8
Chapter 1 Getting Started
•
M for monochrome video
•
C for RGB color video
•
Y for YPrPb (analog) or YCrCb (digital) with 4:4:4 color sampling
•
y for YCrCb (digital) with 4:2:2 color sampling
To use Status Display mode:
1. Turn off the generator.
2. Hold down the Step, G, and B keys while starting the generator, until status display
displays.
Special:
keys
Status display
Alternatively, you can set the status display mode by entering the following command:
SROP
8;
ALLU
Determining if the active format has been modified
If the active format has not been modified from the factory setting, then the index number
and format name are separated by an equal (=) character. If the active format has been
modified, then the index number and format name are separated by a blank space. The
blank space indicates that the active format has been modified from the default format
definition.
