802BT/802R Video Test Generator User Guide
The following table describe the default DCS priority scheme for horizontal sync.
OUTG SSST
0 Do not care
1 Do not care
Do not care 8 (DPMS – OFF)
1 9 (DPMS – SUS-
PEND)
1 10 (DPMS –
STANDBY)
1 1, 3, 5, 7, or 11
1 2, 6, or 11 (DCS)
The following table describe the default DCS priority scheme for vertical sync.
OUTG SSST
0 Do not care
1 Do not care
Do not care 8 (DPMS – OFF)
1 9 (DPMS – SUS-
PEND)
1 10 (DPMS –
STANDBY)
1 1, 3, 5, 7, or 11
1 2, 6, or 11 (DCS)
To enable the legacy DCS priority scheme:
1. Turn off the generator.
2. Hold down the Step and DCS keys while starting the generator.
The generator will remain in this mode through subsequent power cycles until the
generator is re-initialized or reset with the "No special modes" command (hold down
ACS+DCS+DSS while starting the generator).
HSPG HS Output
Do not care No signal
0 No signal
Do not care No signal
Do not care Horizontal Sync
Do not care No signal
1 Horizontal Sync
1 Composite Sync
VSPG VS Output
Do not care No signal
0 No signal
Do not care No signal
Do not care No signal
Do not care vertical Sync
1 vertical Sync
1 Composite Sync
HS Polarity
Do not care
Do not care
Do not care
HSPP
Do not care
HSPP
CSPP
VS Polarity
Do not care
Do not care
Do not care
Do not care
VSPP
VSPP
CSPP
