 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in Assign rule criteria are described below: Parameter Description Source Select and enter the source information here. Options to choose from are Any, Host, and IPv6. When the Any option is selected, any source traffic will be evaluated according to the conditions of this rule.
Page 390 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-24 ACL Configuration Wizard (Create, Packet Type, IPv6, Protocol ID) Window The fields that can be configured in Assign rule criteria are described below: Parameter Description Source Select and enter the source information here.
Page 391 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Protocol Type - ESP After selecting the ESP option as the Protocol Type, the following section will appear. Figure 8-25 ACL Configuration Wizard (Create, Packet Type, IPv6, ESP) Window...
Page 392 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Protocol Type - PCP After selecting the PCP option as the Protocol Type, the following section will appear. Figure 8-26 ACL Configuration Wizard (Create, Packet Type, IPv6, PCP) Window...
Page 393 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Next button to continue. Protocol Type - SCTP After selecting the SCTP option as the Protocol Type, the following section will appear. Figure 8-27 ACL Configuration Wizard (Create, Packet Type, IPv6, SCTP) Window...
Page 394 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Back button to return to the previous window. Click the Next button to continue. Protocol Type - None After selecting the None option as the Protocol Type, the following section will appear.
Page 395: Step 4 - Apply Port
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description are Permit and Deny. Click the Back button to return to the previous window. Click the Next button to continue. Step 4 - Apply Port After clicking the Next button, the following window will appear.
Page 396: Standard Ip Acl
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description ACL, IPv6 ACL, MAC ACL, and Expert ACL. Select and enter the access list’s ID here. The range is from 1 to 14999. ACL Name Select and enter the access list’s name here. This name can be up to 32 characters long.
Page 397 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-32 Standard IP ACL (Main) Window Click the Edit button to re-configure the specific ACL. Click the Delete button to remove the specific ACL. To add an ACL rule in the ACL, select it (the ACL will toggle to the bold font), and click the Add Rule button.
Page 398 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Sequence No. Enter the ACL rule number here. This value must be between 1 and 65535. If this value is not specified, the system will automatically generate an ACL rule number for this entry.
Page 399: Extended Ip Acl
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Remark Enter an optional remark that will be associated with this ACL here. Click the Apply button to accept the changes made. Click the Delete button to remove the specific entry.
Page 400 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide After creating an Extended IP ACL, the newly created Extended IP ACL will be displayed in the ACL display table, as shown below: Figure 8-38 Extended IP ACL (Main) Window Click the Edit button to re-configure the specific ACL.
Page 401 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-40 Extended IP ACL (Add Rule) Window This is a dynamic page. Every selection made in the Protocol Type option will change the bottom part of this page.
Page 402 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-41 Extended IP ACL (Add Rule) TCP Window The dynamic fields that can be configured are described below: Parameter Description Source Select and enter the source information here. Options to choose from are Any, Host, IP, and Wildcard.
Page 403 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Destination Port Select and enter the destination port value here. Options to choose from are =, >, <, ≠, and Range. When selecting the = option, the specific selected port number will be used.
Page 404 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The dynamic fields that can be configured are described below: Parameter Description Source Select and enter the source information here. Options to choose from are Any, Host, IP, and Wildcard. When the Any option is selected, any source traffic will be evaluated according to the conditions of this rule.
Page 405 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide After selecting the ICMP option as the Protocol Type, the following page and parameters will be available, as shown below: Figure 8-43 Extended IP ACL (Add Rule) ICMP Window...
Page 406 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description 5 (critical), 6 (internet), and 7 (network). After selecting the IP precedence value, select the Type-of-Service (ToS) value that will be used here. Options to choose from are 0 (normal), 1 (min-monetary- cost), 2 (max-reliability), 3, 4 (max-throughput), 5, 6, 7, 8 (min- delay), 9, 10, 11, 12, 13, 14, and 15.
Page 407 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description IP addresses by using a wildcard bitmap. The bit corresponding to the bit value 1 will be ignored. The bit corresponding to the bit value 0 will be checked.
Page 408 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Destination Select and enter the destination information here. Options to choose from are Any, Host, IP, and Wildcard. When the Any option is selected, any destination traffic will be evaluated according to the conditions of this rule.
Page 409 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description rule. When the Host option is selected, enter the source host’s IP address here. When the IP option is selected, the Wildcard option will also be available. Enter the group of source IP addresses by using a wildcard bitmap.
Page 410 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Fragments Select the Fragments option to include packet fragment filtering. Source Select and enter the source information here. Options to choose from are Any, Host, IP, and Wildcard. When the Any option is selected, any source traffic will be evaluated according to the conditions of this rule.
Page 411 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The dynamic fields that can be configured are described below: Parameter Description Fragments Select the Fragments option to include packet fragment filtering. Source Select and enter the source information here. Options to choose from are Any, Host, IP, and Wildcard.
Page 412 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-49 Extended IP ACL (Add Rule) PIM Window The dynamic fields that can be configured are described below: Parameter Description Fragments Select the Fragments option to include packet fragment filtering.
Page 413 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide After selecting the VRRP option as the Protocol Type, the following page and parameters will be available, as shown below: Figure 8-50 Extended IP ACL (Add Rule) VRRP Window...
Page 414 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description between 0 and 63. Time Range Enter the time profile name that will be associated with this ACL rule, here. After selecting the IP-in-IP option as the Protocol Type, the following page and parameters will be...
Page 415 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description cost), 2 (max-reliability), 3, 4 (max-throughput), 5, 6, 7, 8 (min- delay), 9, 10, 11, 12, 13, 14, and 15. Select the Type of Service option here. Options to choose from are 0 to 15.
Page 416 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description IP Precedence Select the IP precedence value used here. Options to choose from are 0 (routine), 1 (priority), 2, (immediate), 3 (flash), 4 (flash-override), 5 (critical), 6 (internet), and 7 (network). After selecting the IP precedence value, select the Type-of-Service (ToS) value that will be used here.
Page 417 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description from are Any, Host, IP, and Wildcard. When the Any option is selected, any destination traffic will be evaluated according to the conditions of this rule. When the Host option is selected, enter the destination host’s IP address here.
Page 418 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description address here. When the IP option is selected, the Wildcard option will also be available. Enter the group of source IP addresses by using a wildcard bitmap. The bit corresponding to the bit value 1 will be ignored.
Page 419: Standard Ipv6 Acl
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Stop Enter the stop sequence number here. Counter State Select to enable or disable the counter state option here. Remark Enter an optional remark that will be associated with this ACL here.
Page 420 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description ACL Name Enter the ACL’s name here. This name can be up to 32 characters long. Click the Apply button to create the new ACL. After creating a Standard IPv6 ACL, the newly created Standard IPv6 ACL will be displayed in the ACL...
Page 421 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-60 Standard IPv6 ACL (Add Rule) Window The fields that can be configured are described below: Parameter Description Sequence No. Enter the ACL rule number here. This value must be between 1 and 65535.
Page 422 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-61 Standard IPv6 ACL (Counter State Enabled) Window The fields that can be configured are described below: Parameter Description Start Sequence No. Enter the start sequence number here.
Page 423: Extended Ipv6 Acl
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Extended IPv6 ACL After clicking the Add ACL button, users can create a new ACL, as shown below: Figure 8-63 Extended IPv6 ACL (Add ACL) Window The fields that can be configured are described below:...
Page 424 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-65 Extended IPv6 ACL (Selected) Window After selecting the ACL and clicking the Add Rule button, users can configure the new ACL rule, in the selected ACL, as shown below: Figure 8-66 Extended IPv6 ACL (Add Rule) Window This is a dynamic page.
Page 425 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Action Select the action that this rule will take here. Options to choose from are Permit and Deny. Protocol Type Select the protocol type option here. Options to choose from are TCP, UDP, ICMP, Protocol ID, ESP, PCP, SCTP, and None.
