Bosch
Description
Box_50mm, Box_64mm, Box100mm, Box150mm, Box200mm, Box250mm
Description
612 Appendix B Image Reference
Special test image developed per customer specifications. This image has 6 versions.
The primary version has a solid white box in the center of the active video. Depending on
the image selected, the box is sized by square millimeters. If there is room, information on
the current format appears below and to the left of the box. This shows the number of
active pixels and lines as well as the horizontal and vertical scan rates. A forward slash (I)
after the number of active lines indicates the format is interlaced.
