580 Appendix A Command Reference
M M Picture Aspect
1 0 Ratio
1 1 Future
C
Colorimetry (see EIA/CEA-861-B standard, Table 9 for settings)
C C
1 0 Colorimetry
0 0 No data
0 1 SMPTE 170M ITU601
1 0 ITU709
1 1 Future
SC
Non-uniform Picture Scaling (see EIA/CEA-861-B standard, Table 11 for settings)
SC SC
1 0 Non-Uniform Picture Scaling
0 0 No known non-uniform scaling
0 1 Picture has been scaled horizontally
1 0 Picture has been scaled vertically
1 1 Picture has been scaled horizontally and vertically
ETB
Line number of end of top bar representing the last line of a horizontal letterbox bar
area at the top of the picture (0 = no horizontal bar present at top of picture).
SBB
Line number of start of bottom bar representing the first line of a horizontal letterbox
bar area at the bottom of the picture.
ELB
Pixel number of end of left bar representing the last horizontal pixel of a vertical
pillar-bar area at the left side of the picture (0 = no vertical bar present at left of
picture).
SRB
Pixel number of start of right bar representing the first horizontal pixel of a vertical
pillar-bar area at the left side of the picture.
VIC
Video Format Identification Codes (see
PR
Pixel repetition for "2x" and "4x" formats (see EIA/CEA-861-B standard, Table 14 for
settings) This field is set automatically based on settings for
PR PR PR PR
3 2 1 0 Pixel Repetition for Optional (2880)
0 0 0 0 No Repetition (i.e. pixel sent once)
0 0 0 1
DVIC
Pixel sent 2 times (i.e. repeated
once)
for settings).
NCPP and NPPP.