Page 426 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description selected port number will be used. When selecting the > option, all ports greater than the selected port, will be used. When selecting the < option, all ports smaller than the selected port, will be used. When selecting the ≠...
Page 427 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-68 Extended IPv6 ACL (Add Rule) UDP Window The dynamic fields that can be configured are described below: Parameter Description Source Select and enter the source information here. Options to choose from are Any, Host, IPv6, and Prefix Length.
Page 428 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description option, all ports greater than the selected port, will be used. When selecting the < option, all ports smaller than the selected port, will be used. When selecting the ≠ option, all ports, excluding the selected port, will be used.
Page 429 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description selected, any destination traffic will be evaluated according to the conditions of this rule. When the Host option is selected, enter the destination host’s IPv6 address here. When the IPv6 option is selected, the Prefix Length option will also be available.
Page 430 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description selected, any source traffic will be evaluated according to the conditions of this rule. When the Host option is selected, enter the source host’s IPv6 address here. When the IPv6 option is selected, the Prefix Length option will also be available.
Page 431 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description address and prefix length value in the spaces provided. Destination Select and enter the destination information here. Options to choose from are Any, Host, IPv6, and Prefix Length. When the Any option is selected, any destination traffic will be evaluated according to the conditions of this rule.
Page 432 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description conditions of this rule. When the Host option is selected, enter the destination host’s IPv6 address here. When the IPv6 option is selected, the Prefix Length option will also be available. Enter the destination IPv6 address and prefix length value in the spaces provided.
Page 433 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description provided. DSCP Select or enter the DSCP value used here. This value must be between 0 and 63. Flow Label Enter the flow label value here. This value must be between 0 and 1048575.
Page 434 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Flow Label Enter the flow label value here. This value must be between 0 and 1048575. Time Range Enter the time profile name that will be associated with this ACL rule, here.
Page 435: Extended Mac Acl
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-76 Extended IPv6 ACL (Rule Display) Window Click the Delete button to remove the specific ACL rule. Extended MAC ACL After clicking the Add ACL button, users can create a new ACL, as shown below:...
Page 436 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-78 Extended MAC ACL (Main) Window Click the Edit button to re-configure the specific ACL. Click the Delete button to remove the specific ACL. To add an ACL rule in the ACL, select it (the ACL will toggle to the bold font), and click on the Add Rule button.
Page 437 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-80 Extended MAC ACL (Add Rule) Window The fields that can be configured are described below: Parameter Description Sequence No. Enter the ACL rule number here. This value must be between 1 and 65535.
Page 438 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description selected, above, the appropriate hexadecimal value will automatically be entered. Select the CoS value used here. This value is between 0 and 7. Inner CoS Select the inner CoS value used here. This value is between 0 and 7.
Page 439: Extended Expert Acl
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-82 Extended MAC ACL (Rule Display) Window Click the Delete button to remove the specific ACL rule. Extended Expert ACL After clicking the Add ACL button, users can create a new ACL, as shown below:...
Page 440 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-84 Extended Expert ACL (Main) Window Click the Edit button to re-configure the specific ACL. Click the Delete button to remove the specific ACL. To add an ACL rule in the ACL, select it (the ACL will toggle to the bold font), and click on the Add Rule button.
Page 441 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-86 Extended Expert ACL (Add Rule) Window This is a dynamic page. Every selection made in the Protocol Type option will change the bottom part of this page.
Page 442 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-87 Extended Expert ACL (Add Rule) TCP Window The dynamic fields that can be configured are described below: Parameter Description Source IP Address Select and enter the source information here. Options to choose from are Any, Host, IP, and Wildcard.
Page 443 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Destination MAC Address Select and enter the destination information here. Options to choose from are Any, Host, MAC, and Wildcard. When the Any option is selected, any destination traffic will be evaluated according to the conditions of this rule.
Page 444 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide After selecting the UDP option as the Protocol Type, the following page and parameters will be available, as shown below: Figure 8-88 Extended Expert ACL (Add Rule) UDP Window...
Page 445 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description value in the spaces provided. Destination MAC Address Select and enter the destination information here. Options to choose from are Any, Host, MAC, and Wildcard. When the Any option is selected, any destination traffic will be evaluated according to the conditions of this rule.
Page 446 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide After selecting the ICMP option as the Protocol Type, the following page and parameters will be available, as shown below: Figure 8-89 Extended Expert ACL (Add Rule) ICMP Window...
Page 447 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Destination MAC Address Select and enter the destination information here. Options to choose from are Any, Host, MAC, and Wildcard. When the Any option is selected, any destination traffic will be evaluated according to the conditions of this rule.
Page 448 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-90 Extended Expert ACL (Add Rule) EIGRP Window The dynamic fields that can be configured are described below: Parameter Description Fragments Select the Fragments option to include packet fragment filtering.
Page 449 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description destination host’s MAC address here. When the MAC option is selected, the Wildcard option will also be available. Enter the destination MAC address and wildcard value in the spaces provided.
Page 450 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The dynamic fields that can be configured are described below: Parameter Description Fragments Select the Fragments option to include packet fragment filtering. Source IP Address Select and enter the source information here. Options to choose from are Any, Host, IP, and Wildcard.
Page 451 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Time Range Enter the time profile name that will be associated with this ACL rule, here. After selecting the GRE option as the Protocol Type, the following page and parameters will be available,...
Page 452 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description rule. When the Host option is selected, enter the source host’s MAC address here. When the MAC option is selected, the Wildcard option will also be available. Enter the source MAC address and wildcard value in the spaces provided.
Page 453 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-93 Extended Expert ACL (Add Rule) IGMP Window The dynamic fields that can be configured are described below: Parameter Description Fragments Select the Fragments option to include packet fragment filtering.
Page 454 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description destination host’s MAC address here. When the MAC option is selected, the Wildcard option will also be available. Enter the destination MAC address and wildcard value in the spaces provided.
Page 455 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The dynamic fields that can be configured are described below: Parameter Description Fragments Select the Fragments option to include packet fragment filtering. Source IP Address Select and enter the source information here. Options to choose from are Any, Host, IP, and Wildcard.
Page 456 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Time Range Enter the time profile name that will be associated with this ACL rule, here. After selecting the PIM option as the Protocol Type, the following page and parameters will be available,...
Page 457 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description rule. When the Host option is selected, enter the source host’s MAC address here. When the MAC option is selected, the Wildcard option will also be available. Enter the source MAC address and wildcard value in the spaces provided.
Page 458 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-96 Extended Expert ACL (Add Rule) VRRP Window The dynamic fields that can be configured are described below: Parameter Description Fragments Select the Fragments option to include packet fragment filtering.
Page 459 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description destination host’s MAC address here. When the MAC option is selected, the Wildcard option will also be available. Enter the destination MAC address and wildcard value in the spaces provided.
Page 460 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The dynamic fields that can be configured are described below: Parameter Description Fragments Select the Fragments option to include packet fragment filtering. Source IP Address Select and enter the source information here. Options to choose from are Any, Host, IP, and Wildcard.
Page 461 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Time Range Enter the time profile name that will be associated with this ACL rule, here. After selecting the PCP option as the Protocol Type, the following page and parameters will be available,...
Page 462 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description rule. When the Host option is selected, enter the source host’s MAC address here. When the MAC option is selected, the Wildcard option will also be available. Enter the source MAC address and wildcard value in the spaces provided.
Page 463 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-99 Extended Expert ACL (Add Rule) Protocol ID Window The dynamic fields that can be configured are described below: Parameter Description Protocol Enter the Protocol ID value used here. This value must be between 0 and 255.
Page 464 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description from are Any, Host, MAC, and Wildcard. When the Any option is selected, any destination traffic will be evaluated according to the conditions of this rule. When the Host option is selected, enter the destination host’s MAC address here.
