Selecting video formats

802BT/802R Video Test Generator User Guide
hold down the G key while pressing and releasing the B key to switch between digital and
analog outputs. The table below shows the AVST and DVST command settings for analog
and digital outputs.
Video Signal Interface
Analog YYY Grayscale
Analog RGB Color
CVBS or S-Video Grayscale
CVBS or S-Video Color
Analog YPbPr SDTV Color
Analog YPbPr HDTV Color
Digital YYY Grayscale
Digital RGB Color
Digital YCbCr SDTVColor
Digital YCbCr HDTV Color
This section explains how to configure the generator to output video formats that are
supported by the device being tested.
Note: You can create your own formats. See
details. Additionally, you can create your own Format knob lists. See
lists" on page 67 for details.

Selecting formats automatically

When testing EDID-compatible displays, the generator can automatically update the
Format knob list (list of format names shown on the LCD) to include only formats
supported by the display under test. Depending on the output used, the generator can do
this on demand, or automatically when a display is connected.
To update the Format knob list on demand:
1. Connect the display you want to test with the generator.
2. Hold down the R key, and then press and release the ACS key. This puts the generator
into either Analog Friendly or Digital Friendly mode based on the EDID that the
generator receives.
3. Turn the Format knob to choose a format. Only formats supported by the display are
listed.
AVST
1
2
3
4
6
7
0
0
0
0
"Creating custom
DVST
0
0
0
0
0
0
9
10
13
14
formats" on page 63 for
"Editing Format knob
25
