Video Test Generator User Guide
B
Bar information (see EIA/CEA-861-B standard, Table 8 for settings)
B B
1 0 Bar Information
0 0 Bar data not valid
0 1 Vertical Bar info valid
1 0 Horizontal Bar info valid
1 1 Vertical & Horizontal Bar info
valid
A
Active Format Information (AFD) present (see EIA/CEA-861-B standard, Table 8 for
settings)
A Active Format Information
0 Present
0 No data
1 Active format information valid
Y
Video type (see EIA/CEA-861-B standard, Table 8 for settings)
Y Y
1 0 RGB or YCbCr
0 0 RGB (default)
0 1 YCbCr 4:2:2
1 0 YCbCr 4:4:4
1 1 Future
R
Active Format Aspect Ratio (ADF value) (see EIA/CEA-861-B standard, Table 9 for
settings)
R R R R
3 2 1 0 Active Format Aspect Ratio
1 0 0 0 Same as picture aspect ratio
1 0 0 1
1 0 1 0
1 0 1 1
other val- Per DVB AFD active_format
ues
M
Picture Aspect Ratio (see EIA/CEA-861-B standard, Table 9 for settings)
M M Picture Aspect
1 0 Ratio
0 0 No data
0 1 4:3
1 0 16:9
4:3 (Center)
16:9 (Center)
14:9 (Center)
field