Page 465 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-100 Extended Expert ACL (Add Rule) None Window The dynamic fields that can be configured are described below: Parameter Description Fragments Select the Fragments option to include packet fragment filtering.
Page 466 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description destination host’s MAC address here. When the MAC option is selected, the Wildcard option will also be available. Enter the destination MAC address and wildcard value in the spaces provided.
Page 467: Acl Interface Access Group
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Start Sequence No. Enter the start sequence number here. Stop Enter the stop sequence number here. Counter State Select to enable or disable the counter state option here.
Page 468: Acl Vlan Access Map
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-103 ACL Interface Access Group Window The fields that can be configured are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 469 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-104 ACL VLAN Access Map Window The fields that can be configured are described below: Parameter Description Access Map Name Enter the access map’s name here. This name can be up to 32 characters long.
Page 470: Acl Vlan Filter
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-105 ACL VLAN Access Map (Binding) Window The fields that can be configured are described below: Parameter Description Match IP Access-List Here the IP access list that will be matched will be displayed.
Page 471: Cpu Acl
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 8-107 ACL VLAN Filter Window The fields that can be configured are described below: Parameter Description Access Map Name Enter the access map’s name here. This name can be up to 32 characters long.
Page 472 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Delete button to delete the specified entry. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Page 473 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Delete button to delete the specified entry. The fields that can be configured in Match MAC Access List are described below: Parameter Description Sequence No. Enter the sequence number of the associated match entry here. The range is from 1 to 65535.
Page 474 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description ACL List Select the radio button next to the access list entry to use that access list in the configuration. Click the OK button to accept the selection made.
Page 475: Security
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Security Port Security 802.1X RADIUS TACACS IMPB DHCP Server Screening ARP Spoofing Prevention BPDU Attack Protection MAC Authentication Web-based Access Control Network Access Authentication Safeguard Engine Trusted Host...
Page 476: Port Security Port Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Trap State Click to enable or disable port security traps on the Switch. Click the Apply button to accept the changes made. The fields that can be configured in Port Security Trap Rate Settings are described below:...
Page 477 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 9-2 Port Security Port Settings Window The fields that can be configured in Port Security Settings are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 478: Port Security Address Entries
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description • Selecting Inactivity specifies that the secure addresses on this port age out only if there is no data traffic from the secure source address for the specified time period.
Page 479 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The following figure represents a basic EAPOL packet: Figure 9-4 The EAPOL Packet Utilizing this method, unauthorized devices are restricted from connecting to a LAN through a port to which the user is connected.
Page 480 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 9-6 The Authentication Server Authenticator The Authenticator (the Switch) is an intermediary between the Authentication Server and the Client. The Authenticator serves two purposes when utilizing the 802.1X function. The first purpose is to request certification information from the Client through EAPOL packets, which is the only information allowed to pass through the Authenticator before access is granted to the Client.
Page 481 Figure 9-9 The 802.1X Authentication Process The D-Link implementation of 802.1X allows network administrators to choose between two types of Access Control used on the Switch, which are:...
Page 482 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide • Port-based Access Control - This method requires only one user to be authenticated per port by a remote RADIUS server to allow the remaining users on the same port access to the network.
Page 483: 802.1X Global Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide and effectively creates a logical Port that the attached device can then use to communicate with the LAN via the Switch. Figure 9-11 Example of Typical Host-based Configuration 802.1X Global Settings...
Page 484 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 9-13 802.1X Port Settings Window The fields that can be configured in 802.1X Port Settings are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 485: Authentication Sessions Information
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Authentication Sessions Information This window is used to view and configure the authentication session information. To view the following window, click Security > 802.1X > Authentication Sessions Information, as...
Page 486: Authenticator Session Statistics
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Port Select the appropriate port used for the query here. Click the Find button to locate a specific entry based on the information entered. Click the Clear Counters button to clear the counter information based on the selections made.
Page 487: Aaa
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 9-17 Authenticator Diagnostics Window The fields that can be configured in Authenticator Diagnostics are described below: Parameter Description Unit Select the switch unit that will be used for this query here.
Page 488: Application Authentication Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description AAA State Select to enable or disable the Authentication, Authorization, and Accounting (AAA) global state. Click the Apply button to accept the changes made. Application Authentication Settings This window is used to view and configure the application authentication settings.
Page 489 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 9-21 Application Accounting Settings Window Click the Edit button to re-configure the specific entry. Figure 9-22 Application Accounting Settings (Edit) Window The fields that can be configured in Application Accounting Exec Method list are described below:...
Page 490: Authentication Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Delete button to remove the specified entry. Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
Page 491: Accounting Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide After clicking the AAA Authentication Exec tab, the following page will appear. Figure 9-24 Authentication Settings (AAA Authentication EXEC) Window The fields that can be configured in AAA Authentication Enable are described below:...
Page 492 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in AAA Accounting Network are described below: Parameter Description Default Select to enable or disable the use of the default method list here.
Page 493: Radius
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide After clicking the AAA Accounting Commands tab, the following page will appear. Figure 9-28 Accounting Settings (AAA Accounting Commands) Window The fields that can be configured in AAA Accounting Commands are described below:...
Page 494: Radius Server Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description DeadTime Enter the dead time value here. This value must be between 1 and 1440 minutes. By default, this value is 0 minutes. When this option is 0, the unresponsive server will not be marked as dead.
Page 495: Radius Group Server Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 9-30 RADIUS Server Settings Window The fields that can be configured in RADIUS Server Settings are described below: Parameter Description IP Address Enter the RADIUS server’s IPv4 address here.
Page 496 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in RADIUS Group Server Settings are described below: Parameter Description Group Server Name Enter the RADIUS group server’s name here. This name can be up to 32 characters long.
Page 497: Radius Statistic
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide RADIUS Statistic This window is used to view and clear the RADIUS statistics information. To view the following window, click Security > RADIUS > RADIUS Statistic, as shown below:...
Page 498: Tacacs Group Server Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 9-34 TACACS Server Settings Window The fields that can be configured in TACACS Server Settings are described below: Parameter Description IP Address Enter the TACACS server’s IPv4 address here.
Page 499: Tacacs Statistic
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description here. This name can be up to 12 characters long. IPv4 TACACS Server IP Enter the group server’s IPv4 address here. IPv6 TACACS Server IP Enter the group server’s IPv6 address here.
Page 500 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide To view the following window, click Security > IMPB > IPv4 > DHCPv4 Snooping > DHCP Snooping Global Settings, as shown below: Figure 9-37 DHCP Snooping Global Settings Window...
Page 501 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Unit Select the switch unit that will be used for this configuration here. From Port ~ To Port Select the appropriate port range used for the configuration here.
Page 502 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 9-40 DHCP Snooping Database Window The fields that can be configured in DHCP Snooping Database are described below: Parameter Description Write Delay Enter the write delay time value here. This value must be between 60 and 86400 seconds.
Page 503 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide To view the following window, click Security > IMPB > IPv4 > DHCPv4 Snooping > DHCP Snooping Binding Entry, as shown below: Figure 9-41 DHCP Snooping Binding Entry Window...
Page 504 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in ARP Access List are described below: Parameter Description ARP Access List Name Enter the ARP access list name used here. This name can be up to 32 characters long.
Page 505 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 9-44 ARP Inspection Settings Window The fields that can be configured in ARP Inspection Validation are described below: Parameter Description Src-MAC Select to enable of disable the source MAC option here. This option...
Page 506 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide ARP Inspection Port Settings This window is used to view and configure the ARP inspection port settings. To view the following window, click Security > IMPB > IPv4 > Dynamic ARP Inspection > ARP...
Page 507 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description VID List Enter the VLAN ID list used here. State Select to enable or disable the ARP inspection option’s state for the specified VLAN here. Click the Apply button to accept the changes made.
