XAFD
Class
Description
Command syntax
572 Appendix A Command Reference
AFD Mode Setting
Format parameter setting - HDMI active video
Sets the SXCX, SXEX, EXAR, EXCX, and CXAR parameters to values necessary to
support a given AFD code.
XAFD afd_code
afd_code
0 to 15
The following table provides a listing of AFD codes and corresponding parameter settings.
Note: This command will not change the value of SXAR (which remains fixed by the
current format). Therefore, the range of allowed AFD values are determined by the value
of SXAR in the current format.
AFD Code SXAR
2 1.33
1.77
3 1.33 or 1.77
4 1.33 or 1.77
8 1.33
1.77
9 1.33
1.77
10 1.33
1.77
11 1.33
1.77
13 1.33
1.77
14 1.33
1.77
15 1.33
1.77
1 1
CXAR EXCX
1.77 0
1.77 0
1.55 0
> 1.77 0
1.33 0
1.33 0
1.33 0
1.33 0
1.77 0
1.77 0
1.55 0
1.55 0
1.55 0
1.55 8
1.55 8
1.55 0
1.33 8
1.33 0
1
EXAR SXEX
CXAR 280
CXAR 16
CXAR 280
CXAR 264
CXAR 0
CXAR 0
CXAR 16
CXAR 264
CXAR 264
CXAR 32
CXAR 264
CXAR 264
CXAR 8
1.33 264
1.77 264
CXAR 8
1.77 264
1.33 8
