Testing 8-channel HDMI audio output from internal source

802BT/802R Video Test Generator User Guide
To support testing of HDMI audio, the 802 generator provides 8-channel LPCM audio
(using an internally-generated sinewave) at the highest audio sampling rate (192 kHz).
Multiple scenarios are provided that allow you to test one or both audio channels at
different amplitudes and frequencies, as well as test using the different supported
sampling rates.
The following table lists the images used to perform HDMI audio testing using an internal
audio source.
Image Description
Audio_1 Channel 1 output with adjustable amplitude.
Audio_1f Channel 1 output with adjustable frequency.
Audio_2 Channel 2 output with adjustable amplitude.
Audio_2f Channel 2 output with adjustable frequency.
Audio_3 Channel 3 output with adjustable amplitude.
Audio_3f Channel 3 output with adjustable frequency.
Audio_4 Channel 4 output with adjustable amplitude.
Audio_4f Channel 4 output with adjustable frequency.
Audio_5 Channel 5 output with adjustable amplitude.
Audio_5f Channel 5 output with adjustable frequency.
Audio_6 Channel 6 output with adjustable amplitude.
Audio_6f Channel 6 output with adjustable frequency.
Audio_7 Channel 7 output with adjustable amplitude.
Audio_7f Channel 7 output with adjustable frequency.
Audio_8 Channel 8 output with adjustable amplitude.
Audio_8f Channel 8 output with adjustable frequency.
To test an HDMI display using HDMI 8-channel audio from the generator:
1. Connect an HDMI display to the Tx connector on the generator.
2. If necessary, set up the generator for HDMI output.
• See "Setting up the generator for HDMI
up the generator for HDMI operation.
3. Using the Format knob, select either the DMT0660 or 480i2x29 format.
operation" on page 147 for steps on setting
157