Page 508 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Clear Log button to clear the log. IP Source Guard IP Source Guard Port Settings This window is used to view and configure the IP source guard port settings.
Page 509 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 9-50 IP Source Guard Binding Window The fields that can be configured in IP Source Binding Settings are described below: Parameter Description MAC Address Enter the MAC address of the binding entry here.
Page 510 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide IP Source Guard HW Entry This window is used to view the IP source guard hardware entries. To view the following window, click Security > IMPB > IPv4 > IP Source Guard > IP Source Guard HW...
Page 511 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in IP-MAC-Port Binding Trap Settings are described below: Parameter Description Trap State Select the enable or disable the IP-MAC-Port binding option’s trap state.
Page 512: Ipv6
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Clear by MAC Select this option to clear the entry table based on the MAC address entered. Enter the MAC address that will be cleared in the space provided.
Page 513 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Duplicate Address Detection first. ND snooping detects DAD messages (DAD NS and DAD NA) to build its binding database. The NDP packet (NS and NA) is also used to detect whether a host is still reachable and determine whether to delete a binding or not.
Page 514 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide IPv6 RA Guard This window is used to view and configure the IPv6 Router Advertisement (RA) guard settings. To view the following window, click Security > IMPB > IPv6 > IPv6 RA Guard, as shown below:...
Page 515 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 9-57 IPv6 DHCP Guard Window The fields that can be configured in IPv6 DHCP Guard are described below: Parameter Description Policy Name Enter the policy name here. This name can be up to 32 characters long.
Page 516 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in IPv6 Source Guard Settings are described below: Parameter Description Policy Name Enter the policy name here. This name can be up to 32 characters long.
Page 517: Dhcp Server Screening
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Unit Select the switch unit that will be used for this configuration here. From Port ~ To Port Select the appropriate port range used for the configuration here.
Page 518: Dhcp Server Screening Port Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 9-60 DHCP Server Screening Global Settings Window The fields that can be configured in Trap Settings are described below: Parameter Description Trap State Select to enable or disable the DHCP server screening trap here.
Page 519: Arp Spoofing Prevention
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 9-61 DHCP Server Screening Port Settings Window The fields that can be configured in DHCP Server Screening Port Settings are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 520: Bpdu Attack Protection
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 9-62 ARP Spoofing Prevention Window The fields that can be configured in ARP Spoofing Prevention are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 521 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 9-63 BPDU Attack Protection Window The fields that can be configured in BPDU Attack Protection Global Settings are described below: Parameter Description BPDU Attack Protection State Select to enable or disable the BPDU attack protection feature’s global state here.
Page 522: Mac Authentication
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide MAC Authentication This window is used to view and configure the MAC authentication settings. MAC authentication is a feature designed to authenticate a user by MAC address when the user is trying to access the network via the Switch.
Page 523: Web-Based Access Control
RADIUS server. The client user initiates the authentication process of WAC by attempting to gain Web access. D-Link’s implementation of WAC uses a virtual IP that is exclusively used by the WAC function and is not known by any other modules of the Switch. In fact, to avoid affecting a Switch’s other features, WAC will only use a virtual IP address to communicate with hosts.
Page 524 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 9-65 RADIUS Authentication Server Conditions and Limitations • If the client is utilizing DHCP to attain an IP address, the authenticating VLAN must provide a DHCP server or a DHCP relay function so that client may obtain an IP address.
Page 525: Web Authentication
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide • Certain functions exist on the Switch that will filter HTTP packets, such as the Access Profile function. The user needs to be very careful when setting filter functions for the target VLAN, so that these HTTP packets are not denied by the Switch.
Page 526: Wac Port Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide WAC Port Settings This window is used to view and configure the WAC port settings. To view the following window, click Security > Web-based Access Control > WAC Port Settings, as...
Page 527: Network Access Authentication
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 9-68 WAC Customize Page Window The fields that can be configured are described below: Parameter Description Page Title Enter a custom page title message here. This message can be up to 128 characters long.
Page 528: Network Access Authentication Global Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 9-69 Guest VLAN Window The fields that can be configured in Guest VLAN are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 529 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Lowercase and Uppercase. Delimiter Select the delimiter that will be used for the network access authentication MAC address here. Options to choose from are Hyphen, Colon, Dot, and None.
Page 530: Network Access Authentication Port Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Password Type Select the password type option here. Options to choose from are Plain Text and Encrypted. Password Enter the password used here. Click the Apply button to accept the changes made.
Page 531: Network Access Authentication Sessions Information
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description parameter is available. Enter the VLAN ID used here. This is useful when different VLANs on the Switch have different authentication requirements. After the client is authenticated, the client will not be re- authenticated when received from other VLANs.
Page 532: Safeguard Engine
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in Network Access Authentication Sessions Information are described below: Parameter Description Port Select the appropriate switch unit and port used for the query here.
Page 533: Safeguard Engine Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Protocol Name Sub-interface (Group) Description ICMPv4 Protocol Internet Control Message Protocol ICMPv6-Neighbor Protocol IPv6 Internet Control Message Protocol Neighbor Discovery Protocol (NS/NA/RS/RA) ICMPv6-Other Protocol IPv6 Internet Control Message Protocol except...
Page 534: Cpu Protect Counters
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Trap State Select to enable or disable the safeguard engine trap state here. The fields that can be configured in CPU Utilization Settings are described below:...
Page 535: Cpu Protect Type
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 9-75 CPU Protect Sub-Interface Window The fields that can be configured in CPU Protect Sub-Interface are described below: Parameter Description Sub-Interface Select the sub-interface option here. Options to choose from are Manage, Protocol, and Route.
Page 536: Trusted Host
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description 1024 packets per second. Tick the No Limit option to disable the rate limit. Click the Apply button to accept the changes made. The fields that can be configured in Protect Type Information are described below:...
Page 537: Storm Control
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide To view the following window, click Security > Traffic Segmentation Settings, as shown below: Figure 9-78 Traffic Segmentation Settings Window The fields that can be configured in Traffic Segmentation Settings are described below:...
Page 538 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 9-79 Storm Control Window The fields that can be configured in Storm Control Trap Settings are described below: Parameter Description Trap State Select the storm control trap option here. Options to choose from are None, Storm Occur, Storm Clear, and Both.
Page 539 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Type Select the type of storm attack that will be controlled here. Options to choose from are Broadcast, Multicast, and Unicast. When the action is configured as the shutdown mode, the unicast refers to both known and unknown unicast packets;...
Page 540 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Kbps, and Level. KBPS Rise Enter the rise KBPS value used here. This option specifies the rise threshold value as a rate of kilobits per second at which traffic is received on the port.
Page 541: Dos Attack Prevention Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide DoS Attack Prevention Settings This window is used to view and configure the Denial-of-Service (DoS) attack prevention settings. The following well-known DoS types which can be detected by most switches: •...
Page 542: Ssh
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Trap State Select to enable or disable the DoS attack prevention trap state here. Click the Apply button to accept the changes made. The fields that can be configured in DoS Attack Prevention Settings are described below:...
Page 543: Host Key
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 9-83 SSH Global Settings Window The fields that can be configured in SSH Global Settings are described below: Parameter Description IP SSH Server State Select to enable or disable the SSH server’s global state.
Page 544: Ssh Server Connection
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in Host Key are described below: Parameter Description Crypto Key Type Select the crypto key type used here. Options to choose from are the Rivest Shamir Adleman (RSA) key type and the Digital Signature Algorithm (DSA) key type.
Page 545: Ssl
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 9-88 SSH User Settings Window The fields that can be configured in SSH User Settings are described below: Parameter Description User Name Enter the SSH user’s username used here. This name can be up to 32 characters long.
