Special key operations summary

20 Chapter 1 Getting Started
Special mode Function
HDCP tester mode Enables HDCP testing.
Hot plug formats Auto-configures generator for-
mat knob list based on EDID in
response to hot plug.
DVI mode (disable Outputs DVI on HDMI connec-
HDMI) tor.
Hot plug bypass Bypasses hot plug detection
and auto-configuration of the
generator.
The following table describes modes that can be enabled while the generator is running,
and the physical controls and comands for using the modes.
Mode Function
Toggle analog/digital Outputs either digital or ana-
log.
Rotate video type Outputs either RGB, color dif-
ference, or monochrome.
DDC-based auto-con- Auto-configures generator for-
figuration mat knob list based on EDID.
Toggle biLevel/triLevel Toggles between tri-level and
bi-level syncs for analog HDTV
formats with tri-level sync type.
Physical control Command
G, ACS Set: SROP 8192
Rst: SROP
R, ACS Set: SROP 16384
Rst: SROP
R, G Set: SROP 32768
Rst: SROP
Step, R, ACS Set: SROP 65536
Rst: SROP
Physical control
(hold 1st & press
2nd) Command
G, B AVST x;
R, B
R, ACS
B, ACS TSPG x
0 8192
0 16384
0 32768
0 65536
DVST x
