Video interfaces

802BT/802R Video Test Generator User Guide
This section describes the video interfaces available on the generator.

VGA interface

Use to output analog video for testing analog video displays. The following table describes
the VGA connector pinouts.
Pi Signal
1 Analog Red Video
2 Analog Green Video 7
3 Analog Blue Video
4 No Connection
5 Digital Ground

DVI-I interface

Use to output digital video for testing DVI-compliant video displays. Note that the DVI-I
connector also provides an analog output which can be used to test analog formats with a
VGA to DVI adapter when the generator is in analog friendly mode.
The DVI connector pinouts are shown in the following table.
Pin Signal Pin
1 TMDS D2- 9
2 TMDS D2+ 10
3 D2/4 Shield 11
4 TMDS D4- 12
5 TMDS D4+ 13
6 DDC Clock 14
7 DDC Data 15
8 No Connection 16
Pin Signal
6 Analog Red Video Ground
Analog Green Video Ground 12
8 Analog Blue Video Ground
9 DDC/EDID +5 Vdc Out
10 Digital Ground
Signal Pin Signal
TMDS D1- 17 TMDS D0-
TMDS D1+ 18 TMDS D0+
D1/3 Shield 19 D0/5 Shield
TMDS D3- 20 TMDS D5-
TMDS D3+ 21 TMDS D5+
+5 Vdc 22 Clock Shield
Ground 23 TMDS Clock+
Hot Plug Detect 24 TMDS Clock-
Pin Signal
11 No Connection
DDC/EDID Serial Data
13 Horizontal Sync
14 Vertical Sync
15 DDC/EDID Data Clock
Pin Signal
C1 Analog Red
C2 Analog Green
C3 Analog Blue
C4 Horizontal Sync
C5 Analog Ground
9