Page 546: Ssl Global Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Switch supports the 3DES EDE encryption code defined by the Data Encryption Standard (DES) to create the encrypted text. • Hash Algorithm: This part of the cipher suite allows the user to choose a message digest function which will determine a Message Authentication Code.
Page 547: Crypto Pki Trustpoint
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in Import File are described below: Parameter Description File Select Select the file type that will be loaded here. Options to choose from are Certificate and Private Key.
Page 548: Ssl Service Policy
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Delete button to remove the specified entry. SSL Service Policy This window is used to view and configure the SSL service policy settings. To view the following window, click Security > SSL > SSL Service Policy, as shown below:...
Page 549 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 9-92 SFTP Server Settings Window The fields that can be configured in SFTP Server Settings are described below: Parameter Description SFTP Server Select to globally enable or disable the SFTP server feature here.
Page 550: 10. Oam
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide 10. OAM Cable Diagnostics Ethernet OAM CFM Settings This window is used to view and configure the Connectivity Fault Management (CFM) feature’s settings. To view the following window, click OAM > CFM > CFM Settings, as shown below:...
Page 551 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description provider or operator. It facilitates easy identification of administrative responsibility for each maintenance domain. Domain Level Enter the Maintenance Domain’s (MD’s) level here. The range is from 0 to 7.
Page 552 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description • Manage: Specifies to transmit the sender ID TLV with the managed address information. • Chassis-Manage: Specifies to transmit the sender ID TLV with the chassis ID information and the managed address information.
Page 553 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description MIP Creation This option is used to configure the MIP creation for an MA. Select one of the following options: • None: Specifies not to create the MIP on ports in an MA.
Page 554 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description MEPID Enter the MEP’s ID here. The range is from 1 to 8191. Each MEP configured in the same MA must have a unique MEP ID. The MEP on different MA can have the same MEPID.
Page 555 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Back button to return to the previous window. After clicking the Edit button, the following page will appear. Figure 10-7 CFM Settings (Add MA, Add MEP, MEPID Detail, Edit) Window...
Page 556 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description • Error-CCM: Specifies that only the fault alarms whose priority is equal to or higher than “Error CCM Received” will be sent. • XCON-CCM: Specifies that only the fault alarms whose priority is equal to or higher than “Cross-connect CCM Received”...
Page 557: Cfm Port Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in CFM LCK Settings are described below: Parameter Description State Select to Start or Stop the CFM management lock here. This feature will result in the MEP to send LCK PDUs to a client level MEP.
Page 558: Cfm Loopback Test
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Back button to return to the previous window. CFM Loopback Test This window is used to view and configure the CFM loopback test settings. To view the following window, click OAM > CFM > CFM Loopback Test, as shown below:...
Page 559 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide To view the following window, click OAM > CFM > CFM Linktrace Settings, as shown below: Figure 10-13 CFM Linktrace Settings Window The fields that can be configured in CFM Linktrace Settings are described below:...
Page 560: Cfm Packet Counter
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 10-14 CFM Linktrace Settings Window Click the Back button to return to the previous window. CFM Packet Counter This window is used to find and display the CFM packet counter information.
Page 561: Cfm Mip Ccm Table
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide To view the following window, click OAM > CFM > CFM Counter CCM, as shown below: Figure 10-16 CFM Counter CCM Window Click the Clear button to clear the counter information associated with all entries.
Page 562: Ethernet Oam
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 10-19 Cable Diagnostics Window The fields that can be configured in Cable Diagnostics are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 563 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 10-20 Ethernet OAM Settings Window The fields that can be configured in Ethernet OAM Settings are described below: Parameter Description Unit Select the switch’s unit ID that will be used here.
Page 564: Ethernet Oam Configuration Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description remote loopback mode, administrators must ensure that the local client is in the active mode and the OAM connection is established. If the local client is already in the remote loopback mode, then this feature cannot be applied.
Page 565 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 10-21 Ethernet OAM Configuration Settings Window The fields that can be configured in Ethernet OAM Configuration Settings are described below: Parameter Description Unit Select the switch’s unit ID that will be used here.
Page 566 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description • Error Frame Seconds: This feature is used to enable notifying the Ethernet OAM error frame second event and configure the monitor threshold and window on the specified port.
Page 567: Ethernet Oam Event Log Table
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in Ethernet OAM Configuration Table are described below: Parameter Description Unit Select the switch’s unit ID that will be used here. From Port ~ To Port Select the switch’s port range that will be used here.
Page 568: Ethernet Oam Duld Settings
Click the Clear All button to clear all the statistics information. Ethernet OAM DULD Settings This window is used to view and configure the Ethernet OAM feature’s D-Link Unidirectional Link Detection (DULD) settings. DULD is an extension of 802.3ah Ethernet OAM. It provides a mechanism to detect a unidirectional point-to-point Ethernet link without PHY support.
Page 569: Ddm
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 10-24 Ethernet OAM DULD Settings Window The fields that can be configured in Ethernet OAM DULD Settings are described below: Parameter Description Unit Select the switch’s unit ID that will be used here.
Page 570: Ddm Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide voltage threshold settings, bias current threshold settings, Tx power threshold settings, and Rx power threshold settings. DDM Settings The window is used to view and configure the action that will occur for specific ports when an exceeding alarm threshold or warning threshold event is encountered.
Page 571: Ddm Voltage Threshold Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 10-26 DDM Temperature Threshold Settings Window The fields that can be configured in DDM Temperature Threshold Settings are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 572: Ddm Bias Current Threshold Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Add and Delete. Type Select the type of voltage threshold. Options to choose from are Low Alarm, Low Warning, High Alarm, and High Warning. Value Enter the threshold value. This value must be between 0 and 6.55 Volt.
Page 573: Ddm Rx Power Threshold Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 10-29 DDM TX Power Threshold Settings Window The fields that can be configured in DDM TX Power Threshold Settings are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 574: Ddm Status Table
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Unit Select the switch unit that will be used for this configuration here. Port Select the port used for the configuration here. Action Select the action that will be taken here. Options to choose from are Add and Delete.
Page 575: 11. Mpls
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide 11. MPLS MPLS LDP Information Settings MPLS LSP Trigger Information MPLS Forwarding Settings MPLS LDP Neighbor Password Settings MPLS LDP Neighbor Targeted Settings MPLS LDP Neighbor Information MPLS Global Settings...
Page 576 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Max PDU Length In this field the LDP feature’s maximum PDU length value will be displayed. Initial Backoff Enter the initial back-off delay time here. The LDP back-off delay time is a mechanism to prevent an endless sequence of session setup failures that occur between two LSRs with incompatible settings.
Page 577: Mpls Lsp Trigger Information
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Loop Detection Select to enable or disable the loop detection feature here. LDP loop detection makes use of the Path Vector and Hop Count TLVs carried by the label request and label mapping messages to prevent looping of LDP messages.
Page 578: Mpls Forwarding Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 11-2 MPLS LSP Trigger Information Window The fields that can be configured are described below: Parameter Description Enter the sequence number of the LSP trigger filter rule here. When creating a new rule, if not specified, the SN begins from 10 and is incremented by 10.
Page 579 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 11-3 MPLS Forwarding Settings Window The fields that can be configured in Static FTN Settings are described below: Parameter Description Enter the FEC’s IPv4 address of the static FTN here.
Page 580: Mpls Ldp Neighbor Password Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description IP Address Enter the FEC’s IPv4 address of the static FTN here. Mask Enter the FEC’s subnet mask of the static FTN here. Click the Find button to locate a specific entry based on the information entered.
Page 581: Mpls Ldp Neighbor Information
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 11-5 MPLS LDP Neighbor Targeted Settings Window The fields that can be configured in MPLS LDP Neighbor Targeted Settings are described below: Parameter Description Neighbor Targeted Enter the LSR ID of the targeted peer here. The targeted peer is used to establish the LDP session with the non-directly connected neighbor.
