General video display testing procedure

Making physical connections

Setting the video output mode

24 Chapter 2 Testing Video Displays
This section provides an overview of the video testing process, which involves connecting
the generator to the display under test, selecting a format appropriate for the display, and
then selecting images to exercise the display to ensure proper functioning.
Use the following table to connect the generator with display under test.
Display type
Information Computer - VESA (DMT,
Technology CVT)
(IT)
Computer - VESA DDWG
Consumer SDTV - ITU-470-6 base-
Equipment band
(CE)
SDTV - ITU-470-6 base-
band
SDTV - CEA-861B
HDTV - CEA-861B
HDTV - CEA-861B
1. Optional cable available from Quantum Data.
If the application involves testing similar displays with one type of video signal output for
extended periods of time (for example, in a production environment), use one of the
following modes:
• Digital Friendly mode – Digital formats are output without change, while analog
formats are temporarily switched to digital. This mode is available only if the generator
has a digital option (DVI, LVDS, or HDMI) installed.
• Analog Friendly mode – Analog formats are output without change, while the digital
formats are temporarily switched to analog.
For information about using these modes, see
When you need to test various video signal outputs and color encoding methods (for
example, in a repair center), disable all friendly modes, and enable the Status Display
mode (see "LCD" on page 7) so that you can determine the current configuration. Then,
Signal type
Analog component RGB
Digital component RGB
Analog composite CVBS
Analog composite S-Video
Analog component YPbPr
Digital component DVI
RGB
Digital component HDMI
RGB and YCbCr
"Summary of special
Cable
VGA to VGA
DVI to DVI
BNC to RCA 75 Ohm
S-Video (miniDin to
MiniDin)
1
VGA to RCA
DVI to DVI, or HDMI to
DVI
HDMI to HDMI
modes" on page 19.
