Quantum Data 802BT User Manual page 591

Query syntax
Query response
Example 1
Example 2
Example 3
Video Test Generator User Guide
PR PR PR PR
3 2 1 0 Pixel Repetition for Optional (2880)
0 0 1 0
0 0 1 1
0 1 0 0
0 1 0 1
0 1 1 0
0 1 1 1
1 0 0 0
1 0 0 1
XAVI:aviparameter?
value
The following example sets the scan information (S parameter) to overscanned in the AVI
Infoframe.
XAVI:S 1
IFGU
The following example sets the AFD flag (A parameter) to not present and the picture
aspect ratio (M parameter) to 4:3 in the AVI Infoframe.
XAVI: A 0; M 1;IFGU
The following example sets an Audio InfoFrame (version 2) with these properties:
• Overscanned (S parameter)
• Bar information not valid (B parameter)
• Active format information valid (A parameter)
• YC C video type (Y parameter)
b r
• Active format aspect ratio same as picture format ratio (R parameter)
• 4:3 picture aspect ratio (M parameter)
• SMPTE 170M colorimetry (C parameter)
• No known non-uniform scaling (SC parameter)
• No specified line number for horizontal bar (ETB and SBB parameters)
• No specified pixel number for vertical bar (ELB and SRB parameters)
• 480p59 video format (VIC format)
• No pixel repetition (PR format)
XAVI 2 1 13 1 0 1 2 8 1 1 0 0 0 0 0 2 0;IFGU
Pixel sent 3 times
Pixel sent 4 times
Pixel sent 5 times
Pixel sent 6 times
Pixel sent 7 times
Pixel sent 8 times
Pixel sent 9 times
Pixel sent 10 times
581