Page 582: Mpls Global Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide MPLS Global Settings This window is used to view and configure the MPLS feature’s global settings. To view the following window, click MPLS > MPLS Global Settings, as shown below:...
Page 583: Mpls Ldp Session Information
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 11-8 MPLS LDP Interface Settings Window The fields that can be configured are described below: Parameter Description Interface VID Enter the interface’s VLAN ID used here. The range is from 1 to 4094.
Page 584: Mpls Ldp Statistic
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 11-9 MPLS LDP Session Information Window The fields that can be configured in MPLS LDP Session Information are described below: Parameter Description Peer Enter the IP address which is used as the peer LSR ID here.
Page 585: Mpls Qos Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide To view the following window, click MPLS > MPLS LDP Discovery Information, as shown below: Figure 11-12 MPLS LDP Discovery Information Window Click the Show Detail link to view more detailed information about the feature.
Page 586 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 11-15 MPLS QoS Settings Window The fields that can be configured are described below: Parameter Description Policy Name Enter the MPLS QoS policy’s name here. This name can be up to 32 characters long.
Page 587 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 11-16 MPLS QoS Settings (Edit, Inbound EXP to CoS Settings) Window The fields that can be configured in Inbound EXP to CoS Settings are described below: Parameter...
Page 588: Ping Mpls
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Apply button to accept the changes made. Click the Back button to return to the previous window. After clicking the Binding FECs Settings tab, the following page will appear.
Page 589: Traceroute Mpls Ipv4
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 11-19 Ping MPLS Window The fields that can be configured in Ping MPLS are described below: Parameter Description IPv4 Address Select and enter the FEC’s IPv4 address here whose LSP connectivity will be checked.
Page 590 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide echo request expired at each successive LSR along the LSP. The LSR returns an MPLS echo reply. If the sender cannot receive a reply before the timeout, the trace route will stop.
Page 591: 12. Mpls L2Vpn
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide 12. MPLS L2VPN VPWS Settings L2VC Interface Description VPLS Settings VPLS MAC Address Table VPWS Settings This window is used to view and configure the Virtual Private Wire Service (VPWS) settings.
Page 592 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in Find VPWS are described below: Parameter Description VC ID Enter the Pseudo-Wire’s (PW) service instance ID here. The range is from 1 to 4294967295.
Page 593: L2Vc Interface Description
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 12-3 VPWS Settings (Show Detail) Window Click the Back button to return to the previous window. L2VC Interface Description This window is used to view and configure the Layer 2 Virtual Circuit’s (L2VC) interface description.
Page 594: Vpls Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in Find L2VC Interface Description are described below: Parameter Description L2VC Interface Name Enter the L2VC interface’s name here. This name can be up to 64 characters long.
Page 595 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Apply button to accept the changes made. Click the Edit button to modify the specified entry. Click the Show Detail button to view more detailed information about the entry.
Page 596 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Type Select the type here. Options to choose from are Backup and Standalone. Selecting the Backup option will create a backup peer for PW redundancy of an H-VPLS.
Page 597: Vpls Mac Address Table
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 12-9 VPLS Settings (Show Detail, Local ACs, Show Detail) Window Click the Back button to return to the previous window. VPLS MAC Address Table This window is used to clear and display VPLS MAC address information.
Page 598 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Clear by AC button to clear the MAC addresses associated with the AC. Click the Clear by MAC button to clear the MAC address entered. Click the Clear by VPLS button to clear the MAC addresses associated with the VPLS instance.
Page 599: 13. Monitoring
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide 13. Monitoring Mirror Settings Traffic sFlow Device Environment Mirror Settings This window is used to view and configure the mirror feature’s settings. The switch allows users to copy frames transmitted and received on a port and redirect the copies to another port.
Page 600 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description between 1 and 4. Destination Tick the checkbox, next to the Destination option, to configure the destination for this port mirror entry. In the first drop-down menu select the destination type option. Options to choose from are Port, Remote VLAN, and Replace.
Page 601: Traffic
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 13-2 Mirror Settings (Show Detail) Window Click the Back button to return to the previous page. Traffic To view the following window, click Monitoring > Traffic. Traffic Monitoring by Direction This window is used to monitor traffic, per-port, in a certain direction.
Page 602: Traffic Monitoring By Type
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description to choose from are received (RX) and transmitted (TX). Click the Apply button to initiate the display information based to the selections made. Traffic Monitoring by Type This window is used to monitor traffic, per-port, of a certain type.
Page 603: Traffic Monitoring By Error
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 13-5 Traffic Monitoring by Size Window The fields that can be configured are described below: Parameter Description Port Select the port number to display. View By Select the View By option here. Options to choose from are Direction, Type, Size, and Error.
Page 604: Sflow
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 13-6 Traffic Monitoring by Error Window The fields that can be configured are described below: Parameter Description Port Select the port number to display. View By Select the View By option here. Options to choose from are Direction, Type, Size, and Error.
Page 605: Sflow Sampler Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide To view the following window, click Monitoring > sFlow > sFlow Receiver Settings, as shown below: Figure 13-8 sFlow Receiver Settings Window The fields that can be configured in sFlow Receiver Settings are described below:...
Page 606: Sflow Poller Settings
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 13-9 sFlow Sampler Settings Window The fields that can be configured in sFlow Sampler Settings are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 607: Device Environment
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured in sFlow Poller Settings are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 608: 14. Green
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide 14. Green Power Saving Power Saving This window is used to configure the power saving settings of the Switch. To view the following window, click Green > Power Saving, as shown below:...
Page 609: Eee
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Click the Apply button to accept the changes made for each individual section. Click the Delete button to remove the specified entry. NOTE: The hibernation feature can only be configured when physical stacking is disabled on this switch.
Page 610 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 14-3 EEE Window The fields that can be configured in EEE Settings are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 611: 15. Save And Tools
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide 15. Save and Tools Save Configuration Firmware Upgrade & Backup Configuration Restore & Backup Log Backup Ping Trace Route Reset Reboot System DLMS Settings Save Configuration This window is used to save the running configuration to the start-up configuration. This is to prevent the loss of configuration in the event of a power failure.
Page 612: Firmware Upgrade From Tftp
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Unit Select the switch unit that will be used for this configuration here. Source File In this field the source firmware file’s filename and path will be displayed after selection.
Page 613: Firmware Upgrade From Rcp
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 15-4 Firmware Upgrade from FTP Window The fields that can be configured are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 614: Firmware Backup To Http
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 15-5 Firmware Upgrade from RCP Window The fields that can be configured are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 615: Firmware Backup To Tftp
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Firmware Backup to TFTP This window is used to initiate a firmware backup to a TFTP server. To view the following window, click Tools > Firmware Upgrade & Backup > Firmware Backup to TFTP,...
Page 616: Firmware Backup To Rcp
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here. FTP Server IP Enter the FTP server’s IP address here. When select the IPv4 option, enter the IPv4 address of the FTP server in the space provided.
Page 617: Configuration Restore & Backup
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description can be up to 32 characters long. VRF Name Enter the VRF name here. This name can be up to 12 characters long. Source File Enter the source filename and path of the firmware file located on the switch here.
Page 618: Configuration Restore From Ftp
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide To view the following window, click Tools > Configuration Restore & Backup > Configuration Restore from TFTP, as shown below: Figure 15-11 Configuration Restore from TFTP Window The fields that can be configured are described below:...
Page 619: Configuration Restore From Rcp
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 15-12 Configuration Restore from FTP Window The fields that can be configured are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 620: Configuration Backup To Http
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 15-13 Configuration Restore from RCP Window The fields that can be configured are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 621: Configuration Backup To Tftp
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Unit Select the switch unit that will be used for this configuration here. Source File Enter the source filename and path of the configuration file located on the switch here.
Page 622: Configuration Backup To Rcp
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 15-16 Configuration Backup to FTP Window The fields that can be configured are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 623: Log Backup
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 15-17 Configuration Backup to RCP Window The fields that can be configured are described below: Parameter Description Unit Select the switch unit that will be used for this configuration here.
Page 624: Log Backup To Tftp
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description When the System Log option is selected, the system log will be backed up. When the Attack Log is selected, the attack log will be backed up.
Page 625: Ping
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide The fields that can be configured are described below: Parameter Description RCP Server IP Enter the RCP server’s IP address here. When select the IPv4 option, enter the IPv4 address of the RCP server in the space provided. When the IPv6 option is selected, enter the IPv6 address of the RCP server in the space provided.
Page 626 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Domain Name Select and enter the domain name of the system to discover. Ping Times Enter the number of times desired to attempt to Ping the IPv4 address configured in this window.
Page 627: Trace Route
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 15-22 Ping (Start) Window Click the Stop button to halt the Ping Test. Click the Back button to return to the IPv4 Ping section. Trace Route The trace route page allows the user to trace a route between the Switch and a given host on the network.
Page 628 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Domain Name Select and enter the domain name of the destination here. Max TTL Enter the Time-To-Live (TTL) value of the trace route request here. This is the maximum number of routers that a trace route packet can pass.
Page 629: Reset
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Figure 15-24 Trace Route (Start) Window Click the Back button to stop the trace route and return to the IPv4 Trace Route section. Reset This window is used to reset the switch’s configuration to the factory default settings.
Page 630: Dlms Settings
Figure 15-27 Reboot System (Rebooting) Window DLMS Settings This window is used to view and configure the D-Link License Management System (DLMS) settings. The license specifies the feature options that are enabled on the switch. License keys are sold in the market.
Page 631 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Parameter Description Unit Select the switch’s unit ID that will be used here. DLMS Activation Code Enter the DLMS activation code. This code should be 25 characters long.
Page 632: Appendix A - Password Recovery Procedure
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Appendix A - Password Recovery Procedure This section describes the procedure for resetting passwords on the D-Link DXS-3600 Series switch. Authenticating any user who tries to access networks is necessary and important. The basic authentication method used to accept qualified users is through a local login, utilizing a Username and Password.
Page 633: Appendix B - System Log Entries
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Appendix B - System Log Entries The following table lists all possible entries and their corresponding meanings that will appear in the System Log of this switch. 802.1X...
Page 634 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity Web(SSL). client-ip: It indicates the client’s IP address if valid through IP protocol. aaa-method: It indicates the authentication method, e.g.: local, server. server-ip: It indicates the AAA server IP address if authentication method is remote server.
Page 635 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity Event description: This log will be generated when RADIUS assigned a valid VLAN Informational ID attributes. Log Message: RADIUS server <server-ip> assigned VID: <vid> to port <interface- id>...
Page 636 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity ipaddr: IP address of BGP peer. Event description: BGP connection is normally closed. Informational Log Message: BGP-6-NORMALCLOSE: BGP connection is normally closed (Peer:<ipaddr>). Parameters description: ipaddr: IP address of BGP peer.
Page 637 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity ipaddr: IP address of BGP peer. Event description: The total bgp prefix number received exceeds the limit. Information Log Message: BGP-6-TOTALPFXMAX: The total number of prefix received reaches max prefix limit.
Page 638 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity Log Message: <interface-id> recover from BPDU under protection state. Parameters description: interface-id: Interface on which detected STP BPDU attack. Log Description Severity Event description: Cross-connect is detected Critical Log Message: CFM cross-connect.
Page 639 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity mepid: Represents the MEPID of the MEP. macaddr: Represents the MAC address of the MEP. Event description: Remote MEP's MAC reports an error status Warning Log Message: CFM remote MAC error.
Page 640 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity unitID: Represents the ID of the device in the stacking system. portNum: Represents the logical port number of the MEP. mepdirection: Represents the direction of the MEP. This can be "inward" or "outward".
Page 641 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity ipaddr: Represent client IP address. macaddr : Represent client MAC address. Event description: Firmware uploaded successfully. Informational Log Message: [Unit <unitID>, ]Firmware uploaded by <session> successfully (Username: <username>[, IP: <ipaddr>, MAC: <macaddr>])
Page 642 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity Event description: Configuration uploaded unsuccessfully. Warning Log Message: [Unit <unitID>, ]Configuration uploaded by <session> unsuccessfully. (Username: <username>[, IP: <ipaddr>, MAC: <macaddr>]) Parameters description: unitID: The unit ID.
Page 643 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity ipv6address: ipv6 address obtained from a DHCPv6 server. ipif-name: Name of the DHCPv6 client interface. Event description: The ipv6 address obtained from a DHCPv6 server starts Informational renewing.
Page 644 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity Event description: The IPv6 prefix obtained from a delegation router starts Informational renewing. Log Message: The IPv6 prefix < ipv6networkaddr > on interface <intf-name> starts renewing.
Page 645 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity Event description: The address of the DHCPv6 Server pool is used up Informational Log Message: The address of the DHCPv6 Server pool <pool-name> is used up.
Page 646 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide DULD Log Description Severity Event description: A unidirectional link has been detected on this port Informational Log Message: <interface-id> is unidirectional. Parameters description: unitID: the unit ID portNum: port number...
Page 647 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity portNum: 1.Interger value;2.Represent the logic port number of the device. link state: for ex: , 100Mbps FULL duplex Event description: Port link down. Informational Log Message: Port < interface-id > link down Parameters description: portNum: 1.Interger value;2.Represent the logic port number of the device.
Page 648 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity Log Message: <interface-id> LBD loop occurred. <interface-id > VLAN <vlan-id> LBD loop occurred. Parameters description: interface-id: Interface on which loop is detected. vlan-id: VLAN on which loop is detected.
Page 649 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity Log Message: Conflict LLDP-MED device type detected ( on port < portNum >, chassis id: < chassisType>, <chassisID>, port id: < portType>, <portID>, device class: <deviceClass>) Parameters description: portNum: The port number.
Page 650 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity 5. interfaceName(5) 6. agentCircuitId(6) 7. local(7) portID: port ID. deviceClass: LLDP-MED device type. Login/Logout CLI Log Description Severity Event description: Login through console successfully. Informational Log Message: [Unit <unitID>, ]Successful login through Console (Username:...
Page 651 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity username: Represent current login user. ipaddr: Represent client IP address. Event description: Logout through telnet. Informational Log Message: Logout through Telnet (Username: <username>, IP: <ipaddr>) Parameters description: username: Represent current login user.
Page 652 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity Event description: the host failed to pass the authentication. Critical Log Message: MAC-based Access Control host login fail (MAC: <mac-address>, <interface-id>, VID: <vlan-id>) Parameters description: mac-address: the host MAC addresses.
Page 653 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity Parameters Description: module-type: the expansion module name. Event Description: Module inserts and can’t works. Warning Log Message: Module < module-type > inserts but can’t work except reboot device.
Page 654 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity Log Message: New root port selected [( [Instance:<InstanceID> ], <interface-id>)] Parameters description: InstanceID: Instance ID. portNum:Port ID Event description: Spanning Tree port status changed Notice Log Message: Spanning Tree port status change [( [Instance:<InstanceID>...
Page 655 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity Event description: Spanning Tree MST configuration ID VLAN mapping table Informational added. Log Message: Spanning Tree MST configuration ID VLAN mapping table changed (instance: <InstanceID> add vlan <startvlanid> [- <endvlanid>]).
Page 656 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity changed state from Loading to Full Parameters description: nbr-id: Neighbor's router ID. Event description: One OSPF virtual neighbor state changed from Full to Down. Notice Log Message: OSPF-5-VNBRFULLTODOWN: OSPF nbr <nbr-id>...
Page 657 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity Event description: Power is recovered. Critical Log Message: Unit <unit-id> <power-descr> back to normal Parameters description: unitID: The unit ID. power-descr: The power position and ID.
Page 658 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity Log Message: Unit <unit-id>, Safeguard Engine enters NORMAL mode. Parameters description: unit_id: the unit ID. SNMP Log Description Severity Event Description: SNMP request received with invalid community string Informational Log Message: SNMP request received from <ipaddr>...
Page 659 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity Parameters description: Stack_TP_TYPE: The stacking topology type is one of the following: 1. Ring, 2. Chain. unitID: Box ID. macaddr: MAC address. Event description: Backup master changed to master.
Page 660 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity Multicast: Storm is resulted by multicast packets, including unknown L2 multicast, known L2 multicast, unknown IP multicast and known IP multicast. Unicast: Storm is resulted by unicast packets, including both known and unknown unicast packets interface-id: The interface ID on which a storm is occurring.
Page 661 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity Parameters description: vc_id: The link up Pseudo-wire ID ipaddr: The peer IP address of the link up Pseudo-wire Event description: Pseudo-wire is deleted Informational Log Message: Pseudo-wire id <vc_id> peer ip <ipaddr> is deleted...
Page 662 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity vr-id: VRRP virtual router ID. intf-name: Interface name on which virtual router is based. Auth-type: VRRP interface authentication type. Event description: Checksum error of one received VRRP advertisement message.
Page 663 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity into chip L2 table. Errcode <vrrp-errcode> Parameters description: vrrp-mac-addr: VRRP virtual MAC address vrrp-errcode: Errcode of VRRP protocol behavior. Event description: Failed when deleting a virtual MAC from switch chip L2 table.
Page 664 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity Event description: Failed when deleting a virtual MAC from switch chip’s L3 table. Error Log Message: VRRP-3-MACL3DELFAIL: Failed to delete virtual IP <vrrp-ip-addr> MAC <vrrp-mac-addr> from chip L3 table. Errcode <vrrp-errcode>...
Page 665 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Log Description Severity <ipaddr>). Parameters description: username: The use name that used to login SSL server. ipaddr: The IP address of SSL client. Event description: Logout through Web(SSL).
Page 666: Appendix C - Trap Entries
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Appendix C - Trap Entries The following table lists all possible trap log entries and their corresponding meanings that will appear in the switch. 802.1X Trap Name Description...
Page 667 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Trap Name Description dot1agCfmFaultAlarm This trap is initiated when a connectivity defect is 1.3.111.2.802 detected. .1.1.8.0.1 Binding objects: (1) dot1agCfmMepHighestPrDefect CFM Extension Trap Name Description dCfmAisOccurred A notification is generated when MEP detects the 1.3.6.1.4.1.17...
Page 668 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide DOS Prevention Trap Name Description dDosPreveAttackDetectedPacke The trap is sent when detect DOS attack. 1.3.6.1.4.1.17 1.14.59.0.2 Binding objects: (1) dDoSPrevCtrlAttackType (2) dDosPrevNotiInfoDropIpAddr (3) dDosPrevNotiInfoDropPortNumber ERPS Trap Name Description...
Page 669 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Trap Name Description an agent role, has detected that the ifOperStatus 1.5.4 object for one of its communication links left the down state and transitioned into some other state (but not into the notPresent state).
Page 670 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Trap Name Description mplsLdpPathVectorLimitMismatc This notification is sent when 1.3.6.1.2.1.10 the'mplsLdpEntityPathVectorLimit' does NOT match .166.4.0.2 the value of the 'mplsLdpPeerPathVectorLimit' for a specific Entity. mplsLdpSessionUp If this notification is sent when the value of 1.3.6.1.2.1.10...
Page 671 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Trap Name Description dMacAuthLoggedAgesOut The trap is sent when a MAC-based Access Control 1.3.6.1.4.1.17 host ages out. 1.14.153.0.3 Binding objects: (1) ifIndex, (2) dnaSessionClientMacAddress (3) dnaSessionAuthVlan MAC Notification...
Page 672 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Trap Name Description (1) ifIndex, (2) if AdminStatus (3) ifOperStatu linkDown A notification is generated when port linkdown. 1.3.6.1.6.3.1. 1.5.3 Binding objects: (1) ifIndex, (2) if AdminStatus (3) ifOperStatu...
Page 673 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Trap Name Description from normal to exhaust. 1.14.19.1.1.0. Binding objects: (1) dSafeguardEngineCurrentMode dSafeguardChgToNormal This trap indicates system change operation mode 1.3.6.1.4.1.17 from exhausted to normal. 1.14.19.1.1.0. Binding objects:...
Page 674 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Trap Name Description dStormCtrlOccurred This trap is sent when dStormCtrlNotifyEnable is 1.3.6.1.4.1.17 'stormOccurred' or 'both' and a storm is detected. 1.14.25.0.1 Binding objects: (1) ifIndex, (2) dStormCtrlNotifyTrafficType dStormCtrlStormCleared This trap is sent when dStormCtrlNotifyEnable is 1.3.6.1.4.1.17...
Page 675 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Trap Name Description dWebAuthLoggedSuccess The trap is sent when a host has successfully logged 1.3.6.1.4.1.17 in (passed Web-Authentication). 1.14.154.0.1 Binding objects: ifIndex dnaSessionAuthVlan dnaSessionClientMacAddress dnaSessionClientAddrType dnaSessionClientAddress dnaSessionAuthUserName dWebAuthLoggedFail The trap is sent when a host has failed to pass Web- 1.3.6.1.4.1.17...
Page 676: Appendix D - Radius Attributes Assignment
DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Appendix D - RADIUS Attributes Assignment The RADIUS Attributes Assignment on the DXS-3600 is used in the following modules: Console, Telnet, SSH, Web, 802.1X, MAC-based Access Control, and WAC.
Page 677 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide is configured on the RADIUS server with a value of “0”, the effective bandwidth will be set “no_limited”, and if the bandwidth is configured less than “0” or greater than maximum supported value, the bandwidth will be ignored.
Page 678 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Tag field value String field format 0x01 VLAN name (ASCII) 0x02 VLAN ID (ASCII) Others When the switch receives the VLAN setting string, it will think it is the VLAN ID first.
Page 679: Appendix E - Ietf Radius Attributes Support
RADIUS attributes currently supported by the switch. RADIUS attributes are supported by the IETF standard and Vendor-Specific Attribute (VSA). VSA allows the vendor to create an additionally owned RADIUS attribute. For more information about D-Link VSA, refer to the RADIUS Attributes Assignment Appendix.
Page 680 DXS-3600 Series Layer 3 Managed 10Gigabit Ethernet Switch Web UI Reference Guide Number IETF Attribute NAS-Port-ID NAS-IPv6-Address RADIUS Accounting Attributes: Number IETF Attribute User-Name NAS-IP-Address NAS-Port Service-Type Framed-IP-Address Calling-Station-ID NAS-Identifier Acct-Status-Type Acct-Delay-Time Acct-Input-Octets Acct-Output-Octets Acct-Session-ID Acct-Authentic Acct-Session-Time Acct-Input-Packets Acct-Output-Packets Acct-Terminate-Cause...

D-Link DXS-3600 Series Reference Manual

1 Introduction

2 Web-Based Switch Configuration

3 System

4 Management

5 Layer 2 Features

6 Layer 3 Features

7 Quality of Service (Qos)

8 Access Control List (ACL)

9 Security

Quick Links

Related Manuals for D-Link DXS-3600 Series

Summary of Contents for D-Link DXS-3600 Series
